| Ref | Part Number | Description |
|---|
| 1 |
132-6120-0P |
PLATE-FLYWHEEL This part replaces 132-6120-03. Price: $510.83 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
107-1413 |
WASHER-HARDENED Price: $1.08 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
132-6121 |
COUPLING-FLYWHEEL Price: $372.90 |
| 4 |
139-9940 |
SCREW-HH This part replaces 99-5132. Price: $1.99 |
| 5 |
117-5663 |
SCREW-HH Price: $1.29 |
| 6 |
87-7510 |
WASHER-FLAT Price: $1.15 |
| 7 |
121-5636 |
TAB-HARNESS Price: $3.37 |
| 8 |
127-2774 |
BRACKET-HARNESS, RH Price: $17.26 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 10 |
33114-016 |
SCREW-HH Price: $0.27 |
| 11 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 12 |
33115-016 |
SCREW-HH Price: $0.75 |
| 13 |
127-2773 |
BRACKET-HARNESS, LH Price: $14.53 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $12.99 |
| 30 |
532175566 |
IGNITION SWITCH Price: $22.99 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED Price: $4.99 |
| 46 |
532169642 |
KIT.HOURMETER.SNAP-IN This part replaces 532169635. Price: $109.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 89 |
532169639 |
BRACKET SNAP-IN HOURMETER Price: $4.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $4.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
