| Ref | Part Number | Description |
|---|
| 1 |
5-1828 |
DISCONTINUED Price: Call Us |
| 2 |
161063 |
Muffler Side Price: Call Us |
| 2 |
5-1530 |
DISCONTINUED Price: Call Us |
| 3 |
32964 |
Nut Price: Call Us |
| 4 |
5-1932 |
DISCONTINUED Price: Call Us |
| 5 |
11-3600 |
DISCONTINUED Price: Call Us |
| 5 |
13200300 |
Elbow STD 90 Degree 3/8 - 18 NPT Price: Call Us |
| 6 |
5-3612 |
DISCONTINUED Price: Call Us |
| 7 |
151396 |
Muffler Assembly Guard Price: Call Us |
| 7 |
3211-25 |
Screw Price: Call Us |
| 8 |
121361X |
Pulley V-Idler (AYP part number) Price: Call Us |
| 8 |
5-1787 |
DISCONTINUED Price: Call Us |
| 9 |
150828 |
Keeper Asm. Belt Engine VGT (AYP part number) Price: Call Us |
| 9 |
5-1788 |
DISCONTINUED Price: Call Us |
| 10 |
105432X |
Bushing Price: Call Us |
| 10 |
242-14 |
DISCONTINUED Price: Call Us |
| 11 |
140923 |
Clutch Electric (AYP part number) Price: Call Us |
| 11 |
5-1994 |
DISCONTINUED Price: Call Us |
| 12 |
143996 |
Pulley Engine VGT Elect Clutch Price: Call Us |
| 12 |
6-8730 |
Seat Price: Call Us |
| 13 |
3-6885 |
DISCONTINUED Price: Call Us |
| 14 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 15 |
151346 |
Tank Fuel Rear 3.50 Price: Call Us |
| 15 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 16 |
109227X |
Pad Spacer Price: Call Us |
| 16 |
3-4685 |
WASHER-TOP THRUST Price: $3.60 |
| 17 |
106082X |
Pad Spacer Price: Call Us |
| 17 |
251-167 |
DISCONTINUED Price: Call Us |
| 18 |
140527 |
Cap Asm Fuel W/Sym Vented Price: Call Us |
| 18 |
302-14 |
VENT Price: $8.03 |
| 19 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 20 |
132748 |
Control Throttle (AYP part number) Price: Call Us |
| 20 |
3-6886 |
DISCONTINUED Price: Call Us |
| 21 |
17720410 |
Screw Hex Thd Cut 1/4 - 20 X 5/8 Price: Call Us |
| 21 |
3220-6 |
NUT-JAM Price: $1.25 |
| 22 |
132783 |
Control Choke Price: Call Us |
| 22 |
329-8 |
DISCONTINUED Price: $14.39 |
| 23 |
222-1 |
DISCONTINUED Price: Call Us |
| 24 |
11050600 |
Washer Ext Tooth 3/8 Price: Call Us |
| 24 |
5-1830 |
DISCONTINUED Price: Call Us |
| 25 |
2-8569 |
DISCONTINUED Price: Call Us |
| 25 |
73920600 |
Nut Keps 3/8-24 Unf Price: Call Us |
| 26 |
3219-1 |
NUT-HEX Price: $0.47 |
| 26 |
3645J |
Bushing Price: Call Us |
| 27 |
139277 |
Stem Tank Fuel Price: Call Us |
| 27 |
289-4 |
DISCONTINUED Price: Call Us |
| 28 |
224-1 |
DISCONTINUED Price: Call Us |
| 28 |
7834R |
Fuel Line (AYP part number) Price: Call Us |
| 29 |
132920 |
Spark Arrester Kit Price: Call Us |
| 29 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 30 |
107-9297 |
HOSE-FUEL This part replaces 6-1190. Price: $7.29 |
| 30 |
161547 |
Extrusion Hood Price: Call Us |
| 31 |
5-1781 |
DISCONTINUED Price: Call Us |
| 32 |
17490508 |
Screw Thdrol 5/16-18 x 1/2 Price: Call Us |
| 32 |
3220-5 |
NUT-JAM Price: $0.65 |
| 33 |
3254-4 |
WASHER-LOCK/INT Price: $0.34 |
| 33 |
73800600 |
Nut, Hex W/Ins. 3/8-16 UNC Price: Call Us |
| 34 |
283-82 |
PIN-CLEVIS This part replaces 283-23. Price: $3.94 |
| 35 |
10040500 |
Washer Lock Hvy Hlcl spr 5/16 Price: Call Us |
| 35 |
3-4684 |
DISCONTINUED Price: Call Us |
| 36 |
3-4683 |
DISCONTINUED Price: Call Us |
| 37 |
123487X |
Clamp Hose Price: Call Us |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 38 |
5-1786 |
DISCONTINUED Price: Call Us |
| 38 |
74780624 |
Bolt, Fin Hex 3/8-16 UNC x 1-1/2 Price: Call Us |
| 39 |
17490636 |
Screw TT 3/8-16 x 2-1/4 UNC Price: Call Us |
| 39 |
3-5198 |
DISCONTINUED Price: Call Us |
| 40 |
17490664 |
Screw TT 3/8-16 x 4 UNC Price: Call Us |
| 40 |
5-1785 |
DISCONTINUED Price: Call Us |
| 41 |
126197X |
Washer 1-1/2 OD X 15/32 ID X .250 Price: Call Us |
| 41 |
5-1784 |
DISCONTINUED Price: Call Us |
| 42 |
10040700 |
Washer Lock 7/16 Price: Call Us |
| 42 |
3-7761 |
DISCONTINUED Price: Call Us |
| 43 |
150280 |
Bolt Hex 7/16-20 X 4-1/4 Ga 5 Price: Call Us |
| 43 |
3211-5 |
SCREW-HH Price: $0.88 |
| 44 |
282-4 |
SHACKLE Price: $32.98 |
| 45 |
128861 |
Nut Flange 1/4-20 Starter Nut Price: Call Us |
| 45 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 46 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 47 |
142040 |
Spacer Engine CV22 Round PM Price: Call Us |
| 47 |
3219-3 |
NUT-HEX Price: $0.34 |
| 48 |
19132007 |
Washer 13/32 x 1-1/4 x 7 Ga. Price: Call Us |
| 48 |
3211-13 |
DISCONTINUED Price: Call Us |
| 49 |
3-6750 |
DISCONTINUED Price: Call Us |
| 51 |
165986 |
Manifold Pipe Vgt Price: Call Us |
| 51 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 52 |
5-1748 |
DISCONTINUED Price: Call Us |
| 53 |
5-1783 |
DISCONTINUED Price: Call Us |
| 54 |
19131414 |
Washer Flat 13/32 x 7/8 x 14 Ga. Price: Call Us |
| 54 |
252-6 |
BEARING-NEEDLE Price: $10.72 |
| 55 |
13280336 |
Nipple, Pipe 4-1/2 Price: Call Us |
| 55 |
5-1782 |
DISCONTINUED Price: Call Us |
| 57 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 58 |
5-1738 |
DISCONTINUED Price: Call Us |
| 59 |
5-1791 |
DISCONTINUED Price: Call Us |
| 60 |
3211-4 |
SCREW-HH Price: $1.02 |
| 61 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 62 |
5-1801 |
DISCONTINUED Price: Call Us |
| 63 |
145549 |
Shield, Heat VGT 22 HP YP/Husq. Price: Call Us |
| 65 |
19131614 |
Washer 13/32 x 1 x 14 Ga. (AYP part number) Price: Call Us |
| 69 |
165391 |
Gasket Muffler Price: Call Us |
| 74 |
162295 |
Elbow Street Brass Price: Call Us |
| 75 |
163776 |
Shield Heat Price: Call Us |
| 76 |
17490612 |
Screw Thdrol 3/8-16 x 3/4 Ty-TT Price: Call Us |
