| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 1 |
86-9370-03 |
PANEL-INSTUMENT This part replaces 86-9370. Price: $80.85 |
| 2 |
85-7470 |
DECAL Price: $25.56 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
233-35 |
KNOB Price: $8.06 |
| 4 |
218-533 |
LENS Price: $17.62 |
| 5 |
3219-14 |
NUT-HEX Price: $0.25 |
| 6 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 7 |
38-1670 |
MTNG BRKT W/38-1660 Price: $16.06 |
| 8 |
38-1650 |
FUEL GAUGE Price: $185.83 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
218-539 |
DISCONTINUED Price: Call Us |
| 10 |
83-0820 |
GAUGE - AMMETER This part replaces 38-1660. Price: $76.09 |
| 11 |
67-8550 |
DISCONTINUED Price: Call Us |
| 12 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 13 |
26-6740 |
TEMP RESET RELAY Price: $165.84 |
| 15 |
27-2360 |
SWITCH Price: $46.56 |
| 16 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 18 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 19 |
3217-6 |
NUT-HEX Price: $1.19 |
| 20 |
3255-5 |
WASHER-LOCK, EXT Price: $0.25 |
| 21 |
3217-26 |
NUT-HEX Price: $0.25 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
218-515 |
BRACKET Price: $12.11 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
63-7590 |
RELAY Price: $78.15 |
| 24 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
3290-134 |
SCREW Price: $0.27 |
| 25 |
532198893 |
CABLE.START.RED.17.5". Price: $11.99 |
| 26 |
3290-360 |
SCREW-HH Price: $4.34 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
22-7810 |
SPACER Price: $16.90 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
67-8560 |
CABLE-CONTROL, THROTTLE Price: $72.13 |
| 32 |
3255-24 |
WASHER-LOCK / EXT Price: $0.25 |
| 33 |
3217-29 |
NUT-HEX Price: $0.25 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
584452601 |
HARNESS.IGN.DASH.HUQ/PRED KIT This part replaces 532401105. Price: $49.99 |
| 41 |
596437001 |
Screws This part replaces 871720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532198138. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 59 |
596941001 |
Outlets This part replaces 532400303. Price: $11.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $4.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
