| Ref | Part Number | Description |
|---|
| 1 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 2 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
2412-109 |
CLIP-J Price: $3.82 |
| 4 |
237-100 |
GROMMET Price: $9.73 |
| 5 |
104-5232 |
CLIP-WIRE This part replaces 60-0930. Price: $3.13 |
| 6 |
93-3190 |
BOOT-INSULATOR, TERMINAL Price: $4.45 |
| 7 |
98-3816 |
CONTROL-HARNESS, WIRE Price: $135.68 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 9 |
82-9790 |
HARNESS Price: $69.81 |
| 10 |
82-9810 |
DISCONTINUED Price: Call Us |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 12 |
532194338 |
PULLEY.ASM.ENG.OGURA.3 Price: $54.99 |
| 15 |
532194264 |
TANK.ASM.FUEL.REAR.W/CAP.2.5 This part replaces 532197024. Price: $89.99 |
| 15 |
58-3850 |
CABLE Price: $80.83 |
| 16 |
104-0086 |
CABLE-BATTERY, POSITIVE This part replaces 43-4030. Price: $78.07 |
| 17 |
98-3815 |
HARNESS - WIRE, MAIN Price: $791.17 |
| 18 |
584248701 |
CAP.ASSY.FUEL.3".N-EPA.BLK.428 This part replaces 532195951. Price: $14.99 |
| 18 |
82-9750 |
HARNESS Price: $24.36 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
2412-131 |
R-CLAMP-CABLE Price: $5.02 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 24 |
86-6400 |
DIODE F/W ENGINE Price: $130.34 |
| 28 |
58-6860 |
CON. BODY/PINS F/W Price: $5.90 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
48-7880 |
NUT-HEX Price: $0.25 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
43-5920 |
WASHER-LOCK, SPRING This part replaces 48-8000. Price: $0.25 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 31 |
99-6124 |
FUSE-40 AMP Price: $4.49 |
| 32 |
218-594 |
FUSE-20 AMP Price: $3.02 |
| 33 |
218-573 |
FUSE-5 AMP Price: $2.64 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 83 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
