| Ref | Part Number | Description |
|---|
| 1 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 2 |
146682 |
SPRING.BRAKE.RETU Price: Call Us |
| 2 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 3 |
123666X |
PULLEY TRANS Price: Call Us |
| 3 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 4 |
115-3276 |
KIT-SERVICE, CASTOR FORK This part replaces 99-1492-01. Price: $530.51 |
| 4 |
12000028 |
SUB= 2267J Price: Call Us |
| 5 |
121520X |
STRAP TORQUE Price: Call Us |
| 5 |
70-8370 |
BOLT Price: $73.52 |
| 6 |
17490512 |
SCREW Price: Call Us |
| 6 |
72-9710 |
HUB-TIRE Price: $288.21 |
| 7 |
130802 |
SUB= 162240 Price: Call Us |
| 8 |
131679 |
SHIFT ROD Price: Call Us |
| 8 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 9 |
3296-67 |
NUT-LOCK, NI Price: $5.05 |
| 10 |
106-6774 |
JOINT-BALL Price: $79.04 |
| 10 |
76020416 |
PIN COTTER 1/8 Price: Call Us |
| 11 |
105701X |
WASH-SHFT PLT LT Price: Call Us |
| 11 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 12 |
19151216 |
WASHER Price: Call Us |
| 12 |
32151-104 |
RING-RETAINING, EXTERNAL Price: $4.85 |
| 13 |
132-3778 |
CYLINDER-STEERING This part replaces 93-2122. Price: $786.47 |
| 14 |
10040400 |
LOCKWASHER Price: Call Us |
| 14 |
93-2270 |
HYD HOSE ASM Price: $91.88 |
| 15 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 15 |
74490544 |
BOLT.HX.FLG.5/16 Price: Call Us |
| 16 |
117-9471 |
KIT-SERVICE,GR3250-D STEERING This part replaces 93-2269. Price: $105.67 |
| 17 |
3220-6 |
NUT-JAM Price: $1.25 |
| 18 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 18 |
74780616 |
BOLT Price: Call Us |
| 19 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 19 |
73800600 |
NUT Price: Call Us |
| 20 |
70-8490 |
SPACER-SPINDLE, REAR Price: $24.99 |
| 21 |
106933X |
KNOB T (1/2-HOLE) Price: Call Us |
| 21 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 22 |
130804 |
BRAKE ROD Price: Call Us |
| 22 |
99-1493 |
DECAL Price: $34.25 |
| 23 |
92-5753 |
CLAMP-HOSE Price: $2.10 |
| 24 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 24 |
73350600 |
NUT Price: Call Us |
| 25 |
106888X |
SPRING ROD LT Price: Call Us |
| 25 |
99-1485-01 |
PLATE-ADAPTER, MOTOR Price: $41.54 |
| 26 |
19131316 |
WASHER Price: Call Us |
| 26 |
99-1486-01 |
PLATE-ADAPTER Price: $35.80 |
| 27 |
325-6 |
SCREW-HH Price: $1.42 |
| 27 |
76020412 |
COTTER PIN Price: Call Us |
| 28 |
145204 |
ROD.BRAKE.PARK.LT Price: Call Us |
| 28 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 29 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 29 |
71673 |
PLUNGER CAP T Price: Call Us |
| 30 |
130807 |
TRANSAXLE MTG BKT Price: Call Us |
| 32 |
74760512 |
BOLT Price: Call Us |
| 34 |
155071 |
SHAFT ASM-PEDAL F Price: Call Us |
| 35 |
120183X |
NYLON BEARING Price: Call Us |
| 36 |
19211616 |
WASHER LT Price: Call Us |
| 37 |
1572H |
SUB= 2882J Price: Call Us |
| 38 |
123674X |
PULLEY.IDLER.FLAT Price: Call Us |
| 39 |
74760644 |
BOLT Price: Call Us |
| 40 |
4470J |
SPACER T Price: Call Us |
| 41 |
154777 |
SUB= 165692 Price: Call Us |
| 42 |
19131312 |
WASHER Price: Call Us |
| 47 |
127783 |
SUB= 139245 Price: Call Us |
| 48 |
154604 |
BELLCRANK ASM Price: Call Us |
| 49 |
123205X |
RETAIN BELT Price: Call Us |
| 50 |
74760624 |
SUB= 74930624 Price: Call Us |
| 51 |
73680600 |
SUB= 73690600 Price: Call Us |
| 52 |
73680500 |
SUB= 73690500 Price: Call Us |
| 54 |
2751R |
CLIP T Price: Call Us |
| 56 |
74760620 |
Bolt Fin Flex 3/8-16unc X 1-1/4 Price: Call Us |
| 57 |
130801 |
SUB= 138255 Price: Call Us |
| 59 |
140312 |
KEEPER BELT CNTSP Price: Call Us |
| 61 |
17490612 |
SCREW Price: Call Us |
| 62 |
8883R |
PEDAL COVER T Price: Call Us |
| 63 |
140186 |
PULLEY.ENGINE Price: Call Us |
| 64 |
71170764 |
BOLT Price: Call Us |
| 65 |
10040700 |
LOCKWASHER Price: Call Us |
| 66 |
154778 |
KEEPER-BELT Price: Call Us |
| 70 |
134683 |
KEEPER BELT ENG Price: Call Us |
| 72 |
19132012 |
WASHER Price: Call Us |
| 74 |
137057 |
SPACER AXLE Price: Call Us |
| 75 |
121749X |
WASHER Price: Call Us |
| 76 |
12000001 |
E-RING LT Price: Call Us |
| 77 |
123583X |
SQUARE KEY Price: Call Us |
| 78 |
121748X |
WASHER Price: Call Us |
| 96 |
4497H |
RETAINER M Price: Call Us |
| 112 |
19091210 |
WASHER LT Price: Call Us |
| 116 |
72110610 |
BOLT RDHD 3/8-16 Price: Call Us |
| 118 |
154774 |
SPACER-BELLCRANK Price: Call Us |
