| Ref | Part Number | Description |
|---|
| 1 |
117-5199 |
HUB-PEDAL, TRACTION Price: $47.99 |
| 1 |
544112903 |
CUTTING DECK Price: $349.99 |
| 2 |
117-9507 |
PEDAL-ACCELERATOR Price: $12.86 |
| 2 |
544112801 |
CUTTING DECK ASSY Price: $318.99 |
| 3 |
506916201 |
NUT Price: $4.99 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 4 |
544449201 |
PLUG Price: $64.99 |
| 5 |
106-3840 |
PEDAL-TRACTION Price: $88.41 |
| 5 |
506570104 |
BOLT Price: $4.99 |
| 6 |
576384102 |
BLADE HOUSING ASSY This part replaces 544065901. Price: $79.99 |
| 6 |
92-7305 |
SPRING-EXTENSION Price: $9.99 |
| 7 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 7 |
544067902 |
SHAFT Price: $37.99 |
| 8 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 8 |
738230434 |
BEARING Price: $17.99 |
| 9 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 9 |
544068001 |
SPACER Price: $11.99 |
| 10 |
576384201 |
BEARING HOUSING This part replaces 544067801. Price: $29.99 |
| 10 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 11 |
127-2721 |
CABLE-TRACTION Price: $141.82 |
| 11 |
576384101 |
BLADE HOUSING ASSY This part replaces 544065902. Price: $84.99 |
| 12 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 12 |
544067901 |
SHAFT Price: $39.99 |
| 13 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 13 |
738230434 |
BEARING Price: $17.99 |
| 14 |
544068001 |
SPACER Price: $11.99 |
| 14 |
66-8010 |
SPACER Price: $4.19 |
| 15 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 15 |
576384201 |
BEARING HOUSING This part replaces 544067801. Price: $29.99 |
| 16 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 16 |
535423801 |
BOLT Price: $4.99 |
| 17 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 17 |
734116401 |
WASHER BRB 8.4X17 Price: $5.99 |
| 18 |
321-9 |
SCREW-HH Price: $0.27 |
| 18 |
732211801 |
LOCKNUT M8 Price: $3.99 |
| 19 |
506922101 |
PULLEY Price: $29.99 |
| 19 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 20 |
115-0282 |
PROXIMITY SENSOR ASM Price: $155.22 |
| 20 |
506533501 |
KEY Price: $3.99 |
| 21 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 21 |
544068002 |
SPACER Price: $9.99 |
| 22 |
323-17 |
SCREW-HH Price: $2.05 |
| 22 |
506778601 |
PULLEY Price: $49.99 |
| 23 |
62-4420 |
WASHER Price: $6.69 |
| 23 |
734117441 |
WASHER Price: $3.99 |
| 24 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 24 |
544114101 |
SCREW Price: $3.99 |
| 25 |
117-8066 |
MOW-STOP Price: $62.29 |
| 25 |
535504202 |
ADAPTER Price: $19.99 |
| 26 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 27 |
106-3731 |
ROD-PIVOT Price: $36.19 |
| 27 |
588145601 |
WASHER This part replaces 506792301. Price: $6.99 |
| 28 |
110-8982 |
WASHER-SPRING Price: $2.71 |
| 28 |
544114101 |
SCREW Price: $3.99 |
| 29 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 29 |
586966601 |
BELT TENSIONER ASSY KIT This part replaces 506540701. Price: $59.99 |
| 30 |
115-0120-03 |
PEDAL-BRAKE Price: $158.58 |
| 30 |
586966601 |
BELT TENSIONER ASSY KIT This part replaces 506519501. Price: $59.99 |
| 31 |
125-8775 |
BUSHING-FLANGE Price: $1.09 |
| 31 |
506532701 |
PULLEY Price: $39.99 |
| 32 |
104-7179 |
PIVOT-PEDAL Price: $43.97 |
| 32 |
734116441 |
SPACER Price: $3.99 |
| 33 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 33 |
506558302 |
BOLT Price: $3.99 |
| 34 |
584288604 |
Washers This part replaces 506918702. Price: $3.99 |
| 34 |
99-7963-03 |
PEDAL-PARK Price: $26.63 |
| 35 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 35 |
725245171 |
SCREW Price: $2.08 |
| 36 |
115-0129 |
ROD-PAWL, BRAKE Price: $29.11 |
| 36 |
732211801 |
LOCKNUT M8 Price: $3.99 |
| 37 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 37 |
506533101 |
SPRING Price: $9.99 |
| 38 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 38 |
589530601 |
BELT Price: $54.99 |
| 39 |
544096103 |
BELT COVER C103 HUSQ - GREY This part replaces 544096101. Price: $74.99 |
| 39 |
99-7214 |
PAWL-BRAKE Price: $28.35 |
| 40 |
506982601 |
SCREW Price: $5.99 |
| 40 |
99-7140 |
SPRING-TORSION Price: $21.98 |
| 41 |
506559701 |
WASHER Price: $4.99 |
| 41 |
52-2891 |
BUSHING-FLANGED, NYLON Price: $3.19 |
| 42 |
323-12 |
SCREW-HH Price: $1.14 |
| 43 |
117-0238 |
DETENT Price: $11.85 |
| 44 |
5-0652 |
SPACER Price: $5.35 |
| 45 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 46 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 47 |
117-0106 |
CABLE-BRAKE, RH Price: $117.67 |
| 48 |
117-0107 |
CABLE-BRAKE, LH Price: $113.33 |
| 49 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 50 |
115-8060 |
CLEVIS-DOUBLE Price: $15.64 |
| 51 |
115-8059 |
YOKE-CABLE Price: $11.28 |
| 75 |
506789701 |
Decal Price: $21.55 |
| 76 |
544238103 |
DECAL Price: $4.99 |
