| Ref | Part Number | Description |
|---|
| 1 |
710-0513A |
BOLT 1/4-28 X .625 GR8 This part replaces 710-0513. Price: $4.04 |
| 2 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 3 |
736-0176 |
Fl-Wash. .25" I.D. x .93" O.D. x .125" Thk. Price: $3.95 |
| 4 |
941-0155 |
Bearing .62" I.D. x 1.38" O.D. x .437" Thk. This part replaces 741-0155. Price: $22.09 |
| 7 |
04956 |
INPUT SHAFT Not Available Price: |
| 8 |
750-0471 |
SPACER Not Available Price: |
| 10 |
750-0275 |
HUB-SPROCKET Not Available Price: |
| 11 |
710-0118 |
Hex Scr. 5/16-18 x .625" Lg. Price: $3.76 |
| 12 |
710-0599 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .50" Lg. Price: $3.86 |
| 13 |
941-0155 |
Bearing .62" I.D. x 1.38" O.D. x .437" Thk. This part replaces 741-0155. Price: $22.09 |
| 14 |
05034A |
BEARING HOUSING Not Available This part replaces 05034. Price: |
| 15 |
710-0629 |
SCREW 3/8-24 x 2.75 GR.5 Not Available Price: |
| 16 |
736-0258 |
Fl-Wash. 3/8" I.D. x 1.25" O.D. x .100 Thk. Price: $3.93 |
| 17 |
710-0599 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .50" Lg. Price: $3.86 |
| 18 |
931-0487 |
Dust Cap This part replaces 731-0487. Price: $10.29 |
| 19 |
721-0175 |
SEAL Not Available Price: |
| 20 |
14985 |
ASS'Y. TILLER HOUSI NG L.H. Not Available Price: |
| 21 |
721P0170 |
GASKET This part replaces 721-0170. Price: $13.38 |
| 22 |
736-0163 |
Thrust Wash. 1.00" I.D. x .030" Thk. Price: $4.05 |
| 23 |
950-0570 |
Step Spacer This part replaces 750-0570. Price: $8.81 |
| 24 |
784-0089 |
SHAFT ASSEMBLY-TINE Not Available Price: |
| 26 |
916-0131 |
Snap Ring This part replaces 716-0131. Price: $6.21 |
| 27 |
14984 |
ASS'Y. TILLER HOUSING (RH) Not Available Price: |
| 28 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 29 |
712-0711 |
Hex Nut 3/8-24 Thd. Price: $3.90 |
| 30 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 31 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
