| Ref | Part Number | Description |
|---|
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 1 |
92-0450-03 |
BRACKET-PIN Price: $19.10 |
| 2 |
92-0448 |
PIN-PIVOT Price: $100.36 |
| 3 |
106-5247-03 |
TRACTION PEDAL ASM Price: $244.19 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
71-0440 |
ABRASIVE-PEDAL Price: $15.80 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 5 |
95-3857 |
SCREW-HSBH Price: $4.09 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 6 |
80-7730 |
SPACER Price: $1.97 |
| 7 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 8 |
92-7609 |
SHAFT-SPRING Price: $62.79 |
| 9 |
3220-3 |
NUT-HJ Price: $0.28 |
| 10 |
92-7608-03 |
BRACKET-SPRING Price: $16.86 |
| 11 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 11 |
532175370 |
LIFT LINK LH Price: $11.99 |
| 12 |
532175371 |
LIFT LINK RH Price: $11.99 |
| 12 |
92-7610 |
RETAINER-SPRING Price: $26.52 |
| 13 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 15 |
104-7201 |
NUT-HF Price: $0.69 |
| 15 |
532175562 |
PLATE ASM SUSP FRONT Price: $89.99 |
| 16 |
321-9 |
SCREW-HH Price: $0.27 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 20 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 21 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 22 |
71-0450 |
ABRASIVE-PEDAL, REAR Price: $10.39 |
| 23 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
532176205 |
TRUNNION Price: $6.99 |
| 32 |
589464902 |
NUT.LIFT LNK.7/16-2 This part replaces 532175994. Price: $3.99 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
| 51 |
819171416 |
Washer 1 17/32 X 7/8 X 16 Ga Price: $3.99 |
| 52 |
532175378 |
ARM SUSP. REAR LH Price: $44.99 |
| 53 |
532175802 |
ARM SUSP REAR RH Price: $84.99 |
| 54 |
532175560 |
PIN.FLANGE Price: $11.99 |
