| Ref | Part Number | Description |
|---|
| 1 |
3220-7 |
NUT-JAM Price: $4.09 |
| 2 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 4 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 5 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 7 |
67-9410 |
WASHER Price: $2.04 |
| 8 |
32128-45 |
NUT-HHF Price: $7.67 |
| 9 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 10 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 11 |
67-7300 |
SCREW-HH Price: $81.39 |
| 12 |
67-7250 |
SPACER-RING Price: $3.32 |
| 13 |
32153-6 |
NUT-LOCK Price: $3.46 |
| 14 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 15 |
115-4525 |
CYLINDER ASM Price: $1,342.36 |
| 16 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 17 |
328-25 |
SCREW-HH Price: $4.07 |
| 18 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 19 |
56-2460 |
WASHER-FLAT Price: $3.32 |
| 20 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 21 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 23 |
63-6430-03 |
FRAME-REAR Price: $757.78 |
| 24 |
63-6770-03 |
PIN-MASKED Price: $145.71 |
| 25 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 26 |
321-4 |
SCREW-HH Price: $0.99 |
| 27 |
110-9666-01 |
WEIGHT-REAR Price: $1,648.93 |
| 28 |
325-14 |
SCREW-HH Price: $2.64 |
| 33 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 34 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 35 |
110-1995-03 |
WEIGHT-REAR, INSIDE Price: $418.76 |
| 36 |
325-10 |
SCREW-HH Price: $1.82 |
