| Ref | Part Number | Description |
|---|
| 1 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 1 |
77-3440 |
SCREW Price: $2.84 |
| 1 |
925-04514 |
BATTERY Not Available This part replaces 725-3174. Price: |
| 2 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 2 |
725-3220 |
POITIVE BATTERY CABLE Not Available Price: |
| 2 |
77-3450 |
WASHER Price: $5.63 |
| 3 |
539110712 |
BAFFLE WLDMT, 52" R.H. MULCH Price: $169.99 |
| 3 |
725-3221 |
NEGATIVE BATTERY CABLE Not Available Price: |
| 3 |
77-3420 |
GASKET Price: $48.90 |
| 4 |
539110710 |
BAFFLE WLDMT, 52" L.H. Price: $119.99 |
| 4 |
710-3083 |
Screw, Hex Cap, 5/16-18 x 1.38 Lg Price: $3.94 |
| 4 |
77-3410 |
KEY Price: $1.91 |
| 5 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 5 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 5 |
77-3400 |
DISCONTINUED Price: Call Us |
| 6 |
539109757 |
BLADE MULCH 18" Price: $19.99 |
| 6 |
703-1823-0716 |
BATTERY HOLD DOWN (CUB YELLOW-99) Not Available This part replaces 703-1823. Price: |
| 6 |
94-3163 |
DISCONTINUED Price: Call Us |
| 7 |
731-3105 |
TRAY, BATTERY Not Available Price: |
| 7 |
94-3166 |
WASHER-PLATE Price: $2.69 |
| 8 |
759-3653 |
CAP-BATTERY VENT Not Available Price: |
| 9 |
729-0207 |
FUSE HOLDER Not Available Price: |
| 9 |
94-3162 |
STUD Price: $30.04 |
| 10 |
925-1381 |
Fuse, 20 Amp This part replaces 725-1381. Price: $5.38 |
| 10 |
94-3164 |
WASHER-SPRING Price: $1.20 |
| 11 |
729-0209 |
CLIP-FUSE HLD MTG Not Available Price: |
| 11 |
94-3159 |
TENSIONER Price: $141.40 |
| 12 |
710-0473 |
Screw, Truss Mach, #10-24 x .50 Lg Price: $3.90 |
| 12 |
94-3165 |
NUT-HEX Price: $2.34 |
| 13 |
77-3520 |
CUP Price: $14.17 |
| 13 |
925-1375 |
RELAY Not Available This part replaces 725-1375. Price: |
| 14 |
77-3510 |
SPRING Price: $11.34 |
| 15 |
736-0722 |
Washer, Lock, #10 Price: $5.81 |
| 15 |
94-3160 |
ROLLER Price: $159.20 |
| 16 |
712-0121 |
Nut, Hex, #10-24 Price: $3.75 |
| 16 |
94-3161 |
DISCONTINUED Price: Call Us |
| 17 |
710-3175 |
SCREW M8-1.25 x 14MM GR8.8 Not Available Price: |
| 17 |
94-3170 |
SCREW Price: $32.46 |
| 18 |
74-8830 |
BELT-TIMING Price: $104.36 |
| 19 |
94-3172 |
WASHER Price: $0.43 |
| 20 |
712-3077 |
HEX NUT M8X1.25 GR8.8 Not Available Price: |
| 20 |
94-3171 |
SCREW-HH Price: $3.39 |
| 21 |
94-3168 |
DISCONTINUED Price: Call Us |
| 22 |
94-3173 |
CAPSCREW Price: $3.29 |
| 23 |
710-0599 |
Screw, Hex Wash Hd TT, 1/4-20 x .50 Lg Price: $3.86 |
| 23 |
76-5010 |
WASHER-SPRING Price: $0.33 |
| 24 |
99-2570 |
DISCONTINUED This part replaces 94-3167. Price: Call Us |
| 25 |
94-3169 |
DISCONTINUED Price: Call Us |
| 539105571 |
BLADE |
NYKCG - 25" Price: $24.99 539105571 |
| 539109755 |
BLADE |
MULCH 21" Price: $22.99 539109755 |
| 539110715 |
BAFFLE |
WLDMT, 61" L.H. MULCH Price: $179.99 539110715 |
| 539110717 |
BAFFLE |
WLDMT 61" R.H. MULCH Price: $109.99 539110717 |
| 539110720 |
BAFFLE |
WLDMT, 72" L.H. MULCH Price: $89.99 539110720 |
| 539110722 |
BAFFLE |
WLDMT, 72" R.H. MULCH Price: $99.99 539110722 |
