| Ref | Part Number | Description |
|---|
| 1 |
618-3189 |
PTO CLUTCH ASSEMBLY Not Available Price: |
| 1 |
74-9080 |
DISCONTINUED Price: Call Us |
| 2 |
919-3076B |
REAR COVER PLATE Not Available This part replaces 619-3076A. Price: |
| 3 |
323-9 |
SCREW-HH Price: $1.29 |
| 3 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 4 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 4 |
710-1238A |
SCREW 5/16-18 x .875 GR5 HXFLG HD This part replaces 710-1238. Price: $3.74 |
| 5 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 5 |
710-3006 |
SCREW .375 x 5/16-18 Not Available Price: |
| 6 |
32148-10 |
NUT-CLINCH Price: $1.29 |
| 6 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .5 GR5 Price: $4.02 |
| 7 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
710-3118 |
Screw, Hex Cap Lock, 3/8-16 x 1.0 GR5 Price: $4.77 |
| 8 |
323-5 |
SCREW-HH This part replaces 323-33. Price: $0.41 |
| 8 |
710-04003A |
SCREW 6MM x 40MM Not Available This part replaces 710-04003. Price: |
| 9 |
130-2486 |
MOUNT This part replaces 53-9681. Price: $36.47 |
| 9 |
711-1325 |
PTO SHAFT Not Available Price: |
| 10 |
74-5470-03 |
MOUNT-ENGINE, LH This part replaces 74-5470. Price: $44.48 |
| 10 |
911-1337A |
INPUT CLUTCH SHAFT Not Available This part replaces 711-1337. Price: |
| 11 |
33115-100 |
SCREW-HH This part replaces 48-7840. Price: $1.57 |
| 11 |
711-1345 |
SHAFT-2000 PTO Not Available Price: |
| 12 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 12 |
711-1371 |
PTO BACK SHAFT Not Available Price: |
| 13 |
32128-37 |
NUT-HF Price: $3.63 |
| 13 |
711-1373 |
PTO ACTUATOR SHAFT Not Available Price: |
| 14 |
716-0180 |
Ring, Retaining Price: $10.38 |
| 14 |
87-5100 |
WASHER-SNUBBING Price: $3.46 |
| 15 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 15 |
716-0200 |
RETAINING RING Not Available Price: |
| 16 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 16 |
716-0201 |
RETAINING RING Not Available Price: |
| 17 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 17 |
716-0384 |
Ring, Retaining Price: $3.74 |
| 18 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 18 |
716-0393 |
RETAINING RING Not Available Price: |
| 19 |
33114-030 |
SCREW-HH This part replaces 48-7730. Price: $0.50 |
| 19 |
716-0397 |
RETAINING RING Not Available Price: |
| 20 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 20 |
716-3001 |
Ring, Retaining Price: $3.96 |
| 21 |
717-3469 |
GEAR 81T Not Available Price: |
| 21 |
76-4120-03 |
MOUNT-ENGINE, RH This part replaces 76-4120. Price: $79.57 |
| 22 |
48-7810 |
SCREW Price: $7.98 |
| 22 |
917-3479A |
AUX DRIVE GEAR 28T Not Available This part replaces 717-3479. Price: |
| 23 |
48-7570 |
SCREW-HH Price: $8.48 |
| 23 |
717-3487 |
PTO GEAR 61T Not Available Price: |
| 24 |
84-0760-03 |
ADAPTER-PUMP This part replaces 84-0760. Price: $876.02 |
| 24 |
917-3490A |
AUX DRIVE PINION 28T Not Available This part replaces 717-3490. Price: |
| 25 |
917-3491A |
AUX DRIVE GEAR 32T Not Available This part replaces 717-3491. Price: |
| 25 |
93-5398 |
SCREW-HH Price: $3.22 |
| 26 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 26 |
717-3492 |
PTO GEAR 14T Not Available Price: |
| 27 |
322-3 |
SCREW-HH Price: $0.79 |
| 27 |
717-3494B |
Gear, 2000 PTO Pinion: 54T Price: Call Us |
| 28 |
717-3500 |
PTO GEAR 34T Not Available Price: |
| 28 |
74-3650 |
FAN Price: $269.64 |
| 29 |
114-3988 |
FAN DRIVE ASM This part replaces 74-5520. Price: $342.27 |
| 29 |
718-0668 |
SPLINE GEAR COUPLING Not Available Price: |
| 30 |
718-0681 |
PTO COVER Not Available Price: |
| 30 |
76-4220-03 |
MOUNT-ENGINE, LH This part replaces 76-4220. Price: $127.64 |
| 31 |
718-3116 |
Collar, 2 Speed Price: $77.88 |
| 32 |
33115-025 |
SCREW-HH This part replaces 48-7780. Price: $0.61 |
| 32 |
718-3134 |
PTO COUPLING Not Available Price: |
| 33 |
84-1440 |
DISCONTINUED Price: Call Us |
| 33 |
919-0551A |
PTO ACTUATOR Not Available This part replaces 719-0551A. Price: |
| 34 |
33113-012 |
SCREW-HH This part replaces 48-7610. Price: $0.71 |
| 34 |
721-0496 |
Seal, Oil Price: $9.52 |
| 35 |
721-0497 |
OIL SEAL Price: $12.92 |
| 35 |
77-3600 |
SHIELD-ADAPTER Price: $24.35 |
| 36 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 36 |
721-0500 |
O-RING Not Available Price: |
| 37 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 37 |
721-0504 |
OIL PLUG Not Available Price: |
| 38 |
721-0509 |
OIL SEAL Not Available Price: |
| 38 |
76-4310-03 |
SUPPORT-BASE, BATTERY This part replaces 76-4310. Price: $22.33 |
| 39 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 39 |
921-3020A |
Seal, Oil, 1.18 ID This part replaces 721-3020A. Price: $10.75 |
| 40 |
14-0949 |
BATTERY BASE WA *B Price: $97.58 |
| 40 |
732-0187 |
COMPRESSION SPRING Not Available Price: |
| 41 |
323-4 |
SCREW-HH Price: $1.02 |
| 41 |
932-05125 |
DETENT SHAFT SPRING This part replaces 732-0863. Price: $3.66 |
| 42 |
100-3794 |
DISCONTINUED This part replaces 93-4233. Price: Call Us |
| 42 |
732-0980 |
COMPRESSION SPRING Not Available Price: |
| 43 |
736-0355 |
Washer, Flat, .56 x 1.0 x .040 ... Not Available Price: |
| 43 |
94-5615 |
BRACKET-HOSE, RETURN Price: $58.90 |
| 44 |
53-9682 |
MOUNT-ENGINE Price: $108.69 |
| 44 |
736-0463 |
Washer, Flat, .25 x .630 x .0515 Price: $3.91 |
| 45 |
736-0615 |
Washer, Thrust, 1.007 x 1.542 x .03 Price: $8.02 |
| 46 |
741-0724 |
SLEEVE BEARING Not Available Price: |
| 47 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 48 |
741-0991 |
SLEEVE BEARING Not Available Price: |
| 49 |
741-1100 |
Bearing, Ball Price: $33.54 |
| 50 |
741-1118 |
NEEDLE BEARING Not Available Price: |
| 51 |
941-3033A |
Bearing, Ball This part replaces 741-3033A. Price: $50.07 |
| 52 |
941-3037 |
Bearing, Ball This part replaces 741-3037. Price: $38.73 |
| 53 |
941-3057 |
Bearing, Ball, 20x47x14, 6204 This part replaces 741-3057. Price: $35.46 |
| 54 |
741-3083 |
Bearing, Needle Thrust Price: $14.74 |
| 55 |
748-3094 |
ARM-PTO SELECT Not Available Price: |
| 56 |
750-1223 |
SPACER Not Available Price: |
| 57 |
750-1228 |
SPACER Not Available Price: |
| 58 |
936-0570 |
FLAT WASHER Not Available This part replaces 736-0570. Price: |
| 501072001 |
501072001 |
Price: Call Us |
| 501072107 |
501072107 |
Price: Call Us |
| 501834401 |
501834401 |
Price: Call Us |
| 501873501 |
501873501 |
CHAIN GUIDE PLATE Price: $5.54 |
| 505698100 |
596285101 |
DEPTH GAUGE FILING GAUGE DEPTH This part replaces 505698100. Price: $6.99 |
