| Ref | Part Number | Description |
|---|
| 1 |
3-8394 |
DISCONTINUED Price: Call Us |
| 1 |
530039127 |
Flywheel Price: $3.33 |
| 2 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 2 |
530001733 |
Nut Price: $2.99 |
| 3 |
3-6501 |
DISCONTINUED Price: Call Us |
| 3 |
530015254 |
Wave Washer Price: $1.99 |
| 4 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 4 |
530027163 |
Retainer Price: $0.28 |
| 5 |
3290-239 |
DISCONTINUED Price: Call Us |
| 5 |
530027170 |
Starter Pulley Price: $3.40 |
| 6 |
3-7138 |
DISCONTINUED Price: Call Us |
| 6 |
545008009 |
KIT STARTER SPRING This part replaces 530042067. Price: $5.99 |
| 7 |
530027096 |
Baffle Plate Price: $3.33 |
| 8 |
256-148 |
FLANGE BUSHING Price: $14.60 |
| 8 |
530010861 |
Fan Housing Price: $3.33 |
| 9 |
5-1036 |
DISCONTINUED Price: Call Us |
| 9 |
530015425 |
Screw This part replaces 530015709. Price: $0.99 |
| 10 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 10 |
530015441 |
Washer Price: $1.99 |
| 11 |
3-8008 |
Plate, Lower Hinge Price: Call Us |
| 11 |
530015713 |
Screw Price: $1.99 |
| 12 |
3-6493 |
DISCONTINUED Price: Call Us |
| 12 |
530027164 |
Starter Cam Price: $3.33 |
| 13 |
32121-48 |
PIN-SPRING Price: $0.61 |
| 13 |
530027162 |
Starter Dog Price: $1.99 |
| 14 |
323-6 |
SCREW-HH Price: $0.66 |
| 14 |
530015241 |
Screw Price: $1.99 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15 |
530027569 |
Handle-Starter This part replaces 530026735. Price: $1.99 |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
530069233 |
Rope Kit Price: $3.33 |
| 17 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 17 |
530015720 |
Screw Price: $1.99 |
| 18 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 18 |
530001516 |
Snap Ring Price: $1.99 |
| 19 |
117127 |
TIRE (16 X 6.5-8) 2-PLY -2 WHEEL AXEL This part replaces 231-39. Price: $107.13 |
| 19 |
530015696 |
Clip Price: $0.99 |
| 20 |
3218-6 |
NUT-JAM Price: $0.61 |
| 20 |
530057236 |
OIL TANK CAP This part replaces 530010846. Price: $5.99 |
| 21 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 21 |
530015425 |
Screw This part replaces 530015708. Price: $0.99 |
| 22 |
3-8014 |
AXLE SHAFT Price: $49.11 |
| 22 |
530039128 |
Ignition Module (Inc. # 48) Price: $36.99 |
| 23 |
242-32 |
LUG NUT Price: $4.77 |
| 23 |
530069217 |
Gasket Set (Inc. 79 & 108) Price: $3.33 |
| 24 |
3-6506 |
DISCONTINUED Price: Call Us |
| 24 |
530015306 |
Screw Price: $1.99 |
| 25 |
242-39 |
WHEEL ASM Price: $244.32 |
| 25 |
530027264 |
Clamp Price: $1.99 |
| 26 |
3233-23 |
Carriage Bolt Price: Call Us |
| 26 |
530032093 |
Crankshaft Bearing Price: $7.99 |
| 27 |
3-2889 |
DISCONTINUED Price: Call Us |
| 27 |
530002595 |
Flywheel Key Price: $1.99 |
| 28 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 28 |
530027143 |
Crankshaft/Rod Ass'y. Price: $129.99 |
| 29 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 29 |
530032100 |
Piston Pin Bearing Price: $3.33 |
| 30 |
323-6 |
SCREW-HH Price: $0.66 |
| 30 |
530010862 |
Piston Kit (Includes: 29, 46, 50 & Piston Pin) Model 3000 CB Price: $59.99 |
| 31 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 31 |
530015710 |
Screw Price: $3.33 |
| 32 |
3-8011 |
DISCONTINUED Price: Call Us |
| 32 |
530027184 |
Spur Price: $1.99 |
| 33 |
5-1037 |
DISCONTINUED Price: Call Us |
| 33 |
530019146 |
Crankshaft Seal Price: $2.99 |
| 34 |
5-0460 |
STRG SWAGED CABLE ASM Price: $96.86 |
| 34 |
530010865 |
Crankcase Ass'y. (Inc. 18,26,33,125-127,129 137 & 138,141, & 142) Price: $3.33 |
| 35 |
5-2106 |
PVT CSTR/SFT WA*RO Price: $291.44 |
| 35 |
530015718 |
Screw Price: $0.24 |
| 36 |
4-2320 |
DISCONTINUED Price: Call Us |
| 36 |
530015722 |
Washer Price: $1.99 |
| 37 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 37 |
530028645 |
Muffler Cover Price: $3.99 |
| 38 |
3210-3 |
SCREW-HH Price: $5.29 |
| 38 |
530027095 |
Spark Arrestor Screen Price: $2.99 |
| 39 |
3-8408 |
DISCONTINUED Price: Call Us |
| 39 |
530028647 |
Muffler Diffuser Price: $3.99 |
| 40 |
351-26 |
DISCONTINUED Price: Call Us |
| 40 |
530028646 |
Muffler Baffle Plate Price: $1.99 |
| 41 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 41 |
530028644 |
Muffler Body Price: $4.99 |
| 42 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 42 |
530012153 |
Cylinder Model 3000 CB Price: $2.00 |
| 43 |
3217-6 |
NUT-HEX Price: $1.19 |
| 43 |
530030123 |
Spark Plug (RCJ-4) Price: $3.33 |
| 44 |
322-13 |
SCREW-HH Price: $2.73 |
| 44 |
530030054 |
Sealant Price: $17.99 |
| 45 |
5108 |
VALVE This part replaces 232-21. Price: $6.29 |
| 46 |
5-1257 |
DISCONTINUED Price: Call Us |
| 46 |
530015697 |
Retainer Price: $1.99 |
| 47 |
322-10 |
SCREW-HH Price: $0.70 |
| 47 |
530015721 |
Screw Price: $3.33 |
| 48 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 48 |
530039130 |
High Tension Lead Ass'y. Price: $3.33 |
| 49 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 49 |
530027218 |
Carb. Adaptor Price: $6.96 |
| 50 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 50 |
530027092 |
Piston Ring Model 3000 CB Price: $5.00 |
| 51 |
530015707 |
Screw Price: $1.99 |
| 52 |
530027285 |
Clamp Ass'y. Price: $2.99 |
