| Ref | Part Number | Description |
|---|
| 1 |
532086902 |
CONTROL BAR Price: $5.99 |
| 2 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532132001. Price: $7.99 |
| 3 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 4 |
532125463 |
HANDLE Price: $46.99 |
| 5 |
532125078 |
WASHER.ENGINE.BZP This part replaces 532213146. Price: $4.99 |
| 6 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 7 |
532125464 |
HANDLE.UPPER.ECONOMY.BLACK. Price: $38.99 |
| 8 |
532130861 |
CABLE.MZR.51.RT.SP./PU. This part replaces 532851809. Price: $10.99 |
| 9 |
874780424 |
Bolt Hex Fin 1/4-20 x 1-1/2 This part replaces 874350424. Price: $3.99 |
| 10 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 11 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 12 |
532137009 |
NEEDS DESCRIPTION Price: Call Us |
| 14 |
532189009 |
SKIRT.20RD/SD.FO/VE.BO WHEELS This part replaces 532140541. Price: $12.99 |
| 15 |
817021008 |
SCREW This part replaces 532085825. Price: $3.99 |
| 16 |
532069180 |
LOCKNUT Price: $2.99 |
| 17 |
532125078 |
WASHER.ENGINE.BZP Price: $4.99 |
| 19 |
532752052 |
PROTECTOR Price: $15.99 |
| 20 |
532067609 |
AXLE BOLT Price: $7.99 |
| 21 |
532436482 |
WHEEL.7X1.5.DMD.3SPK.GREY This part replaces 532800060. Price: $11.99 |
| 22 |
532136624 |
SPACER.WHEEL.390.X1.0X.380.RTA Price: $7.99 |
| 23 |
532145494 |
DECAL MOWER CUT/FINGER Price: $8.99 |
| 24 |
532055611 |
WASHER Price: $3.99 |
| 25 |
532154147 |
PROTECTOR Price: $22.99 |
| 27 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532132010. Price: $3.99 |
| 28 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 30 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 33 |
532162226 |
HOUSING Price: $214.99 |
| 34 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $14.99 |
| 35 |
531006063 |
BLADE Price: $30.99 |
| 36 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 37 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 38 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 40 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
| 41 |
532131922 |
CONTROL.THROTTLE.B&S.WALK Price: $17.99 |
| 42 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $4.99 |
| 44 |
532192301 |
BRACKET.SKIRT.BZP This part replaces 532125207. Price: $4.99 |
| 45 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 46 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 47 |
532087930 |
GUIDE CLIP PM Price: $5.99 |
| 48 |
532128416 |
NEEDS DESCRIPTION Price: Call Us |
| 49 |
532162234 |
BRACKET Price: $22.99 |
