| Ref | Part Number | Description |
|---|
| 1 |
481477 |
Grip, Deck Latch Price: Call Us |
| 2 |
462253 |
Deck Latch Assembly w/Grip Price: Call Us |
| 3 |
43668 |
Spacer, Deck Latch Price: Call Us |
| 4 |
484191 |
Spring, Torsion Return Lever Price: Call Us |
| 5 |
483345 |
Ring Pin Assembly w/Lanyard Price: Call Us |
| 6 |
425574 |
Adjustment Bracket, Upper Cut Height Price: Call Us |
| 7 |
452408 |
Adjustment Bracket, Lower Cut Height Price: Call Us |
| 8 |
485570 |
Slide, Height Adjustment Price: Call Us |
| 9 |
43487 |
Pin, Deck Lift Price: Call Us |
| 10 |
04050-10 |
Retaining Ring, 1/2" External "E" Price: Call Us |
| 11 |
04020-27 |
Nut, 1/2-20 UNF Jam Price: Call Us |
| 11 |
04020-28 |
Nut, 1/2-20 UNF LH Jam Price: Call Us |
| 11 |
481765 |
Rod End, 1/2-20 RH Female Price: Call Us |
| 11 |
481766 |
Rod End, 1/2-20 LH Female Price: Call Us |
| 11 |
484141 |
Linkage, Deck Lift Price: Call Us |
| 12 |
04001-72 |
Bolt, Hex Head 1/2-13 x 2" Price: Call Us |
| 13 |
04040-07 |
Flatwasher, 1/2-.531 X 1.062 X .095 Price: Call Us |
| 14 |
04001-09 |
Bolt, Hex Head 5/16-18 x 1" Price: Call Us |
| 14 |
04030-03 |
Lockwasher, 5/16" Spring Price: Call Us |
| 15 |
04108-04 |
Capscrew, 5/8-11 x 1-1/2" This part replaces 04105-01. Price: Call Us |
| 16 |
04030-07 |
Lockwasher, 5/8" Spring Price: Call Us |
| 17 |
04019-03 |
Nut, Serrated Flange 5/16-18 Price: Call Us |
| 18 |
04019-04 |
Nut, Serrated Flange 3/8-16 Price: Call Us |
| 19 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 20 |
04001-22 |
Bolt, Hex Head 3/8-16 x 2-3/4" Price: Call Us |
| 21 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Price: Call Us |
| 22 |
04021-07 |
Nut, Elastic Stop 1/2-13 Price: Call Us |
| 23 |
481598 |
Spring, Deck Lift Price: Call Us |
| 24 |
424504 |
Pedal, Foot Lift Price: Call Us |
| 25 |
04004-44 |
Stud, 5/8-11 x 22" Price: Call Us |
| 26 |
43526 |
Swivel Joint, LH Price: Call Us |
| 27 |
43527 |
Swivel Joint, RH Price: Call Us |
| 28 |
04020-09 |
Nut, 5/8-11 UNC Price: Call Us |
| 29 |
04019-04 |
Nut, Serrated Flange 3/8-16 Price: Call Us |
| 30 |
48540 |
Chain Price: Call Us |
| 31 |
48114-04 |
Grease Fitting, 1/4-28 Self Tap Price: Call Us |
| 32 |
04040-09 |
Flatwasher, 5/8" Price: Call Us |
| 33 |
04061-07 |
Cotter Pin, 3/16 x 1" Price: Call Us |
| 34 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 35 |
04003-40 |
Bolt, Carriage 7/16-14 x 1-1/4" Price: Call Us |
| 36 |
04040-11 |
Flatwasher, 7/16-.500 x 1.25 x .083 Price: Call Us |
| 37 |
04021-11 |
Nut, Elastic Stop 7/16-14 Price: Call Us |
