| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 1 |
575608801 |
PLATE, ENGINE W/DECALS This part replaces 574846302. Price: $179.99 |
| 2 |
574846402 |
PLATE, IDLER, BLK Price: $79.99 |
| 3 |
574870901 |
BELT, HYDRO, 3400 Price: $34.99 |
| 3 |
75-4370-03 |
BRACKET-SEAT This part replaces 75-4370. Price: $20.93 |
| 4 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 4 |
574811001 |
PULLEY, V, 1.125 BORE Price: $39.99 |
| 5 |
596739801 |
PULLEYS This part replaces 539976688. Price: $29.99 |
| 5 |
92-8753 |
DISCONTINUED Price: Call Us |
| 6 |
596481401 |
Pulleys This part replaces 539107620. Price: $22.99 |
| 6 |
92-8001 |
SENSOR-SWITCH, REED Price: $86.02 |
| 7 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 7 |
510041603 |
ARM, IDLER, STEEL, W/BGS Price: $49.99 |
| 8 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 Price: $24.99 |
| 8 |
75-4360-03 |
BRACKET-SUSPENSION, SEAT This part replaces 75-4360. Price: $17.81 |
| 9 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 Price: $24.99 |
| 10 |
510206301 |
PIVOT, BEARING Price: $3.99 |
| 10 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 11 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 11 |
525435601 |
PIVOT, IDLER Price: $5.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
574607001 |
CLUTCH 200 FT LB Price: $379.99 |
| 13 |
322-3 |
SCREW-HH Price: $0.79 |
| 13 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 14 |
510254402 |
Springs This part replaces 510254401. Price: $5.99 |
| 14 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 15 |
110-4149 |
KIT-SEAT PLATE This part replaces 93-9976. Price: $166.30 |
| 15 |
596394601 |
Shields This part replaces 539114662. Price: $2.99 |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 17 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 17 |
575229902 |
BRKT, MUFFLER, BLK Price: $29.99 |
| 18 |
539131604 |
MUFFLER ASM TWIN Price: $39.99 |
| 18 |
75-3680-03 |
ROD-SEAT This part replaces 75-3680. Price: $38.90 |
| 19 |
32121-38 |
PIN-ROLL Price: $0.53 |
| 19 |
539101714 |
SOLENOID Price: $22.99 |
| 20 |
575017305 |
STOP CLUTCH STOP This part replaces 575017302. Price: $12.99 |
| 20 |
75-1350 |
THROTTLE CABLE Price: $15.76 |
| 21 |
539102759 |
INSULATOR Price: $3.99 |
| 22 |
584825501 |
HOSE.ASSEMBLY.OIL.DRAIN Price: $27.99 |
| 23 |
539102757 |
CABLE POSITIVE Price: $7.99 |
| 24 |
539101363 |
CLAMP Price: $2.99 |
| 25 |
539912757 |
KEY, 1/4 SQ X 1 1/4 Price: $3.99 |
| 26 |
585807101 |
PLUG OIL DRAIN Price: $2.99 |
| 27 |
522599003 |
ADAPTER This part replaces 522599001. Price: $8.99 |
| 27 |
98-2359-03 |
SEAT FRAME ASM This part replaces 94-1250. Price: $369.09 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
525464701 |
HHFS 5/16-18 X 3/4 Price: $2.99 |
| 29 |
596918101 |
Bolts This part replaces 539976949. Price: $2.99 |
| 29 |
63-6760 |
FITTING-CONNECTOR Price: $61.52 |
| 30 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 30 |
525866201 |
HHFS 3/8-16 X 2.0 GD 5 Price: $3.99 |
| 31 |
581332806 |
Bolts This part replaces 581332802. Price: $6.99 |
| 31 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 32 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 33 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 34 |
596437001 |
Screws This part replaces 539990071. Price: $2.99 |
| 34 |
75-3430-03 |
LEVER-THROTTLE This part replaces 75-3430. Price: $29.18 |
| 35 |
233-42 |
KNOB Price: $12.88 |
| 35 |
539100413 |
RHSNB 3/8-16 X 1-1/4 Price: $2.99 |
| 36 |
596435701 |
Bolts This part replaces 539107271. Price: $2.99 |
| 36 |
93-9979 |
DISCONTINUED Price: Call Us |
| 37 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 37 |
93-9983 |
BRACKET - SEAT, LATCH Price: $7.18 |
| 38 |
539107475 |
BOLT 5/16-18 X 3/4 Price: $4.99 |
| 38 |
66-4160 |
SPRING-SOLENOID, UPPER Price: $11.93 |
| 39 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 39 |
596582701 |
Screws This part replaces 539990302. Price: $2.99 |
| 40 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 40 |
92-1125 |
DISCONTINUED Price: Call Us |
| 40 |
92-1126 |
DISCONTINUED Price: Call Us |
| 40 |
92-1127 |
DECAL- CLIP INSTRUCTION Price: $17.95 |
| 40 |
92-1128 |
DECAL- CLIP INSTRUCTION Price: $24.42 |
| 40 |
92-1129 |
DISCONTINUED Price: Call Us |
| 40 |
92-1130 |
DISCONTINUED Price: Call Us |
| 40 |
92-1131 |
DECAL- CLIP INSTRUCTION Price: $24.42 |
| 40 |
93-8057 |
DECAL-CLIP INSTR,PORTUG. Price: $5.91 |
| 40 |
93-8058 |
DECAL-CLIP INSTR,NORWEG. Price: $5.91 |
| 40 |
93-8059 |
DECAL-CLIP INSTR,FINNISH Price: $5.91 |
| 41 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 41 |
93-0140 |
GROMMET-RUBBER Price: $3.94 |
| 42 |
2412-133 |
CLAMP-R Price: $3.19 |
| 42 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 43 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 44 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 45 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 46 |
321-4 |
SCREW-HH Price: $0.99 |
| 46 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 47 |
323-4 |
SCREW-HH Price: $1.02 |
| 47 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 48 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 49 |
595316401 |
Washers This part replaces 539109554. Price: $2.99 |
| 49 |
93-8060 |
DECAL-REELS Price: $53.80 |
| 50 |
2412-93 |
CLAMP-R Price: $1.02 |
| 50 |
596581701 |
Washers This part replaces 539115528. Price: $2.99 |
| 51 |
539109562 |
WASHER 3/8 X 3/4 X .187 TK Price: $3.99 |
| 52 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 53 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 54 |
596917301 |
Washers This part replaces 539111897. Price: $4.99 |
