| Ref | Part Number | Description |
|---|
| 1 |
131-1234 |
FRONT DECK ASM Price: $2,948.39 |
| 2 |
32120-72 |
RING-SNAP Price: $2.09 |
| 3 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 4 |
132-9421 |
PULLEY-IDLER, FLAT Price: $41.10 |
| 5 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 6 |
110-6128 |
IDLER ARM ASM Price: Call Us |
| 7 |
139-1037 |
DOUBLE DRIVEN SPINDLE ASM This part replaces 119-4548. Price: $724.15 |
| 8 |
108-8076 |
V-BELT, DECK Price: $29.86 |
| 9 |
139-1038 |
HIGH DRIVEN SPINDLE ASM This part replaces 119-4549. Price: $691.39 |
| 10 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 11 |
131-1237 |
PLATE-SPINDLE, FRONT-CENTER Price: $93.58 |
| 12 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 13 |
131-1238 |
PLATE-SPINDLE, FRONT-RIGHT Price: $76.58 |
| 14 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 15 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 16 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 17 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 19 |
920242 |
WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 20 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 21 |
325-7 |
SCREW-HH Price: $1.53 |
| 22 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 23 |
139-1728 |
BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 24 |
32128-14 |
NUT-HF Price: $0.41 |
| 25 |
68-0090 |
SCREW-ADJUSTING Price: $7.49 |
| 26 |
107938 |
SPRING-EXTENSION Price: $9.99 |
| 27 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 28 |
70-1160 |
WASHER Price: $3.59 |
| 33 |
131-1239 |
PLATE-SPINDLE, FRONT-LEFT Price: $76.58 |
