| Ref | Part Number | Description |
|---|
| 1 |
133-2911 |
LIFT ARM ASM #1 This part replaces 110-0991. Price: $382.73 |
| 2 |
140-6385 |
NO. 5 LIFT ARM ASM This part replaces 127-8519. Price: $573.28 |
| 3 |
133-2914 |
LIFT ARM ASM #4 This part replaces 114-8874. Price: $382.73 |
| 4 |
127-8494 |
PIN-LIFT ARM Price: $145.20 |
| 6 |
327-7 |
SCREW-HH Price: $5.69 |
| 12 |
163-3530 |
CYLINDER-HYDRAULIC This part replaces 119-6988. Price: $515.30 |
| 14 |
92-1298 |
PIN-LYNCH Price: $2.27 |
| 15 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 16 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 17 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 18 |
163-3534 |
CYLINDER-HYDRAULIC This part replaces 119-6987. Price: $558.76 |
| 19 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 20 |
110-0922 |
HOOP-CHAIN Price: $15.10 |
| 21 |
63-8410 |
WASHER Price: $1.76 |
| 22 |
323-7 |
SCREW-HH Price: $0.65 |
| 23 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 24 |
84-2451 |
CHAIN-STRAIGHT, 5 LINK Price: $9.25 |
| 25 |
138-1248 |
PIVOT YOKE ASM This part replaces 107-2052. Price: $429.41 |
| 27 |
323-6 |
SCREW-HH Price: $0.66 |
| 28 |
107-4027 |
CAP Price: $12.59 |
| 29 |
107-7400 |
PIN-LYNCH Price: $9.56 |
| 31 |
127-8506-03 |
PLATE-BRIDGE Price: $26.00 |
| 32 |
127-8507-03 |
PLATE-BRIDGE Price: $27.01 |
| 33 |
325-7 |
SCREW-HH Price: $1.53 |
| 34 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 35 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 36 |
117-0148 |
PIN-CYLINDER Price: $52.54 |
| 37 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 38 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 39 |
139-5995 |
GUIDE-HOSE, RH This part replaces 119-3920. Price: $32.43 |
| 40 |
139-5996 |
HOSE GUIDE ASM-LH This part replaces 119-3921. Price: $32.43 |
| 41 |
99-7667 |
WASHER-FLAT Price: $4.80 |
