| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144925. Price: $149.99 |
| 1 |
751-3006 |
FUEL TANK Not Available Price: |
| 2 |
237-80 |
O-RING Price: $6.10 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 2 |
935-0149 |
Fuel Tank Bushing This part replaces 751-3008. Price: $2.43 |
| 3 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 3 |
951-0171 |
Fuel Shut-Off Valve with Screen This part replaces 751-0171. Price: $18.13 |
| 4 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 4 |
951-0226A |
Gas Tank Cap This part replaces 751-0226. Price: $50.20 |
| 5 |
703-0057 |
CLAMP-GAS TANK Not Available Price: |
| 6 |
218-591 |
COIL ASM Price: $291.02 |
| 6 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 6 |
735-3004 |
PAD STRIP-GAS TANK Not Available Price: |
| 7 |
726-0205 |
Clamp, Hose Price: $3.71 |
| 8 |
532404349 |
KIT.BOX.BATTERY.REAR.BOOT.POS This part replaces 532156417. Price: $24.99 |
| 9 |
703-0049 |
Support, Fuel Tank Price: Call Us |
| 10 |
703-0052 |
SUPPORT-BOTTOM Not Available Price: |
| 11 |
703-0055 |
DEFLECTOR, HEAT Not Available Price: |
| 12 |
735-3003 |
GROMMET Not Available Price: |
| 13 |
723-3004 |
Seal, Heat Baffle, 56 in. Lg Price: $80.66 |
| 14 |
723-3009 |
STRIP-FOAM 27 IN.LONG Not Available Price: |
| 15 |
723-3010 |
FOAM STRIP 17" Not Available Price: |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN This part replaces 532153664. Price: $19.99 |
| 19 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810090400. Price: $2.99 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $2.99 |
| 21 |
532136850 |
HARNESS LIGHT SOCKET Price: $15.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 25 |
532146147 |
CABLE BATTERY Price: $22.99 |
| 26 |
532108824 |
FUSE HYT Price: $4.99 |
| 28 |
532004207 |
CABLE T This part replaces 532124773. Price: $4.99 |
| 29 |
532160784 |
PLUNGER SWITCH (COLOR:OLIVE) Price: $17.99 |
| 30 |
532140301 |
SWITCH.IGNITION.4.POSITION Price: $32.99 |
| 31 |
532124211 |
NUT IGNITION Price: $4.99 |
| 32 |
532141226 |
COVER SWITCH KEY Price: $4.99 |
| 33 |
532122147 |
KEY.MOLDED.GENERIC Price: $5.99 |
| 40 |
532160720 |
HARNESS.IGNITION Price: $119.99 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $19.99 |
| 44 |
873640400 |
Nut Keps Hex 1/4-20 Unc Price: $2.99 |
| 48 |
532140844 |
ADAPTER.AMMETER Price: $4.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532154959. Price: $24.99 |
| 51 |
532140405 |
FRAME RETAINING RING Price: $3.99 |
| 52 |
532141940 |
WIRE PROTECTION LOOP Price: $4.99 |
| 70 |
532140426 |
HARNESS, ENGINE NLA Price: $7.99 |
| 80 |
532146685 |
HARNESS, CLUTCH Price: $11.99 |
