| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $138.99 |
| 2 |
874760412 |
BOLT LT Price: $3.99 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $11.99 |
| 010 |
115-4117 |
COMPLETE GEAR CASE This part replaces 105-3707. Price: $569.64 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 020 |
127-0425 |
PLUG This part replaces 98-9598. Price: $4.34 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 24 |
532400253 |
CABLE.BATT.POS.WIRE.TG.DA SOL Price: $7.99 |
| 25 |
532412895 |
CABLE.STARTER.6G.BL/RED.17.5 Price: $10.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $24.99 |
| 030 |
98-9388 |
JOINT-PIPE Price: $31.66 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 040 |
98-9544 |
SPRING Price: $0.94 |
| 40 |
532401104 |
HARNESS.IGN.DASH.HUQ/P Price: $68.99 |
| 41 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 817720408. Price: $1.99 |
| 42 |
532154336 |
Cover, Terminal Red This part replaces 532131563. Price: $4.99 |
| 43 |
532192507 |
SOLENOID.W/BRASS.PLUNG Price: $16.99 |
| 46 |
532401763 |
GUAGE.SRVCMNDR.HRMTR. Price: $48.32 |
| 050 |
98-9543 |
SEAT-VALVE Price: $26.61 |
| 50 |
532174651 |
PTO SWITCH Price: $22.99 |
| 55 |
532171877 |
Bolt 5/16-18 unc x 3/4 This part replaces 817060512. Price: $3.99 |
| 060 |
98-9380 |
BALL Price: $0.84 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $24.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 91 |
532190270 |
STRAP, BATTERY MOUNT Price: $5.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 100 |
819091416 |
WASHER Price: $3.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 110 |
98-9540 |
OIL PUMP ROTOR ASM Price: $271.67 |
| 120 |
105-3708 |
COVER-PUMP, OIL Price: $18.70 |
| 130 |
98-9592 |
SCREW Price: $0.70 |
| 140 |
98-9633 |
GASKET-CASE, GEAR Price: $30.19 |
| 150 |
100-1765 |
BOLT This part replaces 98-7496. Price: $1.59 |
| 160 |
105-3797 |
BOLT Price: $1.40 |
| 170 |
98-9356 |
BOLT Price: $2.06 |
| 180 |
98-9437 |
BOLT Price: $1.05 |
| 190 |
99-3510 |
BOLT This part replaces 98-9586. Price: $0.80 |
| 200 |
99-3511 |
BOLT Price: $5.29 |
| 210 |
105-3709 |
STUD Price: $1.13 |
| 220 |
98-7572 |
NUT Price: $0.32 |
| 230 |
98-7699 |
WASHER-SPRING Price: $0.44 |
| 240 |
119-8038 |
SEAL-OIL This part replaces 98-9482. Price: $40.16 |
| 250 |
98-9372 |
O-RING Price: $1.66 |
| 260 |
105-3777 |
O-RING Price: $1.72 |
| 270 |
105-3710 |
STUD Price: $1.16 |
| 280 |
99-3515 |
PLUG-GEARCASE This part replaces 98-9641. Price: $9.00 |
| 290 |
107-9075 |
PLUG-FILLER, OIL This part replaces 98-9449. Price: $7.25 |
