| Ref | Part Number | Description |
|---|
| 1 |
3274-71 |
SCREW-HSH Price: $2.71 |
| 1 |
581505301 |
DECK SVC MZT 52 W/DECALS.ORNG Price: $1,299.00 |
| 2 |
522811301 |
BELT, B, 148.5 Price: $79.99 |
| 3 |
539112079 |
BLADE, 18" Price: $22.99 |
| 4 |
539112170 |
MANDREL.DECK.ASSEMBLY Price: $69.99 |
| 4 |
86-5620 |
BEARING-BALL, 2 BOLT FLANGE Price: $103.16 |
| 5 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 5 |
84-1320-03 |
SHAFT-PTO This part replaces 84-1320. Price: $276.98 |
| 6 |
100-2592 |
SCREW-HHF This part replaces 66-9303. Price: $9.09 |
| 6 |
596841501 |
Bushings This part replaces 539112169. Price: $7.99 |
| 7 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 7 |
539112198 |
IDLER ARM Price: $27.99 |
| 8 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 8 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 9 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 9 |
86-5470 |
DISCONTINUED Price: Call Us |
| 10 |
2412-109 |
CLIP-J Price: $3.82 |
| 10 |
539112242 |
BELT SHIELD, RIGHT 52, ORG Price: $54.99 |
| 11 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 11 |
539112244 |
BELT SHIELD, LEFT 52, ORG Price: $54.99 |
| 12 |
325-14 |
SCREW-HH Price: $2.64 |
| 12 |
584859402 |
BRACKET.RT.PNT.MS431 Price: $3.99 |
| 13 |
106-1061 |
CLUTCH ADAPTER KIT This part replaces 84-1410. Price: $263.30 |
| 13 |
584859404 |
BRACKET.LH.PNT.MS431 Price: $3.99 |
| 14 |
539110733 |
DISCHARGE CHUTE 52" Price: $44.99 |
| 14 |
92-5818-03 |
HOUSING This part replaces 92-5818. Price: $554.35 |
| 15 |
593565003 |
PLATE CONFINEMENT 52" PLATE.PN This part replaces 539112417. Price: $27.99 |
| 15 |
88-1140 |
SPACER-BEARING, LOWER Price: $16.29 |
| 16 |
251-310 |
BEARING-BALL Price: $140.09 |
| 16 |
532110485 |
BEARING Price: $11.99 |
| 17 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 17 |
84-0180 |
DISCONTINUED Price: Call Us |
| 18 |
539103256 |
SPRING Price: $9.99 |
| 18 |
84-1540 |
KEY-CLUTCH Price: $18.26 |
| 19 |
596646001 |
Springs This part replaces 539110735. Price: $3.99 |
| 19 |
88-1170 |
V-BELT (MATCHED SET) Price: $105.24 |
| 20 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 21 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 21 |
84-1570 |
SPACER-PLATE Price: $14.75 |
| 22 |
596565501 |
Nuts This part replaces 539131859. Price: $9.99 |
| 22 |
84-1550 |
MOUNT-RUBBER Price: $27.49 |
| 23 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 23 |
88-1510 |
SCREW-SPECIAL Price: $9.28 |
| 24 |
3234-22 |
SCREW-HHF Price: $2.69 |
| 24 |
581606002 |
BRACKET MZ CHUTE Price: $9.99 |
| 25 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 26 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 26 |
84-1560 |
WASHER-THRUST Price: $2.71 |
| 27 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 27 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 28 |
32128-49 |
NUT-HHF Price: $1.04 |
| 28 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 29 |
325-9 |
SCREW-HH Price: $1.87 |
| 29 |
596437101 |
Screws This part replaces 539108396. Price: $2.99 |
| 30 |
596564405 |
Bolts This part replaces 874780648. Price: $2.99 |
| 30 |
88-1450 |
LOCKNUT-BEARING Price: $32.99 |
| 31 |
596580801 |
Bolts This part replaces 874780516. Price: $2.99 |
| 31 |
94-5623 |
MAIN HARNESS Price: $1,410.45 |
| 32 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 32 |
88-1460 |
WASHER-LOCK Price: $13.85 |
| 33 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 33 |
88-1150 |
SPACER-CLUTCH Price: $31.20 |
| 34 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 34 |
92-5817 |
PIN-STOP, CLUTCH Price: $18.86 |
| 35 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 35 |
88-1280 |
COVER-BELT, LOWER Price: $156.55 |
| 36 |
3256-70 |
WASHER-FLAT Price: $0.25 |
| 36 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 37 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 539107522. Price: $6.99 |
| 37 |
98-7254 |
KIT - CLUTCH REPLACEMENT This part replaces 86-5610. Price: $2,193.47 |
| 38 |
596434404 |
Bolts This part replaces 532137644. Price: $4.99 |
| 38 |
84-1580 |
WASHER-CLUTCH Price: $30.33 |
| 39 |
3234-18 |
SCREW-HHF Price: $0.87 |
| 39 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 40 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
86-3040 |
COUPLER-LINE, DRIVE Price: $381.88 |
| 41 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 41 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 42 |
596582601 |
Nuts This part replaces 539990196. Price: $2.99 |
| 42 |
86-1990 |
WASHER-THRUST Price: $1.81 |
| 43 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 43 |
596134801 |
Nuts This part replaces 539107590. Price: $1.00 |
| 44 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 44 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 45 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 45 |
88-8950 |
DECAL-WARNING Price: $12.65 |
| 46 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 47 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 48 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 50 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810030500. Price: $2.99 |
| 51 |
596433701 |
GSPW Washers This part replaces 819141614. Price: $2.99 |
| 52 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 539107520. Price: $3.99 |
