| Ref | Part Number | Description |
|---|
| 1 |
142930 |
Housing, Lower Price: Call Us |
| 1 |
92-9285 |
HOSE-FUEL Price: $19.25 |
| 2 |
108-3282 |
HOSE-FUEL This part replaces 92-9284. Price: $36.93 |
| 2 |
142931 |
Assembly, Upper Housing Price: Call Us |
| 3 |
142932 |
Seal, Lip Price: Call Us |
| 3 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 4 |
142928 |
Ring, Wire Retaining Price: Call Us |
| 4 |
92-9266 |
STANDPIPE Price: $26.91 |
| 5 |
142933 |
Ring, Retaining Price: Call Us |
| 5 |
46-6560 |
BUSHING Price: $2.94 |
| 6 |
142934 |
Bearing, Shaft Ball Price: Call Us |
| 6 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 7 |
142935 |
Bearing, Cradle Price: Call Us |
| 7 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 8 |
150771 |
Bearing, Thrust 30 x 52 x 13 Price: Call Us |
| 8 |
92-9267 |
SENDER-FUEL Price: $118.15 |
| 9 |
142937 |
Swashplate, Variable Price: Call Us |
| 9 |
62-7650 |
GASKET Price: $4.28 |
| 10 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 11 |
92-9272 |
HOSE-FILL, FUEL Price: $52.93 |
| 12 |
110-4112 |
HOSE-FUEL This part replaces 92-9283. Price: $12.60 |
| 13 |
142938 |
Block, Cylinder Assembly Price: Call Us |
| 13 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 14 |
142939 |
Arm, Trunnion Price: Call Us |
| 14 |
92-6064 |
CLAMP-R Price: $2.04 |
| 15 |
142940 |
Seal, Lip Price: Call Us |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 16 |
92-5674 |
NECK-FILL, FUEL Price: $188.78 |
| 17 |
142941 |
Guide, Slot Price: Call Us |
| 17 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 18 |
150772 |
Shaft, Motor Price: Call Us |
| 18 |
92-5675 |
GROMMET Price: $21.90 |
| 19 |
150773 |
Bearing, Thrust 42 x 68 x 16 Price: Call Us |
| 19 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 20 |
93-1402 |
TANK-FUEL Price: $602.12 |
| 21 |
66-6140 |
DECAL Price: $25.48 |
| 22 |
92-5671 |
STRIP-SEALING Price: $20.41 |
| 23 |
142944 |
Block, Cylinder Assembly Price: Call Us |
| 23 |
92-5670 |
STRIP-SEALING Price: $7.03 |
| 24 |
142945 |
Seal, Lip 10 x 25 x 7 Price: Call Us |
| 24 |
92-4703 |
DISCONTINUED Price: $62.47 |
| 25 |
142946 |
Actuator, Bypass Price: Call Us |
| 25 |
32148-9 |
NUT-CLINCH Price: $2.65 |
| 26 |
150774 |
Center Section Assembly Kit Price: Call Us |
| 26 |
321-2 |
SCREW-HH Price: $2.79 |
| 27 |
142948 |
Seal, Lip 26 x 42 x 8 Price: Call Us |
| 27 |
92-6069-03 |
SHIELD-EXHAUST This part replaces 92-6069. Price: $27.08 |
| 28 |
142949 |
Ring, Retaining Price: Call Us |
| 28 |
32128-33 |
NUT-HF Price: $0.25 |
| 29 |
142950 |
Washer 26 x 35 x 1 Price: Call Us |
| 29 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 30 |
150787 |
Plate, Bypass Price: Call Us |
| 30 |
63-8410 |
WASHER Price: $1.76 |
| 31 |
323-5 |
SCREW-HH Price: $0.41 |
| 32 |
52-9590 |
LATCH-SCREEN Price: $6.57 |
| 33 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 34 |
142951 |
Oil Filter Element Price: Call Us |
| 35 |
142952 |
Arm, Bypass Price: Call Us |
| 36 |
142953 |
Ring, Retaining Price: Call Us |
| 37 |
142954 |
Arm, Actuating Price: Call Us |
| 38 |
142955 |
Pin, Actuating Price: Call Us |
| 38 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 39 |
150777 |
Bolt 5/16-24 x 1-3/4 Price: Call Us |
| 40 |
150778 |
Locknut, Hex 5/16-24 UNJC Price: Call Us |
| 40 |
92-5654-03 |
PANEL-OUT, CLEAN This part replaces 92-5654. Price: $113.82 |
| 41 |
142958 |
Brake Rotor/Stator Kit Price: Call Us |
| 41 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 42 |
92-5653-03 |
RING-CLAMP This part replaces 92-5653. Price: $16.40 |
| 43 |
142884 |
Washer 7/16 x 7/8 x .060 Price: Call Us |
| 43 |
92-5269 |
BELLOWS Price: $193.76 |
| 44 |
150829 |
Differential Assembly Price: Call Us |
| 44 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 45 |
240-9 |
GROMMET Price: $3.25 |
| 46 |
3256-51 |
WASHER-FLAT Price: $0.19 |
| 47 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 48 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 52 |
142991 |
Washer 3/4 x 1.5 x .13 Price: Call Us |
| 53 |
142961 |
Seal .75 x 1.25 x .250 Price: Call Us |
| 56 |
142963 |
Shaft, Input Price: Call Us |
| 58 |
142964 |
Bolt 1/4-20 x 1.38 Price: Call Us |
| 59 |
142965 |
Pin .5 OD x .43 ID x .750 Price: Call Us |
| 62 |
142966 |
Arm, Control Price: Call Us |
| 63 |
142967 |
Puck, Dampener Price: Call Us |
| 64 |
142920 |
Set Screw Price: Call Us |
| 68 |
142969 |
Spring Price: Call Us |
| 69 |
144610 |
Stud 5/16-24 Price: Call Us |
| 83 |
142971 |
Jackshaft Assembly Price: Call Us |
| 85 |
150806 |
Jackshaft Price: Call Us |
| 88 |
142973 |
Screw, Cap Price: Call Us |
| 89 |
142974 |
Washer 7/16 x 1 x 1/2 Price: Call Us |
| 90 |
142975 |
Sleeve Bearing Price: Call Us |
| 91 |
142976 |
Seal, Wiper Price: Call Us |
| 92 |
142977 |
Spring, Block Price: Call Us |
| 93 |
142978 |
Washer, Block Thrust Price: Call Us |
| 113 |
142917 |
Cap, Vent Assembly Price: Call Us |
| 114 |
142918 |
Fitting, O-Ring Assembly Price: Call Us |
| 119 |
142980 |
Spacer Price: Call Us |
| 134 |
144607 |
Nut, Castle 5/16-24 Price: Call Us |
| 135 |
144608 |
Pin, Cotter Price: Call Us |
| 139 |
150775 |
Spring, Compression Price: Call Us |
