| Ref | Part Number | Description |
|---|
| 1 |
61-2790 |
FILTER-SCREEN Price: $49.91 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 4 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 5 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 6 |
107-4543 |
CLAMP Price: $13.47 |
| 7 |
108-1605 |
BUMPER-RECESS Price: $10.02 |
| 8 |
115-9793 |
BREATHER Price: $53.38 |
| 9 |
119-0017 |
TANK-HYD Price: $1,499.14 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
119-6968 |
DIPSTICK-OIL Price: $27.53 |
| 11 |
237-101 |
O-RING Price: $2.80 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 12 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 14 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 15 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 64 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 99 |
532194329 |
SHIELD.BROWNING/DEBRIS Price: $17.99 |
