| Ref | Part Number | Description |
|---|
| 1 |
321-5 |
SCREW-HH Price: $0.22 |
| 2 |
2412-106 |
CLAMP-R Price: $2.04 |
| 2 |
590645302 |
MUFFLER.ASM.SINGLE This part replaces 532446760. Price: $39.99 |
| 4 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 6 |
92-6059 |
PLUG-BUTTON Price: $0.88 |
| 7 |
92-9273-03 |
CONSOLE-CENTER Price: $4,636.98 |
| 8 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 9 |
582540302 |
KEEPER.BELT.ENG.3.25"2BOLT.PNT Price: $6.99 |
| 12 |
33113-016 |
SCREW-HH Price: $0.34 |
| 12 |
586729001 |
PULLEY.ENGINE This part replaces 532401985. Price: $27.99 |
| 13 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA Price: $99.99 |
| 15 |
68-6150 |
BREATHER Price: $27.22 |
| 16 |
98-3844 |
BREATHER TUBE ASM Price: $93.59 |
| 17 |
237-65 |
O-RING Price: $2.50 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 20 |
93-9406 |
DECAL-GLASS, SIGHT Price: $28.02 |
| 21 |
58-5940 |
PLUG-GAGE, SIGHT Price: $184.36 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
48-6900 |
SCREW Price: $1.52 |
| 23 |
92-5682 |
STRIP-SEALING Price: $20.71 |
| 25 |
58-0980-01 |
MUDGUARD-LH Price: $432.91 |
| 26 |
93-9407 |
DECAL-LEVER, LIFT Price: $17.21 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
93-9425 |
DECAL-DANGER Price: $28.20 |
| 32 |
93-9408 |
DECAL-OPERATION WARNING Price: $73.30 |
| 33 |
68-7840 |
STRIP-SEALING Price: $19.08 |
| 34 |
340-117 |
CAP Price: $10.30 |
| 35 |
92-5694 |
HOSE-HYDRAULIC Price: $92.15 |
| 36 |
237-79 |
O-RING Price: $5.46 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
58-1750-03 |
PANEL-ACCESS Price: $270.79 |
| 38 |
92-4746-01 |
MUDGUARD-RH Price: $452.39 |
| 39 |
237-22 |
O-RING Price: $2.43 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 42 |
92-4799 |
FITTING-TEE, HYD Price: $159.71 |
| 44 |
48-7890 |
NUT-HEX Price: $0.25 |
| 45 |
321-24 |
SCREW-HH Price: $2.31 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
237-80 |
O-RING Price: $6.10 |
| 47 |
58-9160 |
PLUG-DRAIN Price: $23.70 |
| 48 |
68-7810 |
PANEL-LINING Price: $140.77 |
| 49 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 50 |
48-7120 |
ELEMENT-SUCTION Price: $153.05 |
| 52 |
3250-36 |
SCREW-PPH Price: $2.41 |
| 53 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE Price: $27.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
