| Ref | Part Number | Description |
|---|
| 1 |
107-7773 |
SCREW-HSH Price: $8.36 |
| 1 |
874610412 |
Bolt, Hex 1/4-28 x 3/4 Gr. 5 (AYP part number) Price: $1.99 |
| 2 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 2 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 3 |
107-2996 |
FRONT GRASS SHIELD ASM Price: $69.51 |
| 3 |
819092016 |
Washer 9/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $2.99 |
| 4 |
125-2098 |
SHIELD-GRASS, REAR (5 INCH) Price: $62.97 |
| 4 |
819091416 |
WASHER This part replaces 819091412. Price: $3.99 |
| 5 |
125-2107 |
TAB-SHIELD, STOP Price: $28.22 |
| 5 |
874780544 |
BOLT HEX This part replaces 874760544. Price: $3.99 |
| 6 |
3256-74 |
WASHER-FLAT Price: $0.27 |
| 6 |
532125357 |
Bracket, Engine, R.H. (AYP part number) Price: Call Us |
| 7 |
322-14 |
SCREW-HH Price: $1.01 |
| 7 |
532009173 |
Spacer, Split (AYP part number) Price: $3.99 |
| 8 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 8 |
532125358 |
Bracket, Engine, L.H. (AYP part number) Price: $11.99 |
| 9 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 9 |
810040500 |
Washer, Lock 5/16 (AYP part number) Price: $2.99 |
| 10 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 10 |
873220500 |
Nut, Hex 5/16-18 (AYP part number) Price: $3.99 |
| 11 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 11 |
819131311 |
Washer 13/32 x 13/16 x 11 Ga. (AYP part number) Price: $3.99 |
| 12 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 12 |
59-2580 |
SPACER-TUBULAR Price: $8.05 |
| 13 |
108-4293 |
ROLLER Price: $18.09 |
| 13 |
532124701 |
Nut 3/8-24 (AYP part number) Price: $5.99 |
| 14 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
532105391 |
Transmission (AYP part number) Price: $3.33 |
| 15 |
108-4286 |
BRACKET-ADJUSTMENT Price: $15.44 |
| 15 |
873510500 |
Nut, Keps 5/16-18 (AYP part number) Price: $5.99 |
| 16 |
108-4289 |
PIN-MOUNT, ROLLER Price: $53.95 |
| 16 |
874610652 |
Bolt, Hex 3/8-24 x 3-1/4 Gr. 5 (AYP part number) Price: Call Us |
| 17 |
3254-21 |
WASHER-LOCK/INT Price: $1.15 |
| 18 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 19 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
