| Ref | Part Number | Description |
|---|
| 2 |
532423062 |
PALNUT 1/4 Price: $2.99 |
| 3 |
596135701 |
GSPW Nuts Price: $2.99 |
| 4 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 7 |
596321701 |
Screws Price: $2.99 |
| 9 |
585691301 |
NUT HEX FLG NYLOCK BLK 5_16-1 Price: $5.99 |
| 10 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 12 |
596321701 |
Screws Price: $2.99 |
| 14 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 15 |
592854702 |
BRACKET CRD IDLER ARM MOUNT BL Price: $22.99 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
596134801 |
Nuts Price: $1.00 |
| 18 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 21 |
532178515 |
WASHER Price: $5.99 |
| 23 |
599972501 |
BOLT This part replaces 596564003. Price: $2.99 |
| 27 |
599365301 |
Belts Price: $54.99 |
| 28 |
592855602 |
KEEPER 97 CRD ANGLED IDLER KEE Price: $22.99 |
| 33 |
587819701 |
KIT.MANDREL.NONGREASE.TALL Price: $49.99 |
| 35 |
532427984 |
BLADE.3N1.LH.CRD.97 Price: $49.99 |
| 36 |
532004497 |
RETAINER M Price: $4.99 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 Price: $2.99 |
| 40 |
531169501 |
SERVICE KIT BELT KEEPER This part replaces 532197258. Price: $4.99 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 43 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 44 |
532199534 |
PULLEY.V-IDLER. Price: $32.99 |
| 47 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 48 |
596136301 |
Bolts Price: $2.99 |
| 49 |
532165579 |
MANDREL ASM.CRD RH 6PT STAR Price: $79.99 |
| 52 |
599210703 |
Idler Price: $17.99 |
| 53 |
595098103 |
BRACKET 97 CRD ANGLED V-IDLER Price: $22.99 |
| 55 |
598969201 |
Wires Price: $5.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
598903802 |
Keepers Price: $4.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 72 |
582035601 |
CHUTE.TEX.CRD.GEN I.97 UPPER Price: $69.99 |
| 75 |
597025001 |
CLG Price: $22.99 |
| 78 |
593787801 |
PULLEYS This part replaces 532173902. Price: $27.99 |
| 80 |
595901601 |
GSPW Bolts Price: $2.99 |
| 84 |
589676103 |
KEEPER 42 MANDREL BELT FOR 6.2 This part replaces 589676102. Price: $6.99 |
| 85 |
532427985 |
BLADE.3N1.RH.CRD.97 Price: $49.99 |
| 86 |
583117001 |
BOLT.3/8-24X1.25GR8. LHTHRD This part replaces 532181713. Price: $3.99 |
| 87 |
596238701 |
Washers Price: $3.99 |
| 88 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 89 |
529846801 |
SERVICE.KIT ARM.BRAKE.97.LH AR This part replaces 532438124. Price: $12.99 |
| 90 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 91 |
596134901 |
GSPH Price: $2.99 |
| 92 |
592855701 |
LINK 97 CRD MANUAL DRIVE BRAKE Price: $7.99 |
| 93 |
592854902 |
BRAKE CRD RH BRAKE ARM BLACK E Price: $14.99 |
| 94 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 95 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 96 |
583261101 |
SPACER.NORAM.CRD This part replaces 532400271. Price: $4.99 |
| 97 |
583119101 |
SHIELD.IDLER.MOWER.CRD. This part replaces 532182061. Price: $4.99 |
| 98 |
593824001 |
STUD.W/"D"ANTI-ROTATION Price: $3.99 |
| 99 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 100 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 103 |
583514601 |
GUARD.FRONT.VENT.97.CRD This part replaces 532436992. Price: $6.99 |
| 104 |
592848101 |
GUARD 97CRD RH MANDREL COVER; Price: $32.99 |
| 105 |
583534001 |
LH.MANDREL.COVER.97.TEX.CRD This part replaces 532438744. Price: $24.99 |
| 106 |
532193216 |
SPRING.BRAKE.RETURN.38" Price: $4.99 |
| 118 |
599236302 |
Clutches Price: $14.99 |
| 120 |
531169701 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532197259. Price: $6.99 |
| 122 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 123 |
596987501 |
Bolts Price: $3.99 |
| 127 |
596434404 |
Bolts Price: $4.99 |
| 128 |
589527301 |
WHEEL.GAUGE.RALLY Price: $8.99 |
| 129 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $22.99 |
| 130 |
596133201 |
Washers Price: $5.99 |
| 131 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 132 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 136 |
583544201 |
WASHOUT.PORT.REMOTE.HOOKUP This part replaces 532439639. Price: $3.99 |
| 138 |
587924812 |
HOSE 3/8ID, RUBBER 12" This part replaces 532440743. Price: $2.99 |
| 139 |
596867401 |
Clamps Price: $1.99 |
| 140 |
598660801 |
GUARD.ASM.LH.CRD.FRENCH.97CM This part replaces 501579401. Price: $49.99 |
| 141 |
598660702 |
GUARD.ASM.RH.CRD.FR.97CM.NO This part replaces 501579302. Price: $69.99 |
| 152 |
583548401 |
CBLE.CLTCH.MANUAL.W/SPR.LT.CRD This part replaces 532440488. Price: $32.99 |
| 159 |
596987501 |
Bolts This part replaces 872140614. Price: $3.99 |
| 160 |
532168937 |
NUT Price: $2.99 |
