| Ref | Part Number | Description |
|---|
| 3 |
532121316 |
PULLEY.IDLER.FLAT.MOWER.BLK.PT Price: $44.99 |
| 5 |
532106902 |
SPACER RETAINER Price: $2.99 |
| 6 |
532124858 |
IDLER-INSIDE T Price: $32.98 |
| 7 |
532106513 |
WASHER, WEAR LT (1 2) Price: $5.99 |
| 8 |
532121425 |
ARM IDLER Price: $4.06 |
| 9 |
532109776 |
PIVOT PIN T Price: $8.99 |
| 10 |
532106523 |
BAR-SUPPORT YT Price: $13.32 |
| 11 |
532106522 |
BRACE-IDLER YT Price: $2.99 |
| 12 |
532121236 |
SPACER Price: $2.38 |
| 14 |
532136819 |
MANDREL ASM SEC 44/50 This part replaces 532121658. Price: $89.99 |
| 15 |
532106214 |
GUARD YT Price: $22.99 |
| 16 |
532106085 |
V-BELT T Price: $37.99 |
| 19 |
532102932 |
IDLER.FLAT.GTV Price: $24.99 |
| 20 |
532106526 |
ARM-IDLER YT Price: $14.99 |
| 21 |
532007644 |
SPRING This part replaces 532124885. Price: $6.23 |
| 22 |
532121705 |
JACKSHAFT YT Price: $123.99 |
| 24 |
532109599 |
BRACKET LH YTH Price: $15.31 |
| 25 |
532105662 |
LINK,PARALLEL Price: $15.31 |
| 26 |
532004921 |
COTTER PIN Price: $4.99 |
| 27 |
532105744 |
ROD,FRT PARALL LT Price: $9.99 |
| 28 |
532109835 |
HINGE PIN T Price: $13.61 |
| 29 |
532109600 |
BRACKET RH YTH Price: $23.03 |
| 30 |
532108119 |
GUARD BELT HYT Price: $12.60 |
| 32 |
532136321 |
RUNNER-RH This part replaces 532124950. Price: $7.99 |
| 33 |
532144729 |
MOWER HOUSING This part replaces 532121423. Price: $262.82 |
| 34 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 35 |
532123713 |
SPRING TORSION This part replaces 532106734. Price: $6.99 |
| 36 |
532110452 |
NUT PUSH M Price: $2.99 |
| 37 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532109743. Price: $2.99 |
| 38 |
532109785 |
DEFLECTOR SHIELD Price: $24.99 |
| 39 |
532126192 |
DECAL Price: $16.99 |
| 41 |
532126194 |
DECAL Price: $16.99 |
| 42 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 43 |
532025034 |
BLADE.106635X.44(NLA) This part replaces 532122265. Price: $19.99 |
| 46 |
532007631 |
RUNNER LH This part replaces 532125074. Price: $14.99 |
| 47 |
532123807 |
BRKT SUSP REAR RH Price: $12.33 |
| 48 |
532123808 |
BRKT SUSP REAR LH Price: $6.73 |
| 49 |
532108592 |
DECAL HYT Price: $7.00 |
| 50 |
532105185 |
DECAL-INST YT Price: $4.62 |
| 51 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 55 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 65 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 67 |
872140606 |
Bolt, Carriage 3/8-16 x 3/8 Price: $4.99 |
| 68 |
532102727 |
SPRING.EXT.8.5" Price: $6.99 |
| 72 |
532124949 |
LOCKNUT Price: $3.99 |
| 73 |
532109729 |
ROLLER T Price: $6.99 |
| 75 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 78 |
532121352 |
BELT RETIANER Price: $3.00 |
| 80 |
532126191 |
DECAL Price: $2.38 |
