| Ref | Part Number | Description |
|---|
| 1 |
296561 |
Cylinder Assembly Price: Call Us |
| 2 |
293708 |
Bushing Price: Call Us |
| 3 |
89660 |
Seal-Oil Price: Call Us |
| 5 |
210812 |
Head-Cylinder Price: Call Us |
| 8 |
294178 |
Breather-Valve Chamber Price: Call Us |
| 10 |
93394 |
Screw Price: Call Us |
| 11 |
66638 |
Tube-Breather Price: Call Us |
| 13 |
93111 |
Screw-Cylinder Hd. Price: Call Us |
| 14 |
93113 |
Screw-Cylinder Head Price: Call Us |
| 15 |
91249 |
Plug-Pipe Price: Call Us |
| 16 |
260271 |
Crankshaft Price: Call Us |
| 18 |
294305 |
Cover Assy.-Crankcase Price: Call Us |
| 19 |
293708 |
Bushing Price: Call Us |
| 20 |
89660 |
Seal-Oil Price: Call Us |
| 21 |
66768 |
Plug-Oil Price: Call Us |
| 22 |
93032 |
Screw Price: Call Us |
| 22A |
93466 |
Screw-Sem Price: Call Us |
| 23 |
296884 |
Flywheel-Magneto Price: Call Us |
| 24 |
61760 |
Key Flywheel Price: Call Us |
| 25 |
295587 |
Piston Assy.-Std. Price: Call Us |
| 26 |
294232 |
Ring Set (Std.) Price: Call Us |
| 27 |
26026 |
Iock-Piston Pin Price: Call Us |
| 28 |
298909 |
Pin Ass-y-Piston Price: Call Us |
| 29 |
294300 |
Rod Assy.-Connecting Price: Call Us |
| 30 |
220459 |
Dipper-Connecting Rod Price: Call Us |
| 31 |
220460 |
Lock-Connecting Rod Screw Price: Call Us |
| 32 |
92296 |
Screw, Conn.Rod Price: Call Us |
| 33 |
296676 |
Valve Exhaust Price: Call Us |
| 34 |
296677 |
Valve Intake Price: Call Us |
| 35 |
260552 |
Spring-Valve Price: Call Us |
| 40 |
93312 |
Gear-Cam Price: Call Us |
| 45 |
230173 |
Tappet-Valve Price: Call Us |
| 46 |
210453 |
Gear-Cam Price: Call Us |
| 53 |
93353 |
Screw, Carburetor Mtg. Sem Price: Call Us |
| 56 |
298738 |
Pulley-Rewind Starter Price: Call Us |
| 57 |
294303 |
Spring-Rewind Price: Call Us |
| 58 |
66694 |
Rope-Rewind Price: Call Us |
| 59 |
230228 |
Pin-Starter Grip Price: Call Us |
| 60 |
742562 |
DISCONTINUE This part replaces 66728. Price: Call Us |
| 61 |
68618 |
Bumper-Starter Pulley Price: Call Us |
| 66 |
298798 |
Clutch Assy.-Rewind Starter Price: Call Us |
| 67 |
211383 |
Housing Price: Call Us |
| 68 |
63770 |
Ball Price: Call Us |
| 70 |
298436 |
Ratchet Price: Call Us |
| 71 |
221653 |
Washer Price: Call Us |
| 73 |
221661 |
Screw-Sem Price: Call Us |
| 74 |
93490 |
Screw Price: Call Us |
| 75 |
220865 |
Washer Price: Call Us |
| 76 |
68238 |
Washer Price: Call Us |
| 90 |
295490 |
Carburetor Assy. Price: Call Us |
| 96 |
210719 |
Throttle-Carburetor Price: Call Us |
| 114 |
65787 |
Gasket-Needle Valve Price: Call Us |
| 116 |
65978 |
Packing-Needle Price: Call Us |
| 117 |
23431 |
Nut-Needle Valve Price: Call Us |
| 118 |
23433 |
Valve-Needle Price: Call Us |
| 147 |
23432 |
Seat-Needle Valve Price: Call Us |
| 148 |
22235 |
Washer-Needle Valve Price: Call Us |
| 149 |
26336 |
Spring Needle Valve Price: Call Us |
| 152 |
260575 |
Spring-Adjustment Price: Call Us |
| 153 |
298031 |
Screw-Carburetor Lever Price: Call Us |
| 154 |
93349 |
Screw, Machine Price: Call Us |
| 180 |
291834 |
Tank Assembly-Fuel Price: Call Us |
| 181 |
298425 |
Cap-Fuel Tank Price: Call Us |
| 187 |
296476 |
Pipe-Fuel Price: Call Us |
| 190 |
93341 |
Screw-Fuel Tank Mtg. Price: Call Us |
| 200 |
297310 |
Blade-Governor Price: Call Us |
| 201 |
260040 |
Link-Governor Price: Call Us |
| 209 |
260041 |
Spring-Governor Price: Call Us |
| 257 |
93263 |
Screw-Fil. Hd. Price: Call Us |
| 298 |
220859 |
Locknut-Muffier Price: Call Us |
| 299 |
294441 |
Muffler-Exhaust Price: Call Us |
| 304 |
294260 |
Housing-Blower Price: Call Us |
| 305 |
93158 |
Screw Price: Call Us |
| 306 |
220478 |
Muffler-Exhaust Price: Call Us |
| 307 |
93042 |
Screw Price: Call Us |
| 308 |
220581 |
Cover-Cylinder Head Price: Call Us |
| 333 |
298502 |
Armature-Magneto Price: Call Us |
| 334 |
93381 |
Screw Price: Call Us |
| 337 |
298809 |
Plug Spark Price: Call Us |
| 340 |
26018 |
Spring Breaker Arm Price: Call Us |
| 341 |
93381 |
Screw Price: Call Us |
| 342 |
65704 |
Plunger Price: Call Us |
| 344 |
93042 |
Screw Price: Call Us |
| 345 |
220366 |
Cover Breaker Pt. Cond. Price: Call Us |
| 346 |
93014 |
Screw Price: Call Us |
| 347 |
221808 |
Switch, Stop Price: Call Us |
| 372 |
220477 |
Camp-Condenser Price: Call Us |
| 375 |
294628 |
Set Price: Call Us |
| 516 |
260374 |
Spring Connector Price: Call Us |
| 534 |
93322 |
Screw-Air Cleaner Price: Call Us |
| 535 |
27987 |
Element-Air Cleaner Price: Call Us |
| 536 |
296767 |
Cleaner Assy.-Air Price: Call Us |
| 540 |
221380 |
Lever, Speed Adjuster Price: Call Us |
| 541 |
22398 |
Washer Price: Call Us |
| 608 |
294259 |
Starter Assy.-Rewind Price: Call Us |
| 294224 |
Ring |
Set .010" OS. Price: Call Us 294224 |
| 294225 |
Ring |
Set .020" OS. Price: Call Us 294225 |
| 294226 |
Ring |
Set .030" OS. Price: Call Us 294226 |
| 295588 |
Piston |
Assy.-.010" O.S. Price: Call Us 295588 |
| 295589 |
Piston |
Assy. .020" O.S. Price: Call Us 295589 |
| 295590 |
Piston |
Assy.-.030" O.S. Price: Call Us 295590 |
