| Ref | Part Number | Description |
|---|
| 1 |
136-0381 |
BOOM-LH Price: $460.17 |
| 1 |
532140064 |
SPRING-MOWER CLUTCH Price: $14.99 |
| 2 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 3 |
108-3725 |
LH SINGLE BODY TURRET ASM Price: $57.64 |
| 3 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 4 |
108-3727 |
DOUBLE TURRET BODY ASM Price: $57.64 |
| 4 |
531165101 |
SERVICE KIT BRAKE ASSEMBLY BRA This part replaces 532130840. Price: $6.99 |
| 5 |
108-3726 |
RH SINGLE BODY TURRET ASM Price: $57.64 |
| 5 |
532131251 |
IDLER BELT GUIDE Price: $3.99 |
| 6 |
532121316 |
PULLEY.IDLER.FLAT.MOWER.BLK.PT Price: $44.99 |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 8 |
596134901 |
GSPH This part replaces 819131410. Price: $2.99 |
| 9 |
108-3439 |
TEE Price: $10.76 |
| 9 |
532140092 |
IDLER ARM ASSY This part replaces 532127744. Price: $8.78 |
| 10 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 10 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 11 |
161-4174 |
CRADLE ASM This part replaces 130-8238-03. Price: $56.88 |
| 11 |
532130841 |
BRAKE ROD Price: $24.99 |
| 12 |
110-5050 |
SCREW-HHF Price: $2.59 |
| 12 |
532127356 |
BRKT LIFT REAR Price: $3.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 14 |
108-3476-03 |
CRADLE-UPPER Price: $84.74 |
| 14 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 15 |
108-3457 |
SPACER Price: $21.03 |
| 15 |
532127357 |
BRKT LIFT REAR LH Price: $4.99 |
| 16 |
108-3742 |
SCREW-HHF Price: $1.90 |
| 16 |
532153298 |
BELT KEEPER Price: $11.99 |
| 17 |
108-3489 |
CAP-TUBE Price: $3.25 |
| 17 |
532128508 |
MOWER LINK STABILIZER Price: $41.84 |
| 18 |
110-5052 |
SCREW-HHF Price: $1.22 |
| 18 |
532128511 |
PIN GROOVE Price: $2.99 |
| 19 |
108-3495 |
COVER-SLIDE Price: $98.16 |
| 19 |
532127380 |
BRKT LINK STABILIIZER Price: $7.99 |
| 20 |
108-3743 |
WASHER Price: $2.31 |
| 20 |
532138496 |
BLADE, HI-LIFT 36" PREMIUM Price: $22.99 |
| 21 |
108-3744 |
SCREW-SHOULDER Price: $9.60 |
| 21 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 22 |
114-9566 |
CLAMP-R Price: $2.78 |
| 22 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 23 |
532850857 |
BLADE BOLT Price: $3.99 |
| 23 |
95-9186 |
CAP Price: $7.89 |
| 24 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 24 |
95-9187 |
CAP-BLANK Price: $10.69 |
| 25 |
108-3735 |
HOSE-BOOM, CENTER (LH) Price: $43.48 |
| 25 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532157722. Price: $3.99 |
| 27 |
3256-68 |
WASHER-FLAT Price: $2.69 |
| 27 |
532174082 |
DECK SVCX1 KIT MOWER.36.LR This part replaces 532156600. Price: $119.99 |
| 28 |
110-5070 |
BUMPER Price: $10.00 |
| 28 |
532173434 |
MANDREL PULLEY This part replaces 532153531. Price: $14.99 |
| 29 |
127-8955-03 |
MOUNT-BOOM Price: $64.84 |
| 29 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 30 |
127-8956-03 |
MOUNT-BOOM Price: $69.93 |
| 30 |
532136631 |
BRACKET ASM DEFLECTOR Price: $9.99 |
| 31 |
110-5057 |
CAPSCREW-HHF Price: $2.71 |
| 31 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 32 |
108-3745 |
NUT-HHF, WHIZ Price: $1.15 |
| 32 |
532122051 |
SUPT,IDLER ARM Price: $4.99 |
| 33 |
137-1673 |
BRACKET-PIVOT This part replaces 119-4993-03. Price: $270.35 |
| 33 |
532171156 |
NEEDS DESCRIPTION Price: Call Us |
| 34 |
137-1674 |
HINGE This part replaces 108-3471-03. Price: $86.08 |
| 35 |
100-8541 |
BUSHING-A ARM Price: $3.49 |
| 36 |
108-3436 |
PIN-CLEVIS Price: $44.88 |
| 36 |
593885101 |
Rods This part replaces 532121980. Price: $5.99 |
| 37 |
3290-468 |
PIN-COTTER Price: $0.95 |
| 37 |
532123713 |
SPRING TORSION Price: $6.99 |
| 38 |
110-5054 |
WASHER-FLAT Price: $1.75 |
| 38 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 39 |
108-3738 |
SCREW-HH Price: $14.09 |
| 39 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 40 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 40 |
532110452 |
NUT PUSH M Price: $2.99 |
| 41 |
108-3419 |
PIVOT PIN ASM Price: $49.14 |
| 41 |
532131264 |
BELT This part replaces 531005026. Price: $34.99 |
| 42 |
108-3605 |
PLATE-BACKING Price: $9.08 |
| 42 |
596040101 |
Washers This part replaces 819171616. Price: $2.99 |
| 43 |
108-3444 |
RETAINER-SPRING Price: $23.03 |
| 43 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 44 |
108-3440 |
SPRING-BREAKAWAY, BOOM Price: $20.19 |
| 45 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 45 |
532110485 |
BEARING Price: $11.99 |
| 46 |
108-3459 |
BOOT-HINGE Price: $16.67 |
| 46 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 47 |
120-8541 |
DAMPENER-HINGE Price: $15.09 |
| 47 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $9.99 |
| 48 |
108-3748 |
SCREW-HHF Price: $1.90 |
| 48 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 49 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 49 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 50 |
133-0412-03 |
CENTER-CENTER, BOOM Price: $263.10 |
| 52 |
136-0382 |
BOOM-RH Price: $460.17 |
| 53 |
136-0438 |
HOSE-FORMED Price: $30.00 |
| 54 |
108-3728 |
HOSE-BOOM Price: $17.99 |
| 62 |
532153390 |
WASHER FELT Price: $3.99 |
