| Ref | Part Number | Description |
|---|
| 1 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 2 |
3296-357 |
Nut-HFH Price: Call Us |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 4 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 5 |
28-9060 |
PLATE-IDLER Price: $137.75 |
| 6 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 7 |
99-1297 |
IDLER ARM ASM This part replaces 27-8580. Price: $133.94 |
| 8 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 9 |
3296-5 |
NUT-HEX Price: $3.09 |
| 10 |
65-5940 |
PULLEY-IDLER Price: $35.61 |
| 11 |
7-0081 |
WASHER-FLAT Price: $0.89 |
| 12 |
65-5950 |
BUSHING-PULLEY Price: $4.44 |
| 13 |
3211-8 |
SCREW-HH Price: $3.50 |
| 14 |
27-1160 |
V-BELT Price: $51.80 |
| 15 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
32146-20 |
NUT-HEX Price: $3.23 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 17 |
7-4150 |
WASHER Price: $1.19 |
| 18 |
27-0970-03 |
PULLEY ASM This part replaces 27-0970. Price: $51.99 |
| 19 |
253-139 |
SEAL-OIL Price: $12.45 |
| 20 |
46-8530 |
BEARING ASM Price: $93.99 |
| 21 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 22 |
27-7680-03 |
RING-DECK SUPPORT This part replaces 27-7680. Price: $70.99 |
| 23 |
68-8340 |
DECAL-TORQUE Price: $19.99 |
| 24 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
61-4160 |
HOUSING-SPINDLE Price: $131.00 |
| 26 |
32128-21 |
NUT-HF Price: $0.39 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
27-0920 |
SHAFT Price: $158.07 |
| 28 |
27-0990-03 |
BLADE-18 INCH This part replaces 27-0990. Price: $18.94 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 29 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 30 |
3253-27 |
WASHER-LOCK Price: $2.24 |
| 31 |
44-2200 |
SCREW-BLADE Price: $4.04 |
| 32 |
27-0950 |
SPACER Price: $29.99 |
| 33 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
92-8791 |
DISCONTINUED This part replaces 72-9260. Price: Call Us |
| 35 |
40-6400 |
SHAFT-ROLLER Price: $38.99 |
| 35 |
583864502 |
Rods This part replaces 583864501. Price: $6.99 |
| 36 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 37 |
29-4820 |
ROLLER Price: $14.88 |
| 38 |
57-0690 |
PIN-SPECIAL Price: $3.66 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532413430 |
KEEPER.CENTER SPAN.1.688 Price: $5.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop This part replaces 585658601. Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532416863 |
PEDAL.FORWARD.HUSQVARNA.DEALER Price: $32.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 230 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 231 |
532407287 |
IDLER.V-GROOVE.1.688.OFFSET Price: $19.99 |
| 284 |
532417693 |
NUT.U-CHNL.1/4-20.550DP.350PNL Price: $3.99 |
| 334 |
585882202 |
SWAY.ROD.BRACKET.K46.X431 Price: $11.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
