| Ref | Part Number | Description |
|---|
| 1 |
117-5135 |
RADIATOR This part replaces 99-3637. Price: $1,486.25 |
| 1 |
184432 |
Wire Asm Inner/Sprg W/plunger Price: Call Us |
| 2 |
112-1684 |
COOLER-OIL Price: $602.14 |
| 2 |
159476 |
Shaft Asm Lift RH w/Inf Price: Call Us |
| 3 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 3 |
138284 |
Pin Groove Price: Call Us |
| 4 |
104-5429 |
CLAMP-FORM, WIRE Price: $11.80 |
| 4 |
12000002 |
E Ring #5133-62 Price: Call Us |
| 5 |
19211621 |
Washer 21/32 X 1 X 21 Ga Price: Call Us |
| 5 |
325-17 |
SCREW-HH Price: $2.90 |
| 6 |
120183X |
Bearing Nylon Blk 629 Id Price: Call Us |
| 6 |
41-8440 |
WASHER Price: $1.49 |
| 7 |
175830 |
Grip Handle Price: Call Us |
| 7 |
32128-49 |
NUT-HHF Price: $1.04 |
| 8 |
104-7201 |
NUT-HF Price: $0.69 |
| 9 |
321-4 |
SCREW-HH Price: $0.99 |
| 10 |
240-4 |
GROMMET-RUBBER Price: $9.91 |
| 11 |
110-8277-03 |
FRAME-RADIATOR Price: $233.96 |
| 11 |
175370 |
Link Lift LH Price: Call Us |
| 12 |
175371 |
Link Lift RH Price: Call Us |
| 12 |
99-8551 |
PLUG-PIPE Price: $4.79 |
| 13 |
105-7281 |
HOSE-AIR INLET, UPPER Price: $108.48 |
| 13 |
4939M |
Retainer Spring Price: Call Us |
| 14 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 15 |
108-9930-0P |
BRACKET-BOTTLE This part replaces 108-9930-03. Price: $27.52 |
| 15 |
175562 |
Plate Asm. Suspension Front Price: Call Us |
| 16 |
108-0638 |
BOTTLE-OVERFLOW Price: $33.20 |
| 16 |
73350800 |
Nut Jam Hex 1/2-13 Unc Price: Call Us |
| 17 |
110-5542 |
HOSE-HYD Price: $119.39 |
| 17 |
175689 |
Trunnion Front Susp. Price: Call Us |
| 18 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 18 |
73800800 |
Nut Lock w/Wsh 1/2-13unc Price: Call Us |
| 19 |
323-10 |
SCREW-HH Price: $0.89 |
| 20 |
108-9935 |
STRIP-FOAM Price: $36.37 |
| 20 |
163552 |
Retainer Spring Price: Call Us |
| 21 |
33103-020 |
SCREW-HHF Price: $2.16 |
| 22 |
110-5543 |
HOSE-HYD Price: $136.82 |
| 23 |
108-3284 |
HOSE-FUEL Price: $13.53 |
| 23 |
110807X |
Nut Special Price: Call Us |
| 24 |
19131016 |
Washer 13/32 X 5/8 X 16 Ga Price: Call Us |
| 25 |
164024 |
Spring Price: Call Us |
| 25 |
2412-137 |
CLAMP-R, DOUBLE Price: $5.08 |
| 26 |
169484 |
Retainer Clip Price: Call Us |
| 26 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 27 |
108-9927 |
SHROUD-FAN Price: $123.47 |
| 27 |
164543 |
Rod Adj Lift Price: Call Us |
| 28 |
108-2872 |
COLLAR-FAN This part replaces 104-4247. Price: $21.29 |
| 28 |
73350600 |
Nut Hex Jam 3/8-16 Unc Price: Call Us |
| 29 |
107-2269 |
SEAL-BULB Price: $28.64 |
| 29 |
138057 |
Knob Inf 3/8-16 Unc Blk W/sym Price: Call Us |
| 30 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 30 |
150233 |
Trunnion Infin Height Price: Call Us |
| 31 |
104-4246 |
FAN-ENGINE This part replaces 107-9096. Price: $154.04 |
| 31 |
176205 |
Trunnion Susp. Arm Price: Call Us |
| 32 |
175994 |
Nut Lift Link 7/16-20 Price: Call Us |
| 32 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 34 |
105-7282 |
HOSE-RADIATOR, UPPER Price: $53.89 |
| 35 |
105-7283 |
HOSE-RADIATOR, LOWER Price: $34.82 |
| 36 |
109-0274 |
HOSE-FUEL Price: $12.99 |
| 36 |
155097 |
Pointer Height Indicator Price: Call Us |
| 37 |
106-6755 |
DECAL-CAP, RADIATOR Price: $18.49 |
| 37 |
123935X |
Plug Hole Blk 1.485/1.515 Dia. Price: Call Us |
| 38 |
17060516 |
Screw 5/16-18 x 1 Price: Call Us |
| 38 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 40 |
19112410 |
Washer 11/32 x 1-1/2 10 Ga. Price: Call Us |
| 41 |
155098 |
Indicator Height STLT Price: Call Us |
| 49 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 50 |
110452X |
Nut PUsh Phos & Oil Price: Call Us |
| 51 |
19171416 |
Washer 17/32 x 7/8 x 16 Ga. Price: Call Us |
| 52 |
175378 |
Arm Susp. Rear LH Price: Call Us |
| 53 |
175802 |
Arm Susp. Rear RH Price: Call Us |
