| Ref | Part Number | Description |
|---|
| 1 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 1 |
KM-13045-2051 |
RECEIVER-O Not Available Price: |
| 2 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 2 |
KM-13107-2296 |
OIL PUMP SHAFT Not Available This part replaces KM-13107-2099. Price: |
| 3 |
71-2570 |
SHAFT-PIVOT Price: $431.51 |
| 3 |
KM-13183-2419 |
PLATE Not Available Price: |
| 4 |
69-7940-01 |
SUPPORT-LIFT ARM, RH Price: $234.45 |
| 4 |
KM-14024-2113 |
OIL PUMP COVER Not Available Price: |
| 5 |
KM-16115-2090 |
CAP OIL FI Not Available Price: |
| 6 |
237-42 |
O-RING Price: $2.78 |
| 6 |
KM-16154-2053 |
ROTOR-PUMP INNER Not Available Price: |
| 7 |
92-4971 |
CYLINDER-HYD Price: $718.13 |
| 7 |
KM-16154-2054 |
ROTOR-PUMP OUTER Not Available Price: |
| 8 |
237-22 |
O-RING Price: $2.43 |
| 8 |
KM-49065-0734 |
OIL FILTER This part replaces KM-49065-2071. Price: $19.59 |
| 9 |
69-8440 |
HOSE ASM Price: $53.07 |
| 9 |
KM-49065-2072 |
OIL FILTER Not Available Price: |
| 10 |
KM-52005-2120 |
GAUGE Not Available Price: |
| 11 |
72-4310 |
SWITCH-BALL Price: $84.47 |
| 11 |
KM-59051-2114 |
SPUR GEAR Not Available Price: |
| 12 |
69-5440 |
HOSE ASM Price: $73.25 |
| 12 |
KM-92042-014 |
PIN-GEAR Price: $1.36 |
| 13 |
340-70 |
NUT-LOCK Price: $2.10 |
| 13 |
KM-92055-2086 |
O-RING Not Available Price: |
| 14 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 14 |
KM-92143-2187 |
COLLAR,8.2 Not Available Price: |
| 15 |
98-7346 |
SPACER Price: $30.67 |
| 15 |
KM-92145-2132 |
SPRING Not Available This part replaces KM-92144-2053. Price: |
| 16 |
20-4360-03 |
SPACER Price: $8.01 |
| 16 |
KM-130G0614 |
FLANGED BOLT Not Available Price: |
| 17 |
69-9180 |
PIN-CYLINDER Price: $25.38 |
| 17 |
KM-130B0820 |
BOLT-FLANG Not Available Price: |
| 18 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 18 |
KM-214B0512 |
SCREW Not Available Price: |
| 19 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 19 |
KM-600A1300 |
STEEL BALL Not Available Price: |
| 20 |
32153-6 |
NUT-LOCK Price: $3.46 |
| 20 |
KM-670B2011 |
O-Ring Price: $2.62 |
| 21 |
328-5 |
SCREW-HH Price: $3.60 |
| 22 |
325-6 |
SCREW-HH Price: $1.42 |
| 23 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 24 |
71-2590 |
SHAFT-PIVOT Price: $228.41 |
| 25 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 26 |
3217-9 |
NUT-HH Price: $0.37 |
| 27 |
69-7920-01 |
SUPPORT-LIFT ARM, LH Price: $214.14 |
| 28 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 29 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 30 |
111-1290 |
ENGINE - KUBOTA V1505-E2B-HAYTER-1 This part replaces 92-4806. Price: $3,715.61 |
| 31 |
32120-47 |
RING-RETAINING, EXTERNAL Price: $0.99 |
| 32 |
69-8470-03 |
SPRING-TORSION Price: $92.60 |
| 33 |
76-1670-03 |
SPRING-EXTENSION Price: $24.92 |
| 34 |
69-1540-03 |
PIVOT-SPRING, TORSION Price: $122.27 |
| 35 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 36 |
32136-2 |
NUT-SHH Price: $3.55 |
| 37 |
86-8100-01 |
BALL JOINT ASM Price: $137.53 |
| 38 |
21-3000-01 |
NUT-JAM, PUSH ARM Price: $37.02 |
| 39 |
69-9580 |
LH FRONT LIFT ARM ASM Price: $1,165.75 |
| 40 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 41 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 43 |
69-9570 |
RH FRONT LIFT ARM ASM Price: $1,410.77 |
| 44 |
93-7426 |
TUBE-HYD Price: $86.55 |
| 45 |
340-57 |
FITTING-HYD Price: $9.11 |
| 46 |
93-1397 |
VALVE-CONTROL, FLOW Price: $142.88 |
| 539107897 |
596436301 |
Nuts This part replaces 539107897. Price: $2.99 |
| 539111577 |
539111577 |
LIGHT 35W W/BRKT Price: $64.99 |
| 539111578 |
539111578 |
LIGHT MOUNTING BRACKET Price: $11.99 |
| 539111580 |
539111580 |
LIGHT HARNESS Price: $79.99 |
| 539111815 |
539111815 |
BULB, 12V 35 WATT Price: $9.99 |
| 539976856 |
539976856 |
TIE, PLASTIC Price: $4.99 |
| 539991016 |
539991016 |
Price: Call Us |
