| Ref | Part Number | Description |
|---|
| 1 |
142671 |
HOUSING UPPER TRN Price: Call Us |
| 1 |
951-10337 |
FUEL TANK Not Available Price: |
| 2 |
104-3446 |
HOSE-OUTLET, AIR Price: $148.73 |
| 2 |
2274J |
SUB= 74760412 Price: Call Us |
| 2 |
951-10875 |
Flywheel Shroud Not Available Price: |
| 3 |
134400 |
SUB= 68003 Price: Call Us |
| 3 |
3210-5 |
SCREW-HH Price: $0.54 |
| 3 |
951-10335 |
Rubber Fuel Tank Mounting Washer Price: $4.90 |
| 4 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 4 |
951-10334 |
Oil Filler Tube Assembly Price: $20.69 |
| 5 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 5 |
951-10333 |
Dipstick Assembly Price: $15.70 |
| 6 |
138235 |
KIT SHIFTER ASM Price: Call Us |
| 6 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 6 |
951-10877A |
CYLINDER HEAD ASSEMBLY Not Available This part replaces 951-10877. Price: |
| 7 |
134399 |
SHIFTER BOOT Price: Call Us |
| 7 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 7 |
951-11789 |
SHORTBLOCK ASSEMBLY Not Available This part replaces 951-10878. Price: |
| 8 |
3210-8 |
SCREW-HH Price: $1.02 |
| 8 |
73810500 |
NUT.LOCK.5/16-24 Price: Call Us |
| 8 |
951-10320A |
Stop Switch and Brake Ass'y This part replaces 951-10320. Price: $34.99 |
| 9 |
143045 |
SEAL OIL DANA5416 Price: Call Us |
| 9 |
32152-5 |
NUT-HEX Price: $0.54 |
| 9 |
951-10319 |
Recoil Spring and Pulley Assembly Price: $44.50 |
| 10 |
142672 |
SUB= 2225J Price: Call Us |
| 10 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 10 |
951-10314 |
Push Rod Kit Price: $15.70 |
| 11 |
104-3444 |
HOSE-INLET, AIR Price: $147.47 |
| 11 |
134793 |
ASM KIT SHIM 4689 Price: Call Us |
| 11 |
951-10313 |
Valve Kit Price: $57.10 |
| 12 |
143051 |
SUB= 148268 Price: Call Us |
| 12 |
322-6 |
SCREW-HH Price: $0.45 |
| 12 |
951-10370 |
Oil Drain Plug and Washer Assembly Price: $7.96 |
| 13 |
120415X |
WASHER T Price: Call Us |
| 13 |
136-4480 |
AIR CLEANER ASM This part replaces 104-3427. Price: $287.47 |
| 13 |
951-10367 |
Ignition Coil Price: $95.86 |
| 14 |
142674 |
KEY WOODRUFF-DANA Price: Call Us |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
951-10873 |
Carburetor Assembly Price: $83.93 |
| 15 |
138234 |
AS KIT INPUT SHFT Price: Call Us |
| 15 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 15 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 16 |
110078X |
PINION 14T T Price: Call Us |
| 16 |
27-6590 |
SPACER-COUPLING, RUBBER Price: $13.38 |
| 16 |
951-10876 |
Air Cleaner Housing Assembly Complete Price: $36.07 |
| 17 |
27-4370 |
HUB-PUMP Price: $70.04 |
| 17 |
710-05093 |
Carb Stud M6x92 This part replaces 951-10304. Price: $3.65 |
| 18 |
3241-6 |
SCREW-SQH Price: $4.80 |
| 18 |
951-10363 |
Fuel Line Kit - Inc. hoses, clamps & filter Price: $25.25 |
| 19 |
104-3401-03 |
DRIVE SHAFT ASM Price: $64.08 |
| 19 |
105911X |
BEARING.FLNG.5510 Price: Call Us |
| 19 |
951-12296A |
FUEL FILTER This part replaces 951-10358. Price: $8.68 |
| 20 |
142675 |
GEAR SPUR 14 TTH Price: Call Us |
| 20 |
951-10300 |
Fuel Cap Assembly Price: $10.24 |
| 20 |
99-3441 |
HARNESS-WIRE, FUSIBLE LINK Price: $146.90 |
| 21 |
138246 |
COLLAR CLUTCH Price: Call Us |
| 21 |
951-10299A |
Recoil Starter This part replaces 951-10299. Price: $60.89 |
| 22 |
138236 |
ASM KIT CLTCH KEY Price: Call Us |
| 22 |
951-10298 |
Air Cleaner Kit Price: $15.94 |
| 23 |
134791 |
SCREW TAP W/SEAL Price: Call Us |
| 23 |
951-10297 |
Air Cleaner Thumb Screw Price: $5.34 |
| 24 |
142676 |
SHAFT INTERM DANA Price: Call Us |
| 24 |
951-10404 |
MUFFLER GUARD Not Available Price: |
| 25 |
2244J |
WOODRUFF KEY Price: Call Us |
| 25 |
951-10403 |
Muffler Price: $72.42 |
| 26 |
951-10402 |
Muffler Gasket /Heat Shield Price: $16.75 |
| 27 |
120470X |
SPROCKET 18T T Price: Call Us |
| 27 |
951-10387 |
Governor Return Spring Price: $6.54 |
| 28 |
110070X |
SPACER YT Price: Call Us |
| 28 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 29 |
142677 |
GEAR SPUR 37 TTH Price: Call Us |
| 29 |
951-10351A |
SPARK ARRESTOR This part replaces 951-10351. Price: $48.91 |
| 30 |
120405X |
SUB= 124644X Price: Call Us |
| 31 |
108980X |
GEAR 25T LT Price: Call Us |
| 32 |
134796 |
SPUR GEAR 19T Price: Call Us |
| 33 |
138239 |
SPACER Price: Call Us |
| 36 |
2232J |
WASHER 025 Price: Call Us |
| 37 |
108978X |
SPACER Price: Call Us |
| 38 |
110079X |
ASSM GEAR COMB Price: Call Us |
| 39 |
124639X |
SHAFT IDLER Price: Call Us |
| 40 |
120472X |
SPACER T Price: Call Us |
| 41 |
105928X |
SPROCKET 9T LT Price: Call Us |
| 42 |
110084X |
SUB= 167148 Price: Call Us |
| 43 |
134394 |
ASM KIT SHIM Price: Call Us |
| 44 |
120473X |
SHAFT T Price: Call Us |
| 45 |
142678 |
GEAR SPUR 12 TTH Price: Call Us |
| 46 |
120407X |
SUB= 124641X Price: Call Us |
| 49 |
120523X |
SPACER T Price: Call Us |
| 50 |
120951X |
PUCK T Price: Call Us |
| 51 |
2226J |
WASHER 060 Price: Call Us |
| 52 |
134401 |
NEOPRENE WASHER Price: Call Us |
| 53 |
2264J |
WASHER 031 Price: Call Us |
| 54 |
120474X |
SUB= 154658 Price: Call Us |
| 55 |
110081X |
GEAR 15T T Price: Call Us |
| 57 |
110071X |
SUB= 120478X Price: Call Us |
| 58 |
120952X |
SHAFT T Price: Call Us |
| 59 |
110082X |
GEAR 1ST T Price: Call Us |
| 60 |
120475X |
SUB= 154659 Price: Call Us |
| 61 |
142680 |
HOUSING LOWER TNS Price: Call Us |
| 62 |
120961X |
PUCK T Price: Call Us |
| 63 |
7294J |
BRAKE DISC. T Price: Call Us |
| 64 |
108989X |
SPACER LT Price: Call Us |
| 65 |
120953X |
SUB= 918120953X Price: Call Us |
| 66 |
120954X |
PIN T Price: Call Us |
| 67 |
134799 |
TAP SCREW Price: Call Us |
| 68 |
138244 |
SUB= 108992X Price: Call Us |
| 69 |
108996X |
WASHER LT Price: Call Us |
| 70 |
120956X |
NLA Price: Call Us |
