| Ref | Part Number | Description |
|---|
| 6 |
131-4138 |
BRACKET-HANGER, RH Price: $8.65 |
| 7 |
131-1091 |
BRACKET-HANGER, LH Price: $10.00 |
| 8 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 9 |
120-7024 |
SCREW-SHOULDER,HWH Price: $1.31 |
| 10 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 11 |
110-0618 |
PIN-CLEVIS Price: $1.42 |
| 12 |
131-0955 |
ROD-LEVEL, DECK Price: $4.64 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 15 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 16 |
1-806003 |
PIN-COTTER Price: $1.39 |
| 19 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 20 |
133-9289 |
FITTING-WASHOUT Price: $3.86 |
| 25 |
119-8877-03 |
RAMP-DEFLECTOR Price: $10.93 |
| 28 |
119-8858 |
ROD-PIVOT Price: $16.72 |
| 30 |
119-0368 |
SPINDLE HOUSING ASM Price: $100.42 |
| 31 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 32 |
119-8825 |
SHAFT-SPINDLE Price: $31.76 |
| 33 |
80-4430-03 |
BLADE-RECYCLER, 31.35 INCH Price: $37.20 |
| 34 |
3290-465 |
WASHER-BELLEVILLE Price: $2.89 |
| 35 |
26-0671 |
SCREW-HH Price: $7.99 |
| 36 |
119-8804 |
PULLEY-DECK Price: $41.76 |
| 37 |
3219-7 |
NUT-HEX Price: $1.53 |
| 38 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 39 |
120-2229 |
WASHER Price: $1.27 |
| 40 |
114-0463 |
WASHER-FRICTION, COMPOSITE Price: $4.79 |
| 41 |
115-4986 |
SPACER Price: $1.39 |
| 42 |
119-8966 |
ARM-IDLER Price: $30.06 |
| 43 |
132-9420 |
PULLEY-IDLER, FLAT Price: $25.16 |
| 44 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 45 |
323-11 |
SCREW-HH Price: $1.08 |
| 46 |
119-8821 |
V-BELT, 81.8 INCH Price: $54.71 |
| 47 |
106-2177 |
SPRING-EXTENSION Price: $9.92 |
| 48 |
138-7267 |
HOOK-SPRING, RETURN This part replaces 88-5970. Price: $1.12 |
| 50 |
92-2493 |
SPRING-TORSION Price: $7.71 |
| 56 |
119-2368 |
DECAL-RECYCLER Price: $3.60 |
| 59 |
88-4540 |
PIVOT-HINGE, DEFLECTOR Price: $14.47 |
| 60 |
88-6160 |
SPRING-TORSION Price: $22.55 |
| 61 |
92-8916 |
BOLT-SHOULDER Price: $14.99 |
| 62 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 63 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 64 |
138-7270 |
GUIDE-BELT, IDLER This part replaces 107-7307. Price: $1.69 |
| 65 |
323-7 |
SCREW-HH Price: $0.65 |
| 66 |
322-3 |
SCREW-HH Price: $0.79 |
| 67 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 69 |
80-2630-03 |
KICKER Price: $21.21 |
| 70 |
322-6 |
SCREW-HH Price: $0.45 |
| 71 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 72 |
82-6151 |
DISCHARGE COVER ASM Price: $78.46 |
| 73 |
131-3669 |
ROD-SUPPORT, UPPER Price: $13.32 |
| 74 |
131-3681 |
ROD-SUPPORT, LOWER Price: $14.66 |
| 75 |
131-3685 |
GUARD-SIDE Price: $16.40 |
| 76 |
131-3666-03 |
SHIELD-FRONT Price: $13.31 |
| 77 |
3274-55 |
SCREW-HSBH Price: $3.19 |
| 78 |
1-803037 |
NUT-RETAINING Price: $1.39 |
| 83 |
80-4490-03 |
RING-DECK Price: $12.87 |
| 85 |
32103-2 |
NUT-WING Price: $0.68 |
