| Ref | Part Number | Description |
|---|
| 1 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 1 |
HG70740 |
Overhaul Seal Kit Price: Call Us |
| 2 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 2 |
HG52059 |
Fan Cover Price: Call Us |
| 3 |
105-0150 |
SEAL-GREASE This part replaces 253-143. Price: $4.88 |
| 3 |
HG72158 |
Cylinder Block Kit - 16cc Price: Call Us |
| 4 |
47-4250 |
SLEEVE-WEAR Price: $24.09 |
| 4 |
HG51462 |
Thrust Ball Bearing Assembly Price: Call Us |
| 5 |
47-4260 |
SLINGER-GRASS Price: $1.78 |
| 5 |
HG51436 |
Variable Swashplate Price: Call Us |
| 6 |
130-0081 |
REEL-7IN FWY, (30) 11 BLD This part replaces 11-5119. Price: $674.98 |
| 6 |
HG2000015 |
SLOT GUIDE Price: Call Us |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
HG2000014 |
Trunnion Arm Price: Call Us |
| 8 |
322-1 |
SCREW-HH Price: $0.22 |
| 8 |
HG2000025 |
Spring Block Price: Call Us |
| 9 |
3290-244 |
WASHER-LOCK Price: $0.85 |
| 9 |
HG2000024 |
Block Thrust Washer Price: Call Us |
| 10 |
47-4300-01 |
HANDLE ASM This part replaces 47-4300. Price: $71.44 |
| 10 |
HG2000032 |
Shaft Ball Bearing Price: Call Us |
| 11 |
47-4420 |
SPACER-SLEEVE, ADJUSTMENT Price: $7.85 |
| 11 |
HG2000023 |
Spacer Price: Call Us |
| 12 |
47-4400 |
ARM-SPRING Price: $23.59 |
| 12 |
HG2000038 |
Retaining Ring Price: Call Us |
| 13 |
253-84 |
SEAL-OIL Price: $10.00 |
| 13 |
HG51092 |
Lip Seal Price: Call Us |
| 14 |
257-5 |
WASHER-THRUST Price: $1.83 |
| 14 |
HG70578 |
Kit, Pump Shaft (keyed thru taper) Price: Call Us |
| 15 |
257-6 |
BEARING-THRUST Price: $4.78 |
| 15 |
HG70738 |
Housing Kit Price: Call Us |
| 16 |
47-4410 |
HOUSING-RETAINER Price: $83.21 |
| 16 |
HG70739 |
Trunnion Seal Kit Price: Call Us |
| 17 |
57-5190 |
SCREW-SET, HSH This part replaces 32110-19. Price: $5.50 |
| 17 |
HG50641 |
STRAIGHT HEADLESS PIN Price: Call Us |
| 18 |
3218-5 |
NUT-JAM Price: $0.27 |
| 18 |
HG54021 |
O-RING This part replaces HG51437. Price: Call Us |
| 19 |
47-4080-01 |
BEDBAR ASM This part replaces 47-4080. Price: $453.63 |
| 19 |
HG9005110-7500 |
Straight Thread Plug Price: Call Us |
| 20 |
3296-19 |
NUT-HEX Price: $0.65 |
| 20 |
HG70743 |
SHOCK VALVE KIT, .031 ORIFICE Price: Call Us |
| 21 |
32148-5 |
NUT-INSERT Price: $4.10 |
| 21 |
HG70742 |
Shock Valve Kit (.024" Orifice) Price: Call Us |
| 22 |
47-4440 |
WASHER-PLASTIC Price: $1.35 |
| 22 |
HG9005200-7500 |
Straight Thread Plug Price: Call Us |
| 23 |
47-6680 |
BEDKNIFE, RM (FAIRWAY) Price: $90.64 |
| 23 |
HG70736 |
End Cap Kit Price: Call Us |
| 24 |
119-4151 |
SCREW-BEDKNIFE This part replaces 3-6462. Price: $0.41 |
| 24 |
HG2513030 |
BYPASS VALVE KIT Price: Call Us |
| 25 |
3296-57 |
NUT-LOCK, NI Price: $1.13 |
| 25 |
HG9004100-1430 |
O-RING Price: Call Us |
| 26 |
47-4490 |
PINION-REEL Price: $57.09 |
| 26 |
HG50406 |
Gerotor Assembly (.19 cu.in./rev.) Price: Call Us |
| 27 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 27 |
HG50173 |
Socket Head Cap Screw (M8 x 1.25-25mm) Price: Call Us |
| 28 |
68-7530 |
BUSHING This part replaces 19-9750. Price: $19.19 |
| 28 |
HG70924 |
Charge Pump Kit (.19 STD. Splined) Price: Call Us |
| 29 |
47-4530 |
RETAINER-DRAWBAR Price: $21.45 |
| 29 |
HG51457 |
Hex Screw, Flanged Head (M10 x 1.50-65mm) Price: Call Us |
| 30 |
37-3490-01 |
BRACKET-DRAWBAR This part replaces 37-3490. Price: $18.94 |
| 30 |
HG70402 |
CHARGE RELIEF VALVE KIT Price: Call Us |
| 31 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 31 |
HG71287 |
Fan Kit Price: Call Us |
| 32 |
323-6 |
SCREW-HH Price: $0.66 |
| 32 |
HG51348 |
Washer Price: Call Us |
| 33 |
11-5069 |
MAIN TUBE ASM Price: $641.88 |
| 33 |
HG52016 |
Bracket, Shroud Price: Call Us |
| 34 |
47-4510 |
SHAFT-ADJUSTING Price: $47.27 |
| 34 |
HG52014 |
Fan Price: Call Us |
| 35 |
47-5750 |
DECAL-REELMASTER, 11 BLADE Price: $12.85 |
| 35 |
HG52256 |
Washer Price: Call Us |
| 36 |
3219-5 |
NUT-HEX Price: $1.22 |
| 37 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 38 |
3257-3 |
KEY-WOODRUFF Price: $0.99 |
| 39 |
5-1463 |
PINION-REEL Price: $82.16 |
| 485879 |
Fan |
Cover w/ Notch (26EFI Right Side Pump Only) Price: Call Us 485879 |
