| Ref | Part Number | Description |
|---|
| 1 |
133-8095 |
DECAL-CE This part replaces 93-7252. Price: $3.73 |
| 1 |
532196498 |
KIT.SVC.DECK.WLD.54" This part replaces 532188920. Price: $409.99 |
| 2 |
62-5550 |
DECAL Price: $9.32 |
| 3 |
69-8510-01 |
COVER-TOWER, STEERING Price: $72.13 |
| 4 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 5 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 5 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 6 |
532187297 |
Cover Mandrel LH Price: $22.99 |
| 6 |
95-1821 |
SPRING-COMPRESSION This part replaces 95-1821-03. Price: $6.71 |
| 7 |
233-17 |
KNOB Price: $10.58 |
| 7 |
532188187 |
Cover Mandrel RH Price: $22.99 |
| 8 |
106-0483 |
STEERING TOWER PANEL ASM Price: $50.25 |
| 8 |
532193003 |
BOLT, BLADE This part replaces 532174365. Price: $5.99 |
| 9 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 10 |
98-1471 |
WHEEL-STEERING Price: $145.99 |
| 11 |
107-2562 |
NUT-HEX Price: $19.95 |
| 13 |
44-2212 |
AMBER INDICATOR LIGHT ASM Price: $72.17 |
| 13 |
532187291 |
Shaft Asm. w/Lower Bearing Price: $17.99 |
| 14 |
532187281 |
Mandrel Housing Price: $20.99 |
| 15 |
32144-64 |
TSCREW-HWH Price: $5.77 |
| 15 |
532110485 |
Bearing, Ball, Mandrel Price: $7.99 |
| 16 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 17 |
33115-030 |
SCREW-HH Price: $0.68 |
| 18 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 18 |
872140505 |
Bolt Rdhd Sqnk 5/16-18 x 5/8 Price: $2.69 |
| 19 |
106-0293-03 |
BRACKET-GEAR, STEERING Price: $59.65 |
| 20 |
31-0390 |
DISC-FRICTION Price: $11.25 |
| 21 |
20-9500 |
WASHER Price: $3.53 |
| 21 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 22 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 23 |
69-7740-03 |
STEERING GEAR SUPPORT ASM Price: $53.33 |
| 24 |
32128-20 |
NUT-HF Price: $0.99 |
| 25 |
539107609 |
SPRING.TORSION This part replaces 532178102. Price: $1.99 |
| 25 |
69-7760-03 |
STEERING GEAR LINK ASM Price: $49.96 |
| 26 |
106-0271 |
COLUMN-STEERING Price: $303.84 |
| 26 |
532110452 |
Nut, Push Price: $1.99 |
| 27 |
130-7942 |
VALVE-STEERING,CONTROL This part replaces 108-1520. Price: $1,254.29 |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $50.99 |
| 28 |
340-1 |
FITTING-STRAIGHT Price: $10.19 |
| 29 |
532131491 |
Rod, Hinge Price: $1.99 |
| 30 |
32128-23 |
NUT-HF Price: $1.51 |
| 30 |
532173984 |
Screw Thd Roll Price: $2.99 |
| 31 |
532187690 |
Washer, Spacer Mower Vented Price: $1.99 |
| 31 |
69-5500 |
HOSE ASM Price: $95.30 |
| 32 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 32 |
532173436 |
Pulley, Mandrel Price: $7.99 |
| 33 |
28-0380 |
SPACER-AXLE, FRONT Price: $2.37 |
| 33 |
532400234 |
NUT, LOCK This part replaces 532178342. Price: $3.99 |
| 34 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 34 |
873680600 |
Nut Price: $1.99 |
| 35 |
325-5 |
SCREW-HH Price: $1.20 |
| 35 |
532188635 |
Pin Suspension Rear Price: $14.99 |
| 36 |
46-1600 |
SPACER Price: $4.40 |
| 36 |
819131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: $2.99 |
| 37 |
106-0331-03 |
ROD-LATCH, BRAKE Price: $100.63 |
| 38 |
532188657 |
Spring Compression Price: $3.99 |
| 38 |
69-8160-01 |
STEERING TOWER ASM Price: $377.45 |
| 39 |
532187284 |
Pulley, Idler, Stationary Price: $28.99 |
| 39 |
69-9230 |
SHAFT-PIVOT, STEERING Price: $63.94 |
| 40 |
69-1560-03 |
DISCONTINUED Price: Call Us |
| 41 |
98-1459 |
DECAL Price: $3.93 |
| 42 |
532165723 |
Spacer Retainer This part replaces 532122052. Price: $2.99 |
| 43 |
532196216 |
Arm, Idler This part replaces 532187278. Price: $101.99 |
| 46 |
532137729 |
Screw, Thdroll. 1/4-20 x 5/8 Price: $2.49 |
| 47 |
532191273 |
V-Belt, Mower, Secondary Price: $55.99 |
| 49 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 50 |
872110616 |
Bolt, Carr. 3/8-16 x 2 Price: $3.99 |
| 51 |
872140614 |
BOLT This part replaces 872110610. Price: $2.99 |
| 52 |
532188460 |
Pulley Idler clutching Price: $31.99 |
| 56 |
532155986 |
Bar Pnt Adj. Price: $5.99 |
| 57 |
532156941 |
Pin Head Rivet Price: $2.99 |
| 58 |
532187342 |
Baffle Right Price: $12.99 |
| 59 |
532187344 |
Baffle Left Price: $14.99 |
| 60 |
532187607 |
Baffle Center Price: $17.99 |
| 97 |
532413524 |
WASHER.13/32 X 1 X 1/2.11GUARD This part replaces 819133210. Price: $2.99 |
| 98 |
532187282 |
Spring Clutch Drive Price: $9.99 |
| 113 |
872110508 |
Bolt Rdhd Sqnk 5/16-18 unc x 3/4 Price: $2.99 |
| 114 |
532187556 |
Rod Tension Relief Price: $12.99 |
| 116 |
532193406 |
Bolt, Shoulder Price: $1.99 |
| 117 |
532174873 |
Gauge Wheel Price: $7.99 |
| 118 |
873680600 |
Nut This part replaces 873930600. Price: $1.99 |
| 119 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 122 |
532187557 |
Bushing Tension Relief Price: $2.99 |
