TRANSMISSION 3
Parts (18)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 506985803 | SPINDLE Price: $179.99 |
| 1 | 95-0909 | LAMP-12 VOLT Price: $30.75 |
| 2 | 3230-28 | SCREW-CARR Price: $3.69 |
| 2 | 738210504 | Ball Bearing 6005-2rs Price: $28.99 |
| 3 | 3253-33 | WASHER-LOCK Price: $1.19 |
| 3 | 738211004 | BALL BEARING 6010 2RS1 Price: $39.99 |
| 4 | 735314010 | CIRCLIP SGH 47 Price: $4.99 |
| 5 | 735312600 | RETAINING RING SGA 25 Price: $2.99 |
| 6 | 506985901 | SHAFT Price: $44.99 |
| 7 | 735312600 | RETAINING RING SGA 25 Price: $2.99 |
| 8 | 506773401 | WASHER Price: $3.99 |
| 9 | 740681421 | V-RING Price: $3.99 |
| 10 | 535406001 | BRACKET Price: $299.99 |
| 26 | 544262101 | BRACKET Price: $39.99 |
| 27 | 506566501 | CLAMP Price: $2.99 |
| 28 | 725236461 | SCREW Price: $2.99 |
| 45 | 506889901 | DRAW RING Price: $17.99 |
| 46 | 725249371 | Screw M10x25 Price: $1.82 |
