| Ref | Part Number | Description |
|---|
| 1 |
5305 |
HOUSING UPPER Price: Call Us |
| 1 |
92-9200 |
COVER Price: $276.63 |
| 2 |
1919 |
SCREW Price: Call Us |
| 2 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 3 |
5112 |
BALL, DETENT Price: Call Us |
| 3 |
60-2160 |
R-CLIP ASM Price: $8.47 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
3626 |
SPRING, DETENT Price: Call Us |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
3623 |
SCREW, SET Price: Call Us |
| 6 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 6 |
4604 |
KIT, SHIFTER ASSEMBLY Price: Call Us |
| 7 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 7 |
5024 |
BOOT, SHIFTER Price: Call Us |
| 8 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 8 |
3907 |
PUCK, FRICTION Price: Call Us |
| 9 |
5131 |
SCREW TAPPING WITH SEALER Price: Call Us |
| 9 |
58-1650 |
ROD-SEAT Price: $110.80 |
| 10 |
1099 |
RING RETAINING Price: Call Us |
| 10 |
82-9340 |
LEVEL SWITCH ASM Price: $201.99 |
| 11 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 11 |
4689 |
ASSY, KIT, SHIM .625 SHAFT Price: Call Us |
| 12 |
3707 |
GEAR SPUR, 15 TEETH Price: Call Us |
| 12 |
55-4660 |
ARMREST Price: $488.24 |
| 13 |
3876 |
WASHER, PLAIN .632 X 1.38 X .046 Price: Call Us |
| 13 |
56-3850 |
SCREW Price: $3.37 |
| 14 |
115-2030 |
SEAT KIT - RM4000 This part replaces 77-4860. Price: $1,616.82 |
| 14 |
1374 |
KEY WOODRUFF #9 Price: Call Us |
| 15 |
4171 |
ASSY KIT INPUT SHAFT Price: Call Us |
| 15 |
46-0670 |
SCREW-PPH Price: $1.89 |
| 16 |
3725 |
PINION BEVEL 14 TEETH Price: Call Us |
| 17 |
3624 |
RING, RETAINING Price: Call Us |
| 18 |
3625 |
CHAIN, 24 PITCHES Price: Call Us |
| 19 |
1542 |
BEARING, FLANGE Price: Call Us |
| 19 |
60-5580 |
SWITCH-TEMPERATURE Price: $178.50 |
| 20 |
323-7 |
SCREW-HH Price: $0.65 |
| 20 |
5280 |
GEAR Price: Call Us |
| 21 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 21 |
5303 |
COLLAR, CLUTCH Price: Call Us |
| 22 |
32128-21 |
NUT-HF Price: $0.39 |
| 22 |
4760 |
ASSY KIT CLUTCH KEYS Price: Call Us |
| 23 |
5278 |
BEARING FL Price: Call Us |
| 23 |
93-6686 |
DECAL-OIL, HYD Price: $7.01 |
| 24 |
5299 |
SHAFT INTERMEDIATE Price: Call Us |
| 24 |
60-0050 |
SPRING-TRAY, SEAT Price: $78.73 |
| 25 |
1375 |
KEY, WOODRUFF, #61 Price: Call Us |
| 25 |
58-1640 |
PIN-PIVOT, SEAT Price: $59.26 |
| 26 |
3627 |
RING, RETAINING Price: Call Us |
| 26 |
68-7850 |
STRIP-SEALING Price: $41.39 |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 27 |
3830 |
SPROCKET, 18 TEETH Price: Call Us |
| 28 |
3841 |
SPACER Price: Call Us |
| 29 |
3786 |
GEAR, SPUR, 37 TEETH Price: Call Us |
| 30 |
3785 |
GEAR, SPUR, 35 TEETH Price: Call Us |
| 30 |
58-1580-03 |
FRAME-SEAT Price: $402.10 |
| 31 |
3867 |
GEAR, SPUR, 30 TEETH Price: Call Us |
| 31 |
58-9830-03 |
PLATE-SEAT Price: $355.56 |
| 32 |
3783 |
GEAR, SPUR, 25 TEETH Price: Call Us |
| 32 |
5-0652 |
SPACER This part replaces 26-4840. Price: $5.35 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 33 |
3869 |
GEAR, SPUR, 22 TEETH Price: Call Us |
| 34 |
2412-133 |
CLAMP-R Price: $3.19 |
| 34 |
5202 |
GEAR, SPUR, 19 TEETH Price: Call Us |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
3628 |
WASHER, PLAIN .640 X 1.37 X .061 Price: Call Us |
| 36 |
1423 |
WASHER, PLAIN .632 X 1.00 X .026 Price: Call Us |
| 36 |
71-4040 |
HYD FILLER ASM Price: $69.67 |
| 37 |
3422 |
SPACER .630 X 1.00 X .169 Price: Call Us |
| 37 |
58-6820 |
GASKET Price: $13.28 |
| 38 |
4286 |
ASSY GEAR COMB 12&35 TEETH Price: Call Us |
| 39 |
3967 |
SHAFT, IDLER Price: Call Us |
| 40 |
3901 |
SPACER .635 X .875 X .755 Price: Call Us |
| 41 |
3645 |
SPROCKET, 9 TEETH Price: Call Us |
| 42 |
3589 |
GEAR, BEVEL, 42 TEETH Price: Call Us |
| 43 |
4691 |
ASSY, KIT, SHIM .750 SHAFT Price: Call Us |
| 44 |
3882 |
SHAFT, DRIVE Price: Call Us |
| 45 |
3724 |
SCREW TAPPING Price: Call Us |
| 46 |
3646 |
GEAR, SPUR, 12 TEETH Price: Call Us |
| 47 |
3866 |
GEAR, SPUR, 20 TEETH Price: Call Us |
| 48 |
3719 |
GEAR, SPUR, 25 TEETH Price: Call Us |
| 49 |
3868 |
GEAR, SPUR, 28 TEETH Price: Call Us |
| 50 |
3683 |
GEAR, SPUR, 31 TEETH Price: Call Us |
| 51 |
1145 |
WASHER, PLAIN .632 X 1.00 X .060 Price: Call Us |
| 52 |
5130 |
WASHER, NEOPRENE Price: Call Us |
| 53 |
3184 |
WASHER, PLAIN .758 X 1.25 X .031 Price: Call Us |
| 54 |
3880 |
AXLE LEFT HAND Price: Call Us |
| 55 |
3871 |
GEAR MITER 15 TEETH Price: Call Us |
| 56 |
3656 |
RING, RETAINING Price: Call Us |
| 57 |
3839 |
GEAR, SPUR, 32 TEETH Price: Call Us |
| 58 |
3919 |
SHAFT, CROSS Price: Call Us |
| 59 |
3726 |
GEAR, MITER, 15 TEETH Price: Call Us |
| 60 |
3881 |
AXLE, R.H. Price: Call Us |
| 61 |
5304 |
HOUSING LOWER Price: Call Us |
| 62 |
3920 |
PUCK, FRICTION Price: Call Us |
| 63 |
3276 |
DISC, BRAKE Price: Call Us |
| 64 |
3758 |
SPACER Price: Call Us |
| 65 |
3916 |
JAW, BRAKE Price: Call Us |
| 66 |
3843 |
PIN, DOWEL Price: Call Us |
| 67 |
5120 |
SCREW, SELF-TAPPING Price: Call Us |
| 68 |
5285 |
LEVER ACTUATING Price: Call Us |
| 69 |
3760 |
WASHER, PLAIN .321 X 1.00 X .055 Price: Call Us |
| 70 |
3917 |
BRACKET, ANTI-ROTATION Price: Call Us |
| 71 |
3847 |
LOCKNUT 5/16-24 Price: Call Us |
| 72 |
5279 |
SQUARE RING Price: Call Us |
