| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT Price: $273.15 |
| 2 |
100-4928 |
BELT-SEAT Price: $280.73 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
92-8990 |
ADJUSTER-SLAVE Price: $54.82 |
| 6 |
92-8991 |
ADJUSTER (W/LATCH) Price: $73.04 |
| 7 |
3212-4 |
SCREW-HH Price: $2.73 |
| 8 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 9 |
92-6282 |
SWITCH-SEAT Price: $31.99 |
| 10 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 11 |
104-0467-03 |
STRAP-SUPPORT, SEAT Price: $165.70 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 12 |
95-8896 |
FOAM Price: $32.41 |
| 13 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
104-0466 |
SPACER-TUBE Price: $27.25 |
| 15 |
323-14 |
SCREW-HH Price: $1.34 |
| 15 |
532179115 |
TANK.FUEL.5.0 LEFT.FILL.YTGT Price: $89.99 |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 17 |
104-4833-03 |
SHIELD-HEAT Price: $72.12 |
| 18 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 18 |
92-7307 |
LH ARMREST ASM Price: $200.08 |
| 19 |
92-7306 |
RH ARMREST ASM Price: $198.41 |
| 20 |
532178147 |
CONTROL.THROTTLE.COBRA.42"BLK. Price: $29.99 |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 22 |
532175441 |
CHOKE CONTROL This part replaces 532178148. Price: $24.99 |
| 24 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 25 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 28 |
532008542 |
FUEL LINE 42" This part replaces 532007834. Price: $5.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 35 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 unc Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 62 |
532176252 |
HEAT SHIELD Price: $5.59 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 70 |
532175766 |
TUBE EXHAUST LH Price: $48.99 |
| 71 |
532175767 |
TUBE.EXHAUST.KAWASAKI.RH Price: $54.99 |
| 80 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
