| Ref | Part Number | Description |
|---|
| 1 |
532419272 |
Price: $259.99 |
| 2 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 2 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 3 |
873900500 |
NUT LOCK HEX FLANGE 5/16-18 Price: $2.99 |
| 4 |
532417645 |
Price: $2.99 |
| 4 |
98-7413 |
HOSE ASM Price: $110.10 |
| 5 |
58-4750 |
TUBE-STEEL Price: $198.58 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 6 |
532418863 |
ARMS.SUSP.MOWER.REAR.SRD Price: $4.99 |
| 6 |
93-1404 |
TUBE-STEEL Price: $147.37 |
| 7 |
532416358 |
SCREW.#10 X 0.750.BOS THREAD Price: $2.99 |
| 8 |
532420252 |
Price: $7.99 |
| 9 |
532199092 |
SPACER.RETAINER Price: $3.99 |
| 9 |
58-4780 |
TUBE-STEEL Price: $106.87 |
| 10 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.49 |
| 11 |
58-5710 |
HOSE ASM Price: $118.59 |
| 12 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $11.99 |
| 13 |
68-6370 |
HYD TUBE KIT Price: $324.47 |
| 13 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 14 |
532173968 |
KEEPER.BELT.IDLER.PLATED This part replaces 532156085. Price: $4.99 |
| 15 |
532146763 |
PULLEY.IDLER.4.25 Price: $14.99 |
| 15 |
58-3880 |
CLAMP-DOUBLE Price: $7.34 |
| 16 |
33113-050 |
SCREW-HH Price: $0.62 |
| 16 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 17 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 17 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 18 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 18 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 19 |
532110485 |
BEARING Price: $7.99 |
| 19 |
98-7408 |
HOSE ASM Price: $114.75 |
| 20 |
532173984 |
SCREW, WASHER HEAD Price: $2.99 |
| 20 |
58-4850 |
TUBE-STEEL Price: $194.71 |
| 21 |
532416910 |
Price: $11.99 |
| 21 |
68-6270 |
HYD TUBE KIT Price: $403.92 |
| 22 |
532175820 |
PULLEY.IDLER.FLAT.46.PR.DR. Price: $19.99 |
| 22 |
60-2180 |
ADAPTOR Price: $132.52 |
| 23 |
817490628 |
SCREW LT Price: $3.99 |
| 23 |
98-7406 |
HOSE ASM Price: $119.86 |
| 24 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 24 |
819132012 |
WASHER Price: $2.99 |
| 25 |
529311701 |
KEEPER-BELT-BLACK This part replaces 532420253. Price: $2.99 |
| 25 |
98-7411 |
HYD HOSE ASM Price: $96.07 |
| 26 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 26 |
532430313 |
Price: Call Us |
| 27 |
532419271 |
V-BELT.DRIVE.MOWER.30" Price: $39.99 |
| 27 |
98-7410 |
HOSE ASM Price: $111.58 |
| 28 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 29 |
105-9280 |
HOSE ASM Price: $144.00 |
| 29 |
532420895 |
Price: $2.99 |
| 30 |
98-7407 |
HOSE ASM Price: $115.22 |
| 31 |
106-9204 |
HOSE ASM Price: $143.37 |
| 32 |
532401872 |
SPRING RETURN Price: $2.99 |
| 32 |
58-4880 |
TUBE-STEEL Price: $236.51 |
| 33 |
532187281 |
HOUSING MANDREL Price: $20.99 |
| 33 |
98-7412 |
HOSE ASM Price: $105.37 |
| 34 |
532192870 |
MANDREL ASM This part replaces 532192872. Price: $30.99 |
| 34 |
58-4870 |
TUBE-STEEL Price: $136.43 |
| 35 |
532419274 |
BLADE.MOWER.BAGGING.30" Price: $19.99 |
| 35 |
98-7405 |
HOSE ASM Price: $114.18 |
| 36 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 36 |
60-1360 |
CLAMP-SINGLE Price: $5.97 |
| 37 |
33113-025 |
SCREW-HH Price: $1.97 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
340-70 |
NUT-LOCK Price: $2.10 |
| 38 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 39 |
48-7890 |
NUT-HEX Price: $0.25 |
| 40 |
340-115 |
FITTING-TEE, SWIVEL NUT Price: $56.09 |
| 40 |
532419270 |
Price: $11.99 |
| 41 |
532419265 |
Price: $11.99 |
| 42 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 43 |
525568001 |
PULLEY, MANDREL 6.5" BLK This part replaces 532416877. Price: $23.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $7.99 |
| 70 |
532198332 |
CLUTCH.ASM.MANUAL.LT.TEX Price: $51.99 |
| 72 |
532417236 |
Price: $48.99 |
| 73 |
532425274 |
Price: $40.99 |
| 74 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $19.99 |
