| Ref | Part Number | Description |
|---|
| 1 |
110-4817 |
KIT - AXLE HOUSING This part replaces 95-7538. Price: $657.17 |
| 1 |
132771 |
THROTTLE CONTROL Price: Call Us |
| 2 |
115-0622 |
SEAL - OIL This part replaces 100-2557. Price: $10.23 |
| 2 |
17720410 |
SCREW LT Price: Call Us |
| 3 |
104-2378 |
BUSHING Price: $40.73 |
| 3 |
287707 |
ENGINE B&S Price: Call Us |
| 4 |
137352 |
MUFFLER Price: Call Us |
| 5 |
104-2376 |
KNUCKLE ASM Price: $68.43 |
| 6 |
104-2374 |
BOLT Price: $6.33 |
| 7 |
100-3768 |
LH STEERING ARM ASM Price: $207.28 |
| 8 |
100-3766 |
RH STEERING ARM ASM Price: $207.28 |
| 10 |
95-7547 |
SHIM 0.1 Price: $2.53 |
| 10 |
95-7548 |
SHIM 0.2 Price: $3.52 |
| 10 |
95-7549 |
SHIM 0.3 Price: $3.82 |
| 11 |
99-7597 |
PIN-DOWEL Price: $3.74 |
| 12 |
104-2375 |
BOLT Price: $18.54 |
| 13 |
272293 |
GASKET ENG 1 313 LD TIN PLATED Price: Call Us |
| 13 |
99-7599 |
BOLT Price: $3.17 |
| 14 |
13280324 |
PIPE NIPPLE Price: Call Us |
| 14 |
99-7525 |
STUD Price: $7.03 |
| 15 |
13200300 |
ELBOW Price: Call Us |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
11050600 |
LOCKWASHER Price: Call Us |
| 16 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 18 |
106-1141 |
STEERING TIE ROD ASM This part replaces 100-3762. Price: $642.02 |
| 23 |
156123 |
SHIELD-HEAT Price: Call Us |
| 29 |
137180 |
SUB= 532137180 Price: Call Us |
| 31 |
109202X |
TANK.FUEL.LT. Price: Call Us |
| 32 |
140527 |
CAP ASM FUEL Price: Call Us |
| 33 |
123487X |
HOSE CLAMP Price: Call Us |
| 35 |
17490512 |
SCREW Price: Call Us |
| 37 |
137040 |
LINE FUEL Price: Call Us |
| 40 |
124028X |
SUB= 532124028 Price: Call Us |
| 44 |
17490412 |
SCREW HEX CRT Price: Call Us |
| 46 |
19091416 |
WASHER Price: Call Us |
| 62 |
10040500 |
LOCKWASHER Price: Call Us |
| 78 |
17490620 |
SCREW Price: Call Us |
| 81 |
128861 |
NUT Price: Call Us |
