| Ref | Part Number | Description |
|---|
| 1 |
03897651 |
WDMT, HYD. CYLINDER CLAMP Price: Call Us |
| 1 |
43-6840 |
HOUSING-LOWER This part replaces 33-4370. Price: $1,467.48 |
| 1 |
486545 |
Seat Assembly Price: Call Us |
| 2 |
03897851 |
BRKT, CYLINDER CLAMP Price: Call Us |
| 2 |
04017-27 |
Capscrew, 3/8-16 x 1.0" Serrated Flange Hex Hd Price: Call Us |
| 2 |
72-9420 |
VENT This part replaces 21-8230. Price: $6.85 |
| 3 |
05901724 |
BLT, HEX .38-16X1.25 G5 ZCC This part replaces 05958000. Price: $1.45 |
| 3 |
3219-2 |
NUT-HEX Price: $0.37 |
| 3 |
483559 |
Cable, Seat Stop Price: Call Us |
| 4 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 4 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 5 |
21-8280 |
DISCONTINUED Price: Call Us |
| 5 |
483371 |
Spring, Seat Latch Price: Call Us |
| 6 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 6 |
451883 |
Weldment, Seat Latch Price: Call Us |
| 7 |
04001-100 |
Bolt, 3/8-16 x 6.00" Hex Head Price: Call Us |
| 7 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 8 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 8 |
462998 |
Seat Plate Weldment Price: Call Us |
| 9 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 9 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 10 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 10 |
428503 |
Fan Cover, RH Price: Call Us |
| 11 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 24-8790. Price: $702.98 |
| 11 |
428502 |
Fan Cover, LH Price: Call Us |
| 12 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 12 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 13 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 13 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 14 |
483372 |
Spring, Seat Price: Call Us |
| 15 |
04003-07 |
Bolt, Carriage 1/4-20 x 1/2" Price: Call Us |
| 15 |
21-8080 |
DISCONTINUED Price: Call Us |
| 16 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 16 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 17 |
12-5450 |
SCREW Price: $7.99 |
| 17 |
427546 |
Bumper, (Black) Price: Call Us |
| 18 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 18 |
427862 |
Guard, Engine, (Scag Gold) Price: Call Us |
| 19 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 19 |
86-7230 |
GEAR-INPUT, TRANSMISSION This part replaces 21-8150. Price: $610.12 |
| 20 |
21-7820 |
DISCONTINUED Price: Call Us |
| 20 |
425696 |
Bracket, Anti-Rotation Price: Call Us |
| 21 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 21 |
21-8030 |
DISCONTINUED Price: Call Us |
| 22 |
21-8040 |
DISCONTINUED Price: Call Us |
| 22 |
424639 |
Bracket, Dump Mounting Price: Call Us |
| 23 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 23 |
21-8050 |
BRG SHIM .010 Price: $6.29 |
| 24 |
04017-06 |
CAP SCREW, 1/4-20 X 1" SERRATED FLANGE HEX Price: Call Us |
| 24 |
21-8060 |
DISCONTINUED Price: Call Us |
| 25 |
04040-14 |
Flatwasher, 1/4" (.312 x .750 x .065") Price: Call Us |
| 25 |
28-0640 |
DISCONTINUED Price: Call Us |
| 26 |
463168 |
Control Plate w/Decal, LH (Black) Price: Call Us |
| 26 |
99-5691 |
SCREW W/WASHER This part replaces 28-0660. Price: $7.18 |
| 27 |
04110-01 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 27 |
254-90 |
BEARING-CUP Price: $11.29 |
| 28 |
21-8010 |
BRG CONE Price: $30.15 |
| 28 |
424511 |
Bracket, Switch Mount Price: Call Us |
| 29 |
32151-83 |
RING-SNAP This part replaces 32120-32. Price: $0.34 |
| 29 |
425890 |
Bracket, Tank Mount, SFZ52 Price: Call Us |
| 30 |
21-7850 |
PLUG-CUP Price: $23.35 |
| 30 |
463483 |
Mainframe Assy., w/Decals (Black) - SPZ52H Price: Call Us |
| 31 |
21-7870 |
DISCONTINUED Price: Call Us |
| 31 |
424480 |
Support, Deck Guide Price: Call Us |
| 32 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 32 |
43703 |
Spacer, Bearing Price: Call Us |
| 33 |
21-8070 |
DISCONTINUED Price: Call Us |
| 33 |
483379 |
Bearing Price: Call Us |
| 34 |
04001-31 |
Capscrew, Hex Head 3/8-16 x 2-1/2" Price: Call Us |
| 34 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 35 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 35 |
486294 |
Wheel Assembly, (Black) Price: Call Us |
| 36 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 36 |
482622 |
Roller Bearing, Short Price: Call Us |
| 37 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 37 |
482621 |
Bearing, Tapered Roller Price: Call Us |
| 38 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 38 |
48114-10 |
Fitting, Grease Price: Call Us |
| 39 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 39 |
482619 |
Tire, 13 x 6.50 4-Ply (61A, 72A) Price: Call Us |
| 40 |
04001-167 |
Bolt, Hex Head 1/2-13 x 9-1/2" (61V & 72A/VS) Price: Call Us |
| 40 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 41 |
43584 |
Spacer, Caster Wheel Price: Call Us |
| 42 |
43583 |
Sleeve, Caster Wheel (61V, 72A/VS) Price: Call Us |
| 43 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 44 |
453007 |
Yoke Weldment, (Black)) Price: Call Us |
| 45 |
481025 |
Seal, 2.00" O.D. x 1.625" Bore Price: Call Us |
| 46 |
48668 |
Bearing Set Price: Call Us |
| 47 |
04021-20 |
Nut, Elastic Stop 1.0"-14 Price: Call Us |
| 48 |
484195 |
Cap, Grease Price: Call Us |
| 49 |
483493 |
Rubber Isolator Price: Call Us |
| 50 |
453003 |
Footplate Weldment, (Black) - SPZ52 Price: Call Us |
| 51 |
463169 |
Control Plate w/Decal, RH (Black) Price: Call Us |
| 52 |
04003-11 |
SHORT SQ. NECK CARRIAGE BOLT, 3/8-16 X 1-1/4" Price: Call Us |
| 53 |
463108 |
Deck Lift Cover w/Decal, (Scag Gold Logo) - SPZ52 Price: Call Us |
| 54 |
04017-27 |
Capscrew, 3/8-16 x 1.0" Serrated Flange Hex Hd Price: Call Us |
| 55 |
425889 |
Switch Bracket Price: Call Us |
| 56 |
427864 |
Heat Shield, (Scag Gold) Price: Call Us |
| 57 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 58 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 59 |
48030-18 |
Cable Clamp, Double Price: Call Us |
| 428937 |
Heat |
Shield - Scag SR / Kohler ZT Price: Call Us 428937 |
