| Ref | Part Number | Description |
|---|
| 1 |
931-04031 |
FENDER COVER (LH) Not Available This part replaces 631-04031. Price: |
| 1 |
95-7508 |
SUPPORT-AXLE Price: $931.33 |
| 2 |
583515001 |
DECK.LIFT.WELDMENT This part replaces 532436996. Price: $49.99 |
| 2 |
931-04032 |
FENDER COVER (RH) Not Available This part replaces 631-04032. Price: |
| 2 |
95-7506 |
SUPPORT-AXLE Price: $360.26 |
| 3 |
106-1067 |
O-RING This part replaces 95-7507. Price: $18.12 |
| 3 |
594018001 |
Levers This part replaces 532195231. Price: $17.99 |
| 3 |
703-05105-0637 |
RUNNING BOARD BRACKET (RH)(POWDER BLACK) Not Available Price: |
| 4 |
703-05113-0637 |
RUNNING BOARD BRACKET (LH)(POWDER BLACK) Not Available Price: |
| 4 |
95-7537 |
BUSHING-FLANGED Price: $64.20 |
| 5 |
703-05199-0716 |
RUNNING BOARD (CUB YELLOW-99) Not Available Price: |
| 5 |
99-7589 |
PLUG Price: $3.73 |
| 6 |
703-05306 |
GATE-LIFT Not Available Price: |
| 6 |
99-7590 |
WASHER-SEAL Price: $2.94 |
| 7 |
110-4812 |
AXLE VENT ASM This part replaces 99-7591. Price: $11.06 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK Price: $7.99 |
| 7 |
703-05307-0637 |
HI LO SHIFT GATE (POWDER BLACK) Not Available This part replaces 703-05307. Price: |
| 8 |
710-0602 |
Screw, Hex Wash. Hd. Tapp 5/16-18 x 1.0 Price: $4.05 |
| 8 |
99-7592 |
BOLT Price: $1.44 |
| 9 |
710-0895 |
Screw, Hex Wash. Hd, Tapp 1/4-15 x .75 Price: $5.82 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 10 |
710-1242 |
Screw, Truss Phillips Hd. 5/16-14 x .75 Price: $3.95 |
| 11 |
710-1260A |
Screw, Hex Wash. Hd. Tapp 5/16-18 x .75 Price: $3.34 |
| 12 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .5 GR5 Price: $4.02 |
| 13 |
712-0324 |
Nut, Hex Insert Lock, 1/4-20 GR8 Price: $3.38 |
| 14 |
925-04070 |
PTO REVERSE SWITCH Not Available This part replaces 725-04070. Price: |
| 15 |
726-0211 |
Nut, Speed, 5/16-18 Price: $3.90 |
| 16 |
931-05089 |
FENDER This part replaces 731-04025. Price: $683.04 |
| 17 |
735-0275 |
Pad, Floor - LH Price: $52.11 |
| 18 |
735-0276 |
FOOT PAD (RH) Not Available Price: |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 532195181. Price: $14.99 |
| 97 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 98 |
581506903 |
Links This part replaces 532195270. Price: $9.99 |
| 100 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 101 |
532407003 |
LINK.ASM.LIFT.FIXE.38/42/46" Price: $11.99 |
| 777D07564 |
LABEL-REAR |
REFLECTOR Not Available Price: 777D07564 |
| 777D07729 |
LABEL-REAR |
FENDER Not Available Price: 777D07729 |
| 777S32274 |
LABEL-WARNING |
Not Available Price: 777S32274 |
| 777S32286 |
LABEL-ROPS |
WARNING Not Available Price: 777S32286 |
| 777S32332 |
LABEL-START |
INSTR Not Available Price: 777S32332 |
