| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532140840. Price: $219.99 |
| 1 |
MA-19631918000 |
SHAFT Not Available Price: |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
MA-19631919000 |
GEAR 32T Not Available Price: |
| 3 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 3 |
86-1480 |
WASHER Price: $4.82 |
| 3 |
MA-07500062040 |
BEARING NSK 6204 Not Available Price: |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 4 |
84-0780-01 |
PULLEY-SPINDLE Price: $290.34 |
| 4 |
MA-07500063040 |
BEARING NSK 6304 Not Available Price: |
| 5 |
253-154 |
SEAL-OIL Price: $5.48 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
MA-08401020407 |
SEAL, OIL Not Available Price: |
| 6 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
MA-10301916000 |
SPRING Not Available Price: |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 7 |
MA-08000000800 |
BALL Not Available Price: |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
817000616 |
SCREW 3/8-16X1 This part replaces 817490616. Price: $5.99 |
| 8 |
MA-19631921000 |
SHAFT Not Available Price: |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
95-4387 |
SPINDLE SHAFT ASM - CTR Price: $155.61 |
| 9 |
MA-19631922000 |
GEAR 22T Not Available Price: |
| 10 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 92-9800. Price: $18.44 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 10 |
MA-07500062060 |
BEARING NSK6206 Not Available Price: |
| 11 |
86-0010-03 |
BLADE-19" This part replaces 86-0010. Price: $32.86 |
| 11 |
MA-07500062030 |
BEARING NSK 6203 Not Available Price: |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 12 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 12 |
MA-19631956AG0 |
CASE MFD Not Available Price: |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
MA-10251304000 |
PLATE Not Available Price: |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 14 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 14 |
MA-F1540108016 |
BOLT,W/SPRING WASH Not Available Price: |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 15 |
MA-69542-64700 |
BOLT Not Available Price: |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 16 |
MA-F1550110030 |
Bolt Price: $3.52 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
532124238 |
CAP SPRING Price: $4.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK This part replaces 874780814. Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
