| Ref | Part Number | Description |
|---|
| 1 |
120-0244 |
SEAT PLATE ASM Price: $411.04 |
| 1 |
539105024 |
OIL TANK Price: $249.99 |
| 2 |
237-164 |
GROMMET Price: $16.34 |
| 2 |
539102606 |
HYDRAULIC OIL FILTER Price: $22.99 |
| 3 |
539101165 |
FILTER HEAD Price: $37.99 |
| 3 |
83-1040 |
WASHER-FLAT Price: $2.31 |
| 4 |
283-55 |
PIN-CLEVIS Price: $11.14 |
| 4 |
539101202 |
HYDRAULIC CAP Price: $19.99 |
| 5 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 5 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 6 |
117-3067 |
LATCH-SEAT Price: $14.14 |
| 6 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 7 |
104-4821 |
SPRING-TORSION Price: $6.26 |
| 7 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 8 |
283-82 |
PIN-CLEVIS Price: $3.94 |
| 8 |
539113782 |
HYDRAULIC FITTING Price: $5.99 |
| 9 |
104-7201 |
NUT-HF Price: $0.69 |
| 9 |
539102396 |
FITTING Price: $11.99 |
| 10 |
119-1415 |
PIN-COTTER, LOCKING Price: $0.22 |
| 11 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 12 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 12 |
539106933 |
OIL FILTER BRKT Price: $22.99 |
| 13 |
107-1865 |
R-Clamp Price: $6.86 |
| 13 |
539132290 |
HOSE, T-ASM RETURN Price: $37.99 |
| 14 |
3231-40 |
BOLT-CARR, SHORT NECK Price: $1.27 |
| 14 |
539132287 |
HOSE, LPB - MA LINE This part replaces 539132288. Price: $27.99 |
| 15 |
42862 |
BLOCK-TERMINAL, GROUND Price: $19.58 |
| 15 |
539132289 |
HOSE, T-ASM SUPPLY Price: $37.99 |
| 16 |
42863 |
STRIP-JUMPER Price: $2.90 |
| 16 |
539105168 |
NUT 9/16-18 JIC CAP Price: $2.99 |
| 17 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 17 |
539132143 |
HG_PUMP, 10CC W/FAN RIGHT Price: $1,599.99 |
| 18 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 18 |
539132142 |
HG_PUMP, 10CC W/FAN LEFT Price: $1,599.99 |
| 19 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 19 |
539114832 |
DECAL, OIL TANK Price: $2.99 |
| 20 |
117-3065-03 |
PLATE-SEAT Price: $92.88 |
| 20 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 21 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 21 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 22 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 22 |
83-1050 |
SPACER Price: $3.26 |
| 23 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 24 |
121-9076 |
MOUNT-ENGINE Price: $37.76 |
| 24 |
539132284 |
HOSE, RPA - MA LINE Price: $25.99 |
| 25 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 25 |
539132285 |
HOSE, RPB - MB LINE Price: $29.99 |
| 26 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
539132286 |
HOSE, LPA - MB LINE Price: $29.99 |
| 27 |
539132287 |
HOSE, LPB - MA LINE Price: $27.99 |
| 28 |
539101237 |
FITTING, STRAIGHT F6400-8-8-0 Price: $7.99 |
| 29 |
539110814 |
TANK MOUNT Price: $18.99 |
| 31 |
539110815 |
PUSH-MOUNT WIRE CLIP Price: $2.99 |
| 32 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
