| Ref | Part Number | Description |
|---|
| 1 |
186093X428 |
Wheel, Steering Price: Call Us |
| 1 |
95-7522 |
AXLE Price: $377.20 |
| 2 |
195968 |
Axle Asm. Front Price: Call Us |
| 2 |
99-7564 |
SEAL-OIL Price: $25.36 |
| 3 |
95-7544 |
CLIP Price: $4.04 |
| 4 |
403089 |
Spindle Asm. LH Price: Call Us |
| 4 |
95-7523 |
SPACER Price: $26.89 |
| 5 |
403090 |
Spindle Asm. RH Price: Call Us |
| 5 |
99-7555 |
SHIM 0.3 Price: $3.29 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 6 |
95-7525 |
GEAR-BEVEL, 27 TOOTH Price: $333.09 |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
99-7534 |
BEARING-BALL Price: $65.44 |
| 8 |
12000029 |
Ring, Clip #T5304-75 Price: Call Us |
| 8 |
95-7521 |
COVER-AXLE Price: $107.87 |
| 9 |
106-1071 |
O-RING This part replaces 99-7538. Price: $18.43 |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 10 |
93-7775 |
BEARING-BALL This part replaces 99-7561. Price: $127.75 |
| 11 |
99-7539 |
CLIP Price: $11.07 |
| 12 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 16 |
408219 |
Shaft Steering Price: Call Us |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 20 |
195626X428 |
Boot, Steering Price: Call Us |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 22 |
194845 |
Bushing, Strg. Blk. Price: Call Us |
| 26 |
186095X428 |
Insert, Wheel Steering Price: Call Us |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 45 |
19113812 |
Washer 11/32 ID x 2-3/8 OD x 12 Ga. Price: Call Us |
| 50 |
73900600 |
Nut Lock 3/8-16 unc Price: Call Us |
| 51 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x .060 Price: Call Us |
| 54 |
74760636 |
Bolt Hex 3/8-16 unc x 2-1/4 Price: Call Us |
| 55 |
197636 |
Spacer Brace Axle Price: Call Us |
| 57 |
197246 |
Bracket Upstop Price: Call Us |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 63 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 66 |
71020748 |
Bolt Hex Fghd. 7/16-14 x 3 Serr. Price: Call Us |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
| 70 |
196197 |
Bracket Deck Susp. Front Price: Call Us |
