| Ref | Part Number | Description |
|---|
| 1 |
351-78 |
EDGING Price: $60.98 |
| 1 |
532411423 |
KIT.LEVER.CONTROL.RH.AUGER This part replaces 532184110. Price: $22.99 |
| 2 |
323-4 |
SCREW-HH Price: $1.02 |
| 2 |
532184109 |
LEVER, TRACTION DRIVE CONTROL Price: $9.99 |
| 3 |
532179439 |
NUT, CAGE 1/4-20 Price: $2.99 |
| 3 |
75-4370-03 |
BRACKET-SEAT This part replaces 75-4370. Price: $20.93 |
| 4 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 4 |
532178888 |
BUSHING, FLANGE Price: $3.99 |
| 5 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 5 |
92-8753 |
DISCONTINUED Price: Call Us |
| 6 |
532199640 |
SCREW HEX This part replaces 532180402. Price: $3.99 |
| 6 |
92-8001 |
SENSOR-SWITCH, REED Price: $86.02 |
| 7 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 7 |
532178652 |
ROD.INTERLOCK Price: $9.99 |
| 8 |
532184003 |
TUBE ASSM, INTERLOCK Price: $13.99 |
| 8 |
75-4360-03 |
BRACKET-SUSPENSION, SEAT This part replaces 75-4360. Price: $17.81 |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 9 |
532178651 |
TUBE.WELDMENT.INTERLOCK.LH Price: $20.99 |
| 10 |
532178645 |
PANEL, CONTROL This part replaces 532184106. Price: $22.99 |
| 10 |
93-0140 |
GROMMET-RUBBER Price: $3.94 |
| 11 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 11 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 12 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 12 |
874780528 |
SCREW Price: $4.99 |
| 13 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 13 |
532436114 |
TUBE.HANDLE.LOOP.LH.BLACK This part replaces 532184107. Price: $54.99 |
| 14 |
322-3 |
SCREW-HH Price: $0.79 |
| 14 |
532407857 |
TUBE.HANDLE.LOOP.RH.BLACK This part replaces 532184108. Price: $39.99 |
| 15 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 15 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 16 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350. Price: $166.30 |
| 16 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 17 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 17 |
93-8060 |
DECAL-REELS Price: $53.80 |
| 18 |
2412-93 |
CLAMP-R Price: $1.02 |
| 18 |
532184594 |
ROD.AUGER.CONTROL Price: $54.99 |
| 19 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 19 |
532193081 |
ROD.CABLE.TRACTION.LONG Price: $11.99 |
| 20 |
532180428 |
ROD, END CONTROL Price: $8.99 |
| 20 |
75-3680-03 |
ROD-SEAT This part replaces 75-3680. Price: $38.90 |
| 21 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
596436301 |
Nuts This part replaces 873350500. Price: $2.99 |
| 22 |
32121-38 |
PIN-ROLL Price: $0.53 |
| 22 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $5.99 |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
532184087 |
TUBE.LOWER.HANDLE.24.BLACK Price: $59.99 |
| 24 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 24 |
98-9303 |
CABLE-THROTTLE Price: $21.41 |
| 25 |
25-8640 |
SCREW-HH Price: $1.09 |
| 25 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 26 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 26 |
93-0021 |
SWIVEL-CABLE, THROTTLE Price: $33.15 |
| 27 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 27 |
871210616 |
Screw, Hex Head 3/8-16 x 1 Price: $4.99 |
| 28 |
532180494 |
PANEL CLIP Price: $2.64 |
| 28 |
98-2352-03 |
FRAME-SEAT This part replaces 98-2352. Price: $456.00 |
| 29 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 30 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 30 |
532183346 |
PANEL.CONSOLE.HEADLIGHTS Price: $29.99 |
| 31 |
321-4 |
SCREW-HH Price: $0.99 |
| 31 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 32 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 32 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 33 |
532184111 |
ARM.LATCH.INTERLOCK.YELLOW Price: $3.99 |
| 33 |
75-3430-03 |
LEVER-THROTTLE This part replaces 75-3430. Price: $29.18 |
| 34 |
233-42 |
KNOB Price: $12.88 |
| 34 |
532183518 |
BOLT, SHOULDER Price: $2.99 |
| 35 |
873850400 |
This part replaces 532068038. Price: $2.51 |
| 35 |
98-2354-03 |
LATCH-SEAT This part replaces 98-2354. Price: $41.34 |
| 36 |
532443215 |
SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
| 36 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 37 |
532178658 |
SPRING, INTERLOCK Price: $2.99 |
| 37 |
66-4190 |
SPRING-IDLER, CLUTCH Price: $10.15 |
| 38 |
32128-25 |
NUT-HF Price: $3.19 |
| 38 |
532178666 |
HEADLIGHT.HALOGEN.SNOW Price: $219.99 |
| 39 |
110-9730 |
SEAT SUSPENSION ASM This part replaces 75-3000. Price: $776.63 |
| 39 |
532178668 |
BEZEL.HEADLIGHT.BLACK Price: $5.99 |
| 40 |
351-80 |
CLIP Price: $8.87 |
| 41 |
98-9341 |
DISCONTINUED Price: Call Us |
| 41 |
98-9342 |
DECAL-SOLENOID, INFORMATION Price: $69.36 |
| 42 |
2412-133 |
CLAMP-R Price: $3.19 |
| 43 |
92-6534 |
ORDER COMPLETE SEAT Price: Call Us |
| 44 |
92-6533 |
SEAT CUSHION KIT Price: $290.43 |
| 45 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 46 |
63-9920 |
DISCONTINUED Price: Call Us |
| 47 |
92-5524 |
DISCONTINUED Price: Call Us |
| 49 |
98-9302 |
PLATE-STOP, IDLER Price: $12.42 |
| 50 |
112-0169 |
SEATBELT ASM-SERVICE This part replaces 21-4191. Price: $283.31 |
| 51 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 52 |
3212-4 |
SCREW-HH Price: $2.73 |
| 53 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
