| Ref | Part Number | Description |
|---|
| 1 |
119-6702-03 |
FRAME-SUNSHADE Price: $497.25 |
| 1 |
532100710 |
Insert, Wheel, Steering (AYP part number) Price: $10.20 |
| 2 |
119-6744 |
RH ROPS MOUNTING BRACKET ASM Price: $159.37 |
| 2 |
532124701 |
Nut, Lock 3/8-24 UNF (AYP part number) Price: $5.99 |
| 3 |
119-6745 |
LH ROPS MOUNTING BRACKET ASM Price: $94.75 |
| 3 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133808. Price: $3.99 |
| 4 |
130-5635 |
SUNSHADE ASM Price: $1,057.55 |
| 4 |
532100713 |
Wheel, Steering (AYP part number) Price: $64.99 |
| 5 |
109-5013 |
PANHARD ROD ASM Price: $135.99 |
| 5 |
532121897 |
Sleeve, Steering (AYP part number) Price: $8.99 |
| 6 |
817211008 |
Screw, Hex Wsh. Tap #10-16 x 1/2 (AYP part number) This part replaces 817431008. Price: $2.99 |
| 6 |
86-1990 |
WASHER-THRUST Price: $1.81 |
| 7 |
325-10 |
SCREW-HH Price: $1.82 |
| 7 |
532155107 |
STEERING BUSHING KIT This part replaces 532102803. Price: $3.99 |
| 8 |
532148966 |
SHAFT STEERING This part replaces 532123651. Price: $109.99 |
| 8 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 9 |
115-7721 |
NUT-CLIP, U Price: $0.81 |
| 9 |
532124210 |
Clip, Steering (AYP part number) Price: $3.99 |
| 10 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 10 |
532123438 |
Bushing, Lower, Steering (AYP part number) Price: $3.99 |
| 11 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 11 |
812000045 |
Ring, Retaining (AYP part number) Price: $3.99 |
| 12 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 12 |
819211616 |
Washer 21/32 x 1 x 16 Ga. (AYP part number) Price: $3.99 |
| 13 |
119-6732-03 |
BRACKET-MOUNTING, ROPS Price: $21.47 |
| 13 |
532104820 |
Adaptor, Wheel, Steering (AYP part number) Price: $9.99 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
119-6727 |
U-BOLT Price: $6.58 |
| 17 |
328-7 |
SCREW-HH Price: $4.00 |
| 18 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 19 |
3256-28 |
WASHER-FLAT Price: $0.48 |
