| Ref | Part Number | Description |
|---|
| 1 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7580. Price: $27.95 |
| 3 |
3218-5 |
NUT-JAM Price: $0.27 |
| 4 |
21-2850-01 |
MOUNT-PEDAL, RH This part replaces 21-2850. Price: $69.64 |
| 5 |
32144-102 |
SCREW-HWH This part replaces 11-0590. Price: $3.19 |
| 6 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 7 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 8 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 9 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 10 |
82-8670 |
ROD-LATCH, BRAKE Price: $61.33 |
| 11 |
233-17 |
KNOB Price: $10.58 |
| 11 |
532174509 |
CLUTCH KIT This part replaces 532170056. Price: $449.99 |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 12 |
82-8930 |
DECAL-BRAKE, PARKING Price: $24.40 |
| 13 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 14 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 15 |
108-1380 |
LH BRAKE CABLE ASM This part replaces 21-3380. Price: $162.33 |
| 15 |
532151346 |
FUEL TANK 3.5G Price: $84.99 |
| 16 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 16 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 17 |
23-2240-03 |
PUMP CONTROL TUBE ASM This part replaces 23-2240. Price: $209.72 |
| 17 |
532106082 |
PAD-SPACER LT Price: $3.99 |
| 18 |
532161493 |
CAP, FUEL GUAGE Price: $30.99 |
| 18 |
88-0530 |
DISCONTINUED Price: Call Us |
| 19 |
88-1740 |
PAD-PEDAL, REAR Price: $2.80 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 20 |
88-1640 |
PIN-PEDAL, TRACTION Price: $17.64 |
| 21 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532164863. Price: $14.99 |
| 22 |
532175440 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532178639. Price: $27.99 |
| 22 |
88-1650 |
SHAFT-PEDAL, TRACTION Price: $55.18 |
| 23 |
88-1670 |
PIVOT BRACKET ASM Price: $109.29 |
| 24 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 24 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 25 |
28-5220 |
FRICTION WHEEL ASM Price: $108.15 |
| 25 |
873920600 |
Nut Keps 3/8-24 Unf Price: $3.99 |
| 26 |
21-0141 |
RH BALL JOINT ASM Price: $109.12 |
| 26 |
532003645 |
BUSHING OUTLET T Price: $3.99 |
| 27 |
3220-3 |
NUT-HJ Price: $0.28 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 28 |
3217-7 |
NUT-HEX Price: $0.28 |
| 28 |
532008542 |
FUEL LINE 42" This part replaces 532007834. Price: $5.99 |
| 29 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 31 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 32 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 33 |
3274-47 |
SCREW-HSFH Price: $0.53 |
| 34 |
27-7590-01 |
BRAKE MT WA This part replaces 27-7590. Price: $239.14 |
| 35 |
27-9270-01 |
PIVOT SHAFT MOUNT ASM This part replaces 27-9270. Price: $81.41 |
| 35 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 36 |
27-7640-01 |
SHAFT-BRAKE LATCH ASM This part replaces 27-7640. Price: $62.42 |
| 37 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7570. Price: $27.95 |
| 39 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 UNC Price: $3.99 |
| 41 |
27-7490 |
LH BRAKE PEDAL ASM Price: $347.33 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
27-7510 |
RH BRAKE PEDAL ASM Price: $321.91 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
256-10 |
BUSHING-FLANGE Price: $3.68 |
| 43 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 44 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 45 |
27-8550-01 |
PARKING BRAKE PEDAL ASM This part replaces 27-8550. Price: $324.09 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
3220-5 |
NUT-JAM Price: $0.65 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 47 |
88-1730 |
PAD-PEDAL, FRONT Price: $7.33 |
| 48 |
88-1680-01 |
BRACKET-FOOTREST This part replaces 88-1680. Price: $17.86 |
| 49 |
88-0470 |
TUBE-SPACER, PEDAL Price: $10.25 |
| 50 |
88-1710-01 |
FOOTREST ASM This part replaces 88-1710. Price: $62.29 |
| 51 |
88-1720 |
PAD-FOOTREST Price: $5.27 |
| 52 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532176069 |
TUBE.EXHAUST.B&S.VGT.LH Price: $51.99 |
| 71 |
532176070 |
TUBE.EXHAUST.B&S.VGT.RH Price: $64.99 |
| 74 |
532162295 |
ELBOW STREET BRASS Price: $29.99 |
| 79 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532148315. Price: $14.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
