| Ref | Part Number | Description |
|---|
| 1 |
23-5020 |
DISCONTINUED Price: Call Us |
| 1 |
532176027 |
DECK.WELDMENT.42".BLACK This part replaces 532165892. Price: $279.99 |
| 2 |
3-7902 |
DISCONTINUED Price: Call Us |
| 2 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 3 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 3 |
532138017 |
BRKT ASM SWAY BAR Price: $7.99 |
| 4 |
3217-5 |
NUT-HEX Price: $0.25 |
| 4 |
532165460 |
BRACKET SWAY BAR 42" DECK Price: $6.99 |
| 5 |
3-7898 |
WASHER-THRUST Price: $1.47 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
5-1335 |
SIDE GEAR Price: $282.05 |
| 6 |
532178024 |
BAR SWAY DECK Price: $5.99 |
| 7 |
5-2036 |
DISCONTINUED Price: Call Us |
| 8 |
5-2037 |
SIDE GEAR Price: $525.58 |
| 9 |
256-154 |
BUSHING Price: $10.71 |
| 10 |
5-1401 |
DISCONTINUED Price: Call Us |
| 11 |
3-8025 |
DISCONTINUED Price: Call Us |
| 12 |
3-8026 |
GEAR BUSHING SHAFT Price: $16.20 |
| 13 |
5-1413 |
DISCONTINUED Price: Call Us |
| 13 |
587253301 |
MANDREL.NONGREASEABLE.TALL This part replaces 532192872. Price: $32.99 |
| 14 |
3-8015 |
DISCONTINUED Price: Call Us |
| 14 |
532187281 |
HOUSING.MANDREL.4PT. Price: $22.99 |
| 15 |
32150-1 |
KEY-SQUARE Price: $4.39 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 16 |
3-7903 |
DISCONTINUED Price: Call Us |
| 17 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 18 |
242-33 |
DISCONTINUED Price: Call Us |
| 18 |
872140505 |
BOLT Price: $2.99 |
| 19 |
3-8529 |
DISCONTINUED Price: Call Us |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $2.99 |
| 20 |
242-39 |
WHEEL ASM Price: $244.32 |
| 20 |
532159770 |
BAFFLE.VORTEX Price: $12.99 |
| 21 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 22 |
237-70 |
DISCONTINUED Price: Call Us |
| 23 |
117127 |
TIRE (16 X 6.5-8) 2-PLY -2 WHEEL AXEL This part replaces 231-39. Price: $107.13 |
| 23 |
532177563 |
BRKT, DEFL. MOWER Price: $2.99 |
| 24 |
242-32 |
LUG NUT Price: $4.77 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
323-4 |
SCREW-HH Price: $1.02 |
| 25 |
532123713 |
SPRING TORSION Price: $3.99 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 26 |
95-1823 |
WASHER This part replaces 3-3391. Price: $29.18 |
| 27 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK This part replaces 532171859. Price: $22.99 |
| 28 |
3-0737 |
WASHER Price: $7.59 |
| 28 |
819111016 |
WASHER Price: $5.99 |
| 29 |
3-7856 |
DISCONTINUED Price: Call Us |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
2710-11 |
LINK-CHAIN Price: $5.68 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $1.99 |
| 31 |
321-5 |
SCREW-HH Price: $0.22 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 32 |
3-7896 |
REEL BELT Price: $75.42 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $7.99 |
| 33 |
3290-245 |
DISCONTINUED Price: Call Us |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
3-7167 |
DISCONTINUED Price: $2.00 |
| 34 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 35 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 36 |
532173438 |
PULLEY.IDLER.FLAT This part replaces 532131494. Price: $14.99 |
| 37 |
5-1404 |
DISCONTINUED Price: Call Us |
| 38 |
3-7858 |
DISCONTINUED Price: Call Us |
| 39 |
2710-15 |
LINK-OFFSET Price: $29.98 |
| 40 |
4-8049 |
DISCONTINUED Price: Call Us |
| 40 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 41 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 42 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 43 |
3-6168 |
KEY Price: $11.99 |
| 44 |
5-2187 |
TRACTION SPROCKET Price: $91.00 |
| 45 |
5-2188 |
DISCONTINUED Price: Call Us |
| 45 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 46 |
322-4 |
SCREW-HH Price: $0.35 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
251-318 |
BEARING-BALL This part replaces 251-204. Price: $16.40 |
| 48 |
3290-238 |
WASHER-LOCK Price: $2.71 |
| 48 |
532133944 |
WASHER Price: $2.99 |
| 49 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 50 |
5-1354 |
DISCONTINUED Price: Call Us |
| 51 |
3290-244 |
WASHER-LOCK Price: $0.85 |
| 52 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 52 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $2.99 |
| 53 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 53 |
532184907 |
ARM BRAKE ASSY Price: $11.99 |
| 54 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 54 |
532178515 |
WASHER Price: $2.99 |
| 55 |
256-149 |
DISCONTINUED Price: Call Us |
| 55 |
532155046 |
ARM IDLER 42" MOWER LT/YT Price: $7.99 |
| 56 |
32120-69 |
RING-SNAP Price: $2.78 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $2.99 |
| 57 |
3-6561 |
DISCONTINUED Price: Call Us |
| 58 |
3-6049 |
BELL CRANK & SHAFT Price: $531.69 |
| 59 |
3-6557 |
THRUST WASHER Price: $6.96 |
| 59 |
532141043 |
GUARD, BELT Price: $3.99 |
| 60 |
5-1841 |
DISCONTINUED Price: Call Us |
| 61 |
2710-6 |
LINK-CONNECTING Price: $18.99 |
| 62 |
3-6535 |
TRACTION CHAIN Price: $108.13 |
| 63 |
3246-4 |
SCREW-SET Price: $0.75 |
| 64 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 65 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 66 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 67 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 67 |
532106932 |
KNOB T (3/8 HOLE) Price: $2.99 |
| 68 |
3-7386 |
SPINDLE Price: $9.47 |
| 68 |
532144959 |
BELT V SECONDARY Price: $32.99 |
| 69 |
3-6379 |
DISCONTINUED Price: Call Us |
| 70 |
252-62 |
DISCONTINUED Price: Call Us |
| 71 |
3-7843 |
DISCONTINUED Price: Call Us |
| 72 |
3-7857 |
BELT-V, RIBBED Price: $102.86 |
| 73 |
5-1351 |
DISCONTINUED Price: Call Us |
| 74 |
32120-41 |
DISCONTINUED Price: Call Us |
| 75 |
5-1992 |
DISCONTINUED Price: Call Us |
| 76 |
3-6543 |
DISCONTINUED Price: Call Us |
| 78 |
11-4640 |
TENSION SPRING Price: $7.99 |
| 79 |
3276-6 |
Cotter Pin Price: Call Us |
| 80 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 81 |
3-8325 |
DISCONTINUED Price: Call Us |
| 82 |
32121-7 |
PIN-ROLL, SLOTTED Price: $0.31 |
| 83 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 84 |
3-8284 |
DISCONTINUED Price: Call Us |
| 85 |
3220-2 |
NUT-JAM Price: $0.50 |
| 86 |
5-1444 |
ROD & FLANGE WA Price: $28.78 |
| 87 |
3-6952 |
DISCONTINUED Price: Call Us |
| 88 |
5-2038 |
DISCONTINUED Price: Call Us |
| 89 |
3-3129 |
DISCONTINUED Price: Call Us |
| 90 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 91 |
3-8286 |
DISCONTINUED Price: Call Us |
| 92 |
302-42 |
DISCONTINUED Price: Call Us |
| 93 |
3219-2 |
NUT-HEX Price: $0.37 |
| 94 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 95 |
3-7861 |
DISCONTINUED Price: Call Us |
| 142 |
532195784 |
ANCHOR SPRING BRAKE MOWER Price: $4.99 |
| 143 |
532157109 |
BRACKET, ARM IDLER Price: $3.99 |
| 144 |
532173441 |
KEEPER BELT 42" CLUTCH This part replaces 532158634. Price: $5.99 |
| 145 |
532173437 |
PULLEY.IDLER.FLAT.PLATED This part replaces 532165888. Price: $14.99 |
| 146 |
532171977 |
BOLT, CARRIAGE IDLER BLACK Price: $3.99 |
| 147 |
532179748 |
SPRING This part replaces 532131335. Price: $1.99 |
| 148 |
532169022 |
IDLER RETURN SPRING Price: $2.99 |
| 149 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 150 |
531003379 |
WASHER This part replaces 819091210. Price: $2.99 |
| 152 |
532175067 |
KIT.CLUTCH.CABLE This part replaces 532169676. Price: $29.99 |
| 158 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 159 |
872140614 |
BOLT Price: $2.99 |
| 184 |
734117201 |
WASHER This part replaces 819131410. Price: $1.99 |
| 185 |
532188234 |
HEAD ASM. CABLE CLUTCH Price: $34.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $2.99 |
