| Ref | Part Number | Description |
|---|
| 1 |
33106-030 |
SCREW-HHF Price: $1.15 |
| 2 |
100-3046 |
SHAFT-BRAKE, SPLINED Price: $192.79 |
| 3 |
136-2941 |
KIT-SERVICE, PLANETARY ASM This part replaces 105-4500-03. Price: $3,119.29 |
| 5 |
92-7483 |
NUT-LUG Price: $2.04 |
| 6 |
93-7972 |
RING-RETAINING, INTERNAL Price: $0.25 |
| 7 |
94-3050 |
PLATE-SPRING Price: $7.88 |
| 8 |
94-3088 |
SPRING-COMPRESSION Price: $8.24 |
| 9 |
3218-4 |
NUT-JAM Price: $0.49 |
| 10 |
100-3070 |
LH BRAKE ASM This part replaces 100-3070-03. Price: $802.37 |
| 11 |
33106-090 |
SCREW-HHF Price: $2.78 |
| 13 |
105-1218 |
PISTON MOTOR ASM Price: $2,247.58 |
| 14 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 15 |
33116-120 |
SCREW-HH Price: $1.70 |
| 16 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 17 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 18 |
237-166 |
O-RING Price: $10.46 |
| 19 |
100-3069 |
RH BRAKE ASM This part replaces 100-3069-03. Price: $802.37 |
| 21 |
104-3797 |
FITTING-STRAIGHT Price: $26.85 |
| 22 |
100-5530 |
FITTING-45 DEG Price: $109.81 |
| 23 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
